RF Shielded Inductors
TYPE MSC60 SERIES
Meggitt Sigma quality and reliability are guaranteed in this
range of case moulded shielded RF inductors. Their small
size make them ideal for use when space is at a premium and
they are also fully protected from environmental factors
by the moulded body. With a 3% max. degree of coupling,
an environmental classification of 55/100/56 and values from
10 nanno henries to 10 milli henries. This inductor is a
natural choice for new designs.
MEGGITT SIGMA
KEY FEATURES
±10% STANDARD_ OTHER TOLS. AVAILABLE
OPERATING TEMPERATURE -55°C to 105°C
MAX TEMPERATURE RISE +15°C
ALTITUDE TEST 70,000 FEET
TERMINAL PULL STRENGTH 5lbs
WEIGHT 0.75g MAX.
DIELECTRIC WITHSTAND 1000 VRMS
ATTRACTIVELY PRICED
AVAILABLE TAPED
MEGGITT
ELECTRONIC
COMPONENTS
SALES ACTION DESK
TEL: (01793 611666)
FAX: (01793 611777)
EMAIL: sales@megelec.co.uk
WEB SITE: www.megelec.co.uk
LOG No FO621
ISSUE 3
2-PAGES
01-01
SPECIFICATION
Inductance
Code
R10
R12
R15
R18
R22
R27
R33
R39
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
MSC60 SERIES
Inductance
±10%µ
±10%µH
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
PAGE 2 OF 2
Q
Min.
50
51
51
50
49
47
46
44
44
43
42
40
44
44
44
44
44
44
44
44
44
44
50
50
50
55
45
45
45
45
45
50
50
50
50
50
50
55
55
55
55
55
55
60
60
60
60
60
60
45
45
45
45
45
45
45
45
44
40
40
40
Test Freq.
(L&Q)
MHz
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
SRF
(Min)
MHz
250
250
250
250
250
250
250
250
235
210
190
180
140
130
115
105
100
92
85
75
70
65
55
50
46
44
49
45
41
38
34
29
27
25
21
10.5
10.0
9.7
8.5
8.0
7.5
7.0
6.5
6.2
5.7
4.7
4.5
4.2
3.8
1.5
1.2
1.0
0.97
0.92
0.84
0.80
0.74
0.73
0.66
0.54
0.47
DCR
(Max)
ohms
0.025
0.034
0.037
0.047
0.067
0.11
0.13
0.18
0.25
0.33
0.45
0.59
0.07
0.10
0.12
0.14
0.19
0.28
0.35
0.40
0.55
0.72
1.02
0.32
0.62
2.00
0.80
0.89
0.96
1.19
0.37
0.93
2.11
2.23
2.70
2.44
3.12
3.60
4.10
4.40
5.00
5.80
6.40
7.40
9.50
10.50
11.80
13.00
17.50
22.10
26.50
29.90
33.80
47.30
53.00
73.80
81.60
98.90
111.00
119.00
137.00
Rated DC
Current
mA at 90°C
1790
1530
1470
1300
1100
855
780
670
565
490
420
370
1070
895
815
775
650
535
480
450
380
335
280
250
220
200
315
300
290
260
240
205
195
190
170
180
160
150
140
135
125
115
110
105
92
90
80
80
70
60
55
50
50
40
40
35
31
28
27
26
24
Color coded in accordance with MILC - 15305
DIMENSIONS
1.438 ± 0.188
36.525 ± 4.77
0.410 ± 0.010
10.414 ± 0.25
0.162 ± 0.10
4.115 ± 0.25
0.0253 DIA 0.64 DIA
HOW TO ORDER
MSC60
PART
COMMON PART
MSC60 -
Axial Wound
Inductor
1R8
INDUCTANCE VALUE
INDUCTANCE VALUE
Inductance Code
See Table above
K
TOLERANCE
T
PACK STYLE
L - Loose
T - Ammo Box 1000
R - Reeled 2000
K ± 10%
Meggitt Electronic Components Ltd. Ohmic House, Westmead Industrial Estate, Swindon, Wilts. SN5 7US
Telephone:(01793)487301 (Admin.) (01793)611666 (Sales) Email: sales@megelec.co.uk Fax:(01793) 611777
This publication is issued to provide outline information only and (unless specifically agreed to the contrary by the Company in writing) is not to form part of any order
or be regarded as a representation relating to the products or service concerned. We reserve the right to alter without notice the specification, design, price or conditions
of supply of any product or service. Whilst Meggitt Electronic Components products are of the very highest quality and reliability, all electronic components can
occasionally be subject to failure. Where failure of a Meggitt Electronic Components product could result in life threatening consequences, then the circuit and application
must be discussed with the Company. Such areas might include ECG, respiratory. and other medical and nuclear applications and any non fail safe applications circuit.
