Elite
CS-18
Normally Open
High Power DC-8GHz Multi - Throw Switch
SP7T and SP8T versions only
The CS-18 Switch is a broadband multi-position coaxial switch designed to switch RF signals
from one input port to any one of 3 through 8 output ports. It is readily adapted to any 50 Ohms
transmission line system. The standard actuator gives individual solenoid control of each
position and when de-energized, all positions are open. Standard actuator voltage is 28 VDC.
The primary advantage of this switch over the miniature versions shown on previous pages
is the higher power handling capability.
Specifications
RF Contacts:
Actuator
Break before make
Voltage (VDC) 20 C
Current (mA)
Switching Time:
Connectors:
Weight:
20 msec max
SMA (f), TNC(f), N Type (f)
14 oz. max (8 Position)
O
SP3T to SP6T version available. See additional datasheets
12
15
28
600 480 270
Temperature Range:
-55
O
C to +85
O
C (Operating)
Shock:
Vibration:
Humidity:
Typical
Contact Life:
RF Power Handling
MIL-STD-202 Method 213, Condition D (500G Non Operating)
MIL-STD-202 Method 214, Condition D (10G RMS Non Operating)
Moisture Seal Available
5
Million
Cycles
3000
Typical Performance
Hig
800
400
Sta
Co
nda
nne
rd
N
cto
rs
Power CW (Watts)
Typ
e
Co
nne
200
cto
r
s
15
80
25
40
Return Loss
hP
ow
er
0.01
10
0.1
1.0
4.0
Frequency GHz
10
18
26.5
Frequency GHz
8.0
0.0
Specifications
VSWR (max)
Insertion Loss (max)
Isolation (min)
DC-1 GHz 1-4 GHz
1.25:1
0.30 dB
70.0 dB
1.40:1
0.40 dB
60.0 dB
4-8 GHz
0.4
1.70:1
0.50 dB
60.0 dB
IL dB
60
70
80
90
0.01
Frequency GHz
8.0
Specifications subject to change without notice.
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2007
Isolation dB
High Power DC-8GHz Multi - Throw Switch
SP7T and SP8T versions only
Normally Open
Elite
CS-18
(Number of ports reduced for convenience)
Indicator
(Number of ports reduced for convenience)
Analog
(Number of ports reduced for convenience)
TTL
SP7T
SP8T
H = 2.15 STD Model
H = 2.65 TTL Model
Part Numbering System for CS-18 (Normally Open)
CS-18 N 1 7 O - T
Series
Connectors
Actuator Voltage
Connector
S: SMA Female
N: N type Female
T: TNC Female
Actuator Voltage
1: 28Vdc Normally Open
2: 15Vdc Normally Open
3: 12Vdc Normally Open
Options
Actuator Type
Number of Switch Positions
Number of
Actuator Type
Positions
O: No Indicator Contacts
7: SP7T
C: Indicator Contacts
8: SP8T
For SP3T to SP6T see additional
datasheet
Specifications subject to change without notice.
Options
T: TTL Drivers with Diodes
R: Positive + Common
TD: TTL Driver with Decoder
For other options contact Factory
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2007
