IHTH-0750JZ-40
Vishay Dale
High Current Inductor, High Temperature Series
FEATURES
•
Shielded construction
•
Frequency range up to 1.0 MHz
RoHS
•
Handles high transient current spikes without
COMPLIANT
saturation
•
Ultra low buzz noise, due to composite construction
•
100 % lead (Pb)-free and RoHS compliant
APPLICATIONS
•
•
•
•
•
Automotive
Desktop/Server applications
Line filters
Motor control systems
DC/DC converters in distributed power systems
Manufactured under one or more of the following:
US Patents; 6,198,375/6,204,744/6,449,829/6,460,244.
Several foreign patents, and other patents pending.
STANDARD ELECTRICAL SPECIFICATIONS
Lo
HEAT
INDUCTANCE
RATING SATURATION
µH ± 20 %
DCR mΩ DCR mΩ CURRENT
CURRENT
at 100 kHz, TYPICAL
MAX.
DC AMPS
3
DC AMPS
4
0.25 V, 0 A
at 25 °C at 25 °C
TYPICAL
TYPICAL
2.2
0.80
1.20
35
35
DIMENSIONS
in inches [millimeters]
0.375 ± 0.010
[9.53 ± 0.254]
0.050 ± 0.005
[1.27 ± 0.127]
D ± 0.005 [0.127]
4.7
2.50
3.00
22
22
0.750 ± 0.005
[19.05 ± 0.127]
10
5.30
6.00
17
17
0.300 ± 0.005
[7.62 ± 0.127]
22
9.00
10.00
11
11
B ± 0.005 [0.127]
C ± 0.010 [0.254]
A ± 0.005 [0.127]
NOTES:
1. All test data is referenced to 25 °C ambient
2. Operating Temperature Range - 55 °C to + 155 °C
3. DC current (A) that will cause an approximate
ΔT
of 40 °C
4. DC current (A) that will cause Lo to drop approximately 20 %
5. The part temperature (ambient + temp rise) should not exceed
155 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
VALUE
2.2 µH
4.7 µH
10 µH
22 µH
A
0.454 [11.52]
0.445 [11.29]
0.486 [12.34]
0.430 [10.92]
B
0.184 [4.69]
0.188 [4.78]
0.216 [5.48]
0.142 [3.60]
C
0.269 [6.84]
0.256 [6.51]
0.270 [6.86]
0.288 [7.32]
D
0.090 [2.28]
0.073 [1.86]
0.060 [1.51]
0.054 [1.37]
DESCRIPTION
IHTH-0750JZ-40
MODEL
4.7
µ
H
INDUCTANCE
VALUE
± 20
%
INDUCTANCE
TOLERANCE
EB
PACKAGE
CODE
e2
JEDEC LEAD (Pb)-FREE
STANDARD
GLOBAL PART NUMBER
I
H
T
H
0
7
5
SIZE
0
J
Z
E
B
4
R
7
M
4
0
MODEL
PACKAGE
CODE
INDUCTANCE INDUCTANCE SERIES
TOLERANCE
VALUE
Document Number: 34202
Revision: 05-Dec-06
www.vishay.com
44
For technical questions, contact: magnetics@vishay.com
