REVISION CB
DO NOT
SCALE FROM
THIS PRINT
No OF POSITIONS x .100[2.54]
+.000[0.00]
(MOLD TO POSITION:
-.005[0.13]
)
(CUT TO POSITION: ±.010[.25] - SEE NOTE 4)
(No OF POS x .100[2.54]) - (.100[2.54])
BCS-1XX-XXX-X-XX-XXX
C
-T:
-L:
No OF POSITIONS
-01 THRU -50
PLATING SPECIFICATIONS
(SEE TABLE 1)
.050 1.27 REF
MATTE TIN CONTACT AND TAIL
10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-F: 3µ" FLASH SELECTIVE GOLD CONTACT AREA,
MATTE TIN ON TAIL
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-H: 30µ" HEAVY GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-SM: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-TM: MATTE TIN CONTACT AND TAIL
-LM: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-FM: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-LTL: 10µ’’ LIGHT SELECTIVE GOLD IN CONTACT AREA,
TIN LEAD (90/10 +/-5%) ON TAIL
POLARIZING OPTION
INSERT PK-06-N INTO SPECIFIED
POS AND BREAK OFF TAB
(NOT AVAILABLE FOR -BE OPTION)
"B"
-02
-50
.100 2.54 REF
-01
"B"
1st POSITION
-50
-49
ENTRY SPECIFICATION
-DE: DUAL ENTRY (SEE TABLE 1)
-TE: TOP ENTRY (SEE TABLE 1)
-HE: HORIZONTAL ENTRY (SEE TABLE 1)
-PE: PASS-THROUGH ENTRY (SEE TABLE 1)
-DE-BE: (SEE TABLE 1)
-PE-BE: (SEE TABLE 1)
BODY SPECIFICATION
-S: SINGLE ROW (SEE TABLE 1)
-D: DOUBLE ROW (SEE TABLE 1)
"A"
-02
.200 5.08 REF
.100 2.54 REF
"A"
-49
-01
.119 3.02
C
(SEE NOTE 9)
.290 7.37
REF
CONTACT #1
-DE/-DE-BE
FIG 1(SEE NOTE 11)
CONTACT #1
2 MAX SWAY
IN EITHER DIRECTION
.16 4.1
C
.06 1.6
C
2 MAX SWAY
2 MAX SWAY
SECTION "A"-"A"
BCS-1XX-X-D-DE
SECTION "B"-"B"
BCS-1XX-X-S-DE
NOTES:
1.
2.
3.
4.
5.
6.
7.
C
(-DE TAIL ORIENTATION)
(-TE TAIL ORIENTATION)
(-HE TAIL ORIENTATION)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
ANGLES
*
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
8.
9.
10.
11.
REPRESENTS CRITICAL DIM. FOR STATISTICAL PROCESS CONTROL.
MINIMUM PUSHOUT FORCE TO BE: 1 LB.
[ ] DIMENSIONS ARE IN MILLIMETERS.
MINIMUM WALL THICKNESS ON CUT PARTS: .009 [0.23].
CUT PARTS TO BE SYMMETRICAL ABOUT C .
L
1st POSITION WILL ALWAYS POINT UP ON TOP VIEW AS SHOWN.
1 THROUGH 4 POSITIONS ARE TO BE LAYER PACKAGED, 5 THROUGH
50 POSITIONS ARE TO BE TUBED FOR ALL ENTRY SPECIFCATION EXCEPT
BCS-S-HE AND BCS-D-HE. FOR BCS-S-HE AND BCS-D-HE, 1 THROUGH 3
POSITIONS ARE TO BE LAYER PACKAGED, 4 THROUGH 50 POSITIONS ARE TO BE TUBED.
DAMAGE TO THE CUT SURFACE CAN NOT EFFECT LEAD-IN OF THE CORES.
MAXIMUM VARIATION WITHIN A ROW: .006 [0.15].
MAXIMUM VARIATION FROM ROW TO ROW: .012 [0.30].
MAXIMUM CUT FLASH: .015 [0.38].
CHAMFERED END-WALLS MAY OR MAY NOT BE PRESENT ON ONE OR BOTH ENDS OF
FINISHED GOOD.
