ISOCOM
LTD
IECQ
COMPONENT
SPECIFICATION
Component Specification
For
Ceramic Hermetically Sealed
Transistor Optocouplers
®
QC 88000-C001
ISSUE 8
May 2013
M1077 IECQ
IECQ Product Certificate Number E1280/F
Up-to-date lists and bibliographical references of IECQ publications may be downloaded from
www.iecq.org
Further copies of this document may be obtained from:
IEC
International Electrotechnical Commission
Commission Electrotechnique Internationale
Box 131, rue de Varembé, CH 1211 Geneva 20, Switzerland
For sales enquiries, or further information, please contact our sales office at:
Isocom Ltd, 48, Hutton Close, Crowther Industrial Estate, Washington, Tyne and Wear, UK, NE38 0AH
Tel: +44 0191 4166 546 Fax: +44 0191 4155 055
©2007 Copyright reserved to Isocom Limited
Page 1 of 12
QC 88000-C001: 2013
ISOCOM
LTD
FOREWORD
The IECQ Quality Assessment System for Electronic Components (IECQ) is composed of those member countries of
the International Electrotechnical Commission (IEC) who wish to take part in a harmonized system for electronic
components of assessed quality. IECQ is also known in some European member countries as IECQ-CECC.
The object of the System is to facilitate international trade by the harmonization of the specifications and quality
assessment procedures for electronic components, and by the grant of an internationally recognised Mark, or
Certificate of Conformity. The components produced or services provided under the system are thereby acceptable in
all member countries without further testing.
This Component Specification is based upon the requirements of IECQ 03-3, Annex E (QC 001002-2 Amendment 1,
Clause 5.4) and has been prepared by:
Isocom Ltd
48 Hutton Close
Crowther Industrial Estate
Washington
Tyne and Wear
NE38 0AH
United Kingdom
Tel:
+44 0191 4166 546
Fax:
+44 0191 4155 055
and
®
published under the authority of:
BSI Group
Kitemark Court, Davy Avenue
Knowlhill, Milton Keynes
MK5 8PP
United Kingdom
AMENDMENT RECORD
Issue 1 - Changed Page 10 – Amendments 25/06/09
Issue 2 - Changed Page 4 – Amendments 22/03/10
Issue 3 - Changed Pages 4 & 6 – Updated Drawings 25/06/10
Issue 4 - Changed Pages 3 & 4 – Added devices IS49 & 4N49 05/07/10
Issue 5 - Changed Pages 3, 4, 5, 6, 7 & 10 – RoHS Compliant, Added CSM165-2 & Amendments 13/07/10
Issue 6 – Changed pages 4 & 7, added CH301A and 4/5 pin hybrid outline drawing 26/5/11
Issue 7 – Changed pages 3, added text CH301A and CSM166-4 & page 4, added text CH301A 30/5/13
REQUIREMENTS
The requirements for IECQ Component Specifications as detailed in IECQ 03-3, Annex E (QC 001002-2 Amendment
1, Clause 5.4) are satisfied by the following data sheet.
It should note that IECQ are not responsible for manufacturers declarations made in data sheets which fall outside the
limits of approved detailed in IECQ certificates.
This Component Specification is intended for use with applicable IECQ Assessment Specifications. Eg: QC 88000-
A0001
For sales enquiries, or further information, please contact our sales office at:
Isocom Ltd, 48, Hutton Close, Crowther Industrial Estate, Washington, Tyne and Wear, UK, NE38 0AH
Tel: +44 0191 4166 546 Fax: +44 0191 4155 055
©2007 Copyright reserved to Isocom Limited
Page 2 of 12
QC 88000-C001: 2013
ISOCOM
LTD
Ceramic Hermetically Sealed Transistor Optocouplers
■
■
■
■
■
■
■
■
Features
▪
Released to IECQ
▪
Hermetically Sealed
▪
High Density Packaging
▪
1500V DC withstand Test Voltage
▪
Low Input Requirements
▪
High Current Transfer Ratio
▪
RoHS Compliant
®
4N24
4N49
CD500/501
CH300
CH301A
CS200/201
CS224
CSM200
■
■
■
■
■
■
■
CSM1200
CSM1224
CSM165-2
CSM165-4
CSM166-4
CSM2224
IS49
Applications
▪
Military, high reliability system
▪
Medical instruments
▪
Mos, Cmos Applications
▪
Logic Interfacing
▪
Data Transmission
▪
Power Supply
▪
Modems
Description
These devices are single, dual and quad, hermetically sealed optocouplers. Each channel is
composed of an infra-red emitting diode and a silicon phototransistor. Package styles for these
devices include 6 pin, 8 pin, 16 pin flat pack, and hybrid 4 pin, with surface mount, butt cut and gull
wing options available.
The same electrical die, assembly processes and materials are used for each channel of each
device shown below. Therefore absolute maximum ratings, recommended operating conditions,
electrical specifications and performance characteristics are identical for all units. Any exceptions,
due to packaging variations and limitations, are as noted.
