LMUN2131T1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> LMUN2131T1

LMUN2131T1: DescriptionSmall Signal Bipolar Transistor, 0.1A I(C), 1-Element, PNP, Silicon,; CategoryDiscrete semiconductor The transistor; File Size185KB，12 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn; Environmental Compliance

Download Datasheet Parametric View All

LMUN2131T1 Overview

Small Signal Bipolar Transistor, 0.1A I(C), 1-Element, PNP, Silicon,

LMUN2131T1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	LRC
package instruction	,
Reach Compliance Code	unknown
Maximum collector current (IC)	0.1 A
Minimum DC current gain (hFE)	8
Number of components	1
Polarity/channel type	PNP
Maximum power dissipation(Abs)	0.338 W
surface mount	YES
Transistor component materials	SILICON

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

Bias Resistor Transistors

PNP Silicon Surface Mount Transistors

with Monolithic Bias Resistor Network

This new series of digital transistors is designed to replace a single device and its external

resistor bias network. The BRT (Bias Resistor Transistor) contains a single transistor with a

monolithic bias network consisting of two resistors; a series base resistor and a base–emitter

resistor. The BRT eliminates these individual components by integrating them into a single

device. The use of a BRT can reduce both system cost and board space. The device is housed

in the SC–59 package which is designed for low power surface mount applications.

• Simplifies Circuit Design

• Reduces Board Space

• Reduces Component Count

• Moisture Sensitivity Level: 1

• ESD Rating – Human Body Model: Class 1

ESD Rating

– Machine Model: Class B

• The SC–59 package can be soldered using wave or reflow.

The modified gull–winged leads absorb thermal stress during soldering eliminating the

possibility of damage to the die.

• Available in 8 mm embossed tape and reel

Use the Device Number to order the 7 inch/3000 unit reel.

DEVICE MARKING INFORMATION

See detailed ordering and shipping information on page 2 of this data sheet.

ORDERING INFORMATION

*See device marking table on page 2 of this data sheet.

LMUN2111T1

SERIES

SC–59

CASE 318D, PLASTIC

PIN 2

BASE

(INPUT)

PIN 3

COLLECTOR

(OUTPUT)

PIN 1

EMITTER

(GROUND)

MARKINGDIAGRAM

6X = Specific Device Code*

M = Date Code

MAXIMUM RATINGS

= 25°C unless otherwise noted)

Rating

Collector-Base Voltage

Collector-Emitter Voltage

Collector Current

THERMAL CHARACTERISTICS

Characteristic

Total Device Dissipation

= 25°C

Derate above 25°C

Thermal Resistance –

Junction-to-Ambient

Thermal Resistance –

Junction-to-Lead

Junction and Storage

Temperature Range

1. FR–4 @ Minimum Pad

2. FR–4 @ 1.0 x 1.0 inch Pad

Symbol

CBO

CEO

Symbol

Value

100

Unit

Vdc

mAdc

Max

230(Note 1)

338(Note 2)

1.8 (Note 1)

2.7 (Note 2)

540(Note 1)

370(Note 2)

264(Note 1)

287(Note 2)

–55 to +150

Unit

°C/W

°C

θJA

θJL

, T

stg

LMUN2111T1 Series–1/12