(-PE TAIL ORIENTATION)
*
.XX: .01[0.3]
2
.XXX: .005[0.13]
.XXXX: .0020[0.051]
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: GLASS FILLED LCP UL 94 VO, COLOR: BLACK
CONTACT: PHOS. BRONZE
BOX CONNECTOR SOCKET STRIP
BCS-1XX-XXX-X-XX-XXX
09/12/1991
SHEET
1
OF
3
F:\DWG\MISC\MKTG\BCS-1XX-XXX-X-XX-XXX-MKT.SLDDRW
BY:
KOLB
REVISION CB
C
.147 3.73
.320 8.13
REF
CONTACT #1
.143 3.63
C
.290 7.37
REF
CONTACT #1
.110 2.79 REF
IN-PROCESS
-S-HE
.125 3.18 REF
"C"
-01
-50
CONTACT # 2
.015 0.38 REF
C
.122 3.10
.10 2.59
C
2 MAX SWAY
(EITHER DIRECTION)
C
.122 3.10
"C"
2 MAX SWAY
IN EITHER DIRECTION
.31 7.9
C
+0.254
3.18
- 0.381
2 MAX SWAY
(EITHER DIRECTION)
C
2 MAX SWAY
(EITHER DIRECTION)
C
BCS-1XX-X-S-HE
SEE NOTE 11
+.010
.125
- .015
SECTION "C"-"C"
C
.250
+.005
6.35
+0.127
- .003
- 0.076
CONTACT #1
BCS-1XX-XXX-D-TE
FIG 3
-TE
BCS-1XX-X-S-TE
FIG 2
-HE
CONTACT #1
.320 8.13
REF
.150 3.81
CONTACT #1
CONTACT #2
C
.293 7.44 REF
IN-PROCESS
-D-HE
(NO. OF POS x .100[2.54]) - .100[2.54]
(NO. OF POS x .100[2.54])±.008[0.20]
.050 1.27 REF
.30 7.6
C
.128±.010 3.25±0.254
C
C
.20 5.1
.310 7.88
.128±.010 3.25±0.254
"D"
.210 5.33
REF
50
02
.100 2.54 REF
C
BCS-1XX-X-S-PE
.0700 1.779
REF
.015 0.38 REF
BCS-1XX-XXX-D-PE
49
01
.225 5.72
REF
.125
- .015
3.16
- 0.381
*
PROPRIETARY NOTE
*
"D"
2 MAX SWAY
IN EITHER DIRECTION
2 MAX SWAY
(EITHER DIRECTION)
+0.254
+.010
-PE/-PE-BE
(SEE SHEET 3 FOR IN-PROCESS)
FIG 4
BCS-1XX-X-D-HE
C
+.015
.310
- .010
+0.381
7.87
- 0.254
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
SECTION "D"-"D"
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DO NOT SCALE DRAWING
DESCRIPTION:
DWG. NO.
BOX CONNECTOR SOCKET STRIP
SHEET SCALE: 2:1
BCS-1XX-XXX-X-XX-XXX
09/12/1991
SHEET
2
OF
3
F:\DWG\MISC\MKTG\BCS-1XX-XXX-X-XX-XXX-MKT.SLDDRW
BY:
KOLB
REVISION CB
IN-PROCESS 1
BCS-1XX-X-D-PE
(SAME FOR -BE)
IN-PROCESS
BCS-1XX-X-S-PE
(SAME FOR -BE)
IN-PROCESS
IN-PROCESS 2
IN-PROCESS 1
IN-PROCESS 2
.176 4.47
C
.544 13.83
REF
.176 4.47
C
-50
-02
-01
(SEE NOTE 6)
.445 11.31
REF
-50
-01
-50
-01
-01
-02
-49
-50
-49
-49
-02
-S-BE: (SAME AS FIG 1 EXCEPT AS SHOWN
-D-BE: (SAME AS FIG 1)
PT-3-24-01-01
PT-1-24-01-15
-49
-02
-S-PE-BE: (SAME AS -S-PE EXCEPT AS SHOWN)
-D-PE-BE: (SAME AS -D-PE)
PT-1-24-01-24
PT-1-24-01-22
BCS-S-DE
BCS-S-DE-BE
BCS-D-PE
BCS-D-PE
BCS-D-PE-BE
BCS-D-PE-DE-BE
BCS-S-TE
BCS-D-TE
PT-1-24-03-29
PT-1-24-04-38
PT-1-24-20-09
BCS-S-HE
(SEE NOTE 7)
BCS-S-PE
BCS-S-PE-BE
BCS-D-HE
(SEE NOTE 7)
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DO NOT SCALE DRAWING
DESCRIPTION:
DWG. NO.
BOX CONNECTOR SOCKET STRIP
SHEET SCALE: 2:1
BCS-1XX-XXX-X-XX-XXX
09/12/1991
SHEET
3
OF
3
F:\DWG\MISC\MKTG\BCS-1XX-XXX-X-XX-XXX-MKT.SLDDRW
BY:
KOLB