For sales enquiries, or further information, please contact our sales office at:
Isocom Ltd, 48, Hutton Close, Crowther Industrial Estate, Washington, Tyne and Wear, UK, NE38 0AH
Tel: +44 0191 4166 546 Fax: +44 0191 4155 055
©2007 Copyright reserved to Isocom Limited
Page 3 of 12
QC 88000-C001: 2013
ISOCOM
LTD
Selection Guide Package Styles and Configuration Options
Package
4 pin Hybrid
Lead Style
Channels
1
Common Channel Wiring
Isocom Part Numbers and Options
CH300
CH301A
Commercial
CH300/L2
Defense Screen Level
CH301A/L2
CH300/L2S
Space Screen Level
CH301A/L2S
Standard Gold Plate Finish
Solder Dipped
Butt Cut/Gold Plate
Gull Wing/Soldered
Crew Cut/Gold Plate
Metal
Can
1
6 pin LCC
1
6 pin DIP
1
8 pin DIP
2
16 pin
Flat Pack
2/4
®
4N24
4N49
4N24/L2
4N49/L2
4N24/L2S
4N49/L2S
Gold
Plate
Option 20
CSM200, IS49
CSM1200/1244/2224
CSM200/L2, IS49/L2
CSM1200/1244/2224/L2
CSM200/L2S, IS49/L2S
CSM1200/1244/2224/L2S
Gold Plate
Option 20
CS200/201
CS224
CM200/201/L2
CS224/L2
CS200/201/L2S
CS224/L2S
Gold Plate
Option 20
Option 10
Option 30
Option 60
CD500
CD501
CD500/L2
CD501/L2
CD500/L2S
CD501/L2S
Gold Plate
Option 20
Option 10
Option 30
Option 60
CSM165
CSM166
CSM165/L2
CSM166/L2
CSM165/L2S
CSM166/L2S
Gold Plate
Option 20
Functional Diagrams
CH300
CH301A
4/5 pin Hybrid
1 Channel
CS200/201
6 pin DIP
1 Channel
1
2
CSM200
6 pin LCC
1 Channel
6
1
CSM1224
IS49
6 pin LCC
1 Channel
5
4
3
CD500
CD501
8 pin DIP
2 Channel
CSM165-2
16 pin Flat Pack
*2 Channel
6
5
4
4N24
4N49
6 pin TO-5
1 Channel
5
7
3
2
1
CS224
6 pin DIP
1 Channel
6
1
CSM1200
** 6 pin LCC
1 Channel
5
4
3
6
1
CSM2224
6 pin LCC
1 Channel
5
4
3
CSM166-4
16 pin Flat Pack
4 Channel
CSM165-4
16 pin Flat Pack
4 Channel
*
**
Note 2 channel is only for circuit of 2 middle channels 2 & 3 channel on the circuits.
See Outline Drawings 6 Terminal LCC Surface Mount, 1 Channel
For sales enquiries, or further information, please contact our sales office at:
Isocom Ltd, 48, Hutton Close, Crowther Industrial Estate, Washington, Tyne and Wear, UK, NE38 0AH
Tel: +44 0191 4166 546 Fax: +44 0191 4155 055
©2007 Copyright reserved to Isocom Limited
Page 4 of 12
QC 88000-C001: 2013
ISOCOM
LTD
Outline Drawings
16 pin Flat Pack, 2 and 4 Channel
7.24 (0.285)
6.99 (0.275)
®
2.29 (0.09)
max
11.13 (0.438)
10.72 (0.422)
1.27 (0.05)
Ref
0.46 (0.018)
0.36 (0.014)
8.13 (0.32)
Max
0.88 (0.0345)
Min
2.85 (0.112)
Max
0.89 (0.035)
0.69 (0.027)
5.23
(0.206)
Max
0.31 (0.012)
0.23 (0.009)
9.02 (0.355)
8.76 (0.345)
NOTE: DIMENSIONS IN MILLIMETERS
8 pin DIP 2 Channel
9.40 (0.370)
9.91 (0.39)
0.76 (0.03)
1.27 (0.05)
8.13 (0.32)
Max
7.16 (0.282)
7.57 (0.298)
0.51 (0.020)
Min
3.81 (0.15)
Min
2.29 (0.09)
2.79 (0.11)
For sales enquiries, or further information, please contact our sales office at:
Isocom Ltd, 48, Hutton Close, Crowther Industrial Estate, Washington, Tyne and Wear, UK, NE38 0AH
Tel: +44 0191 4166 546 Fax: +44 0191 4155 055
©2007 Copyright reserved to Isocom Limited
Page 5 of 12
QC 88000-C001: 2013
4.32 (0.17)
Max
0.2 (0.008)
0.33 (0.013)
7.36 (0.29)
7.87 (0.31)
NOTE: DIMENSIONS IN MILLIMETERS
0.51 (0.02)
Max
