MBR16xx, MBRF16xx & MBRB16xx Series
Vishay Semiconductors
formerly General Semiconductor
Schottky Barrier Rectifier
Reverse Voltage
35 to 60V
Forward Current
16A
ITO-220AC (MBRF16xx)
0.405 (10.27)
0.383 (9.72)
0.188 (4.77)
0.172 (4.36)
0.110 (2.80)
0.100 (2.54)
0.140 (3.56)
DIA.
0.130 (3.30)
0.131 (3.39)
DIA.
0.122 (3.08)
TO-220AC (MBR16xx)
0.415 (10.54) MAX.
0.154 (3.91)
0.370 (9.40)
0.360 (9.14)
0.148 (3.74)
0.113 (2.87)
0.103 (2.62)
0.145 (3.68)
0.135 (3.43)
0.410 (10.41)
0.390 (9.91)
PIN
1
0.160 (4.06)
0.140 (3.56)
2
1.148 (29.16)
1.118 (28.40)
0.110 (2.79)
0.100 (2.54)
0.560 (14.22)
0.530 (13.46)
CASE
1
0.185 (4.70)
0.175 (4.44)
DIA.
0.055 (1.39)
0.045 (1.14)
0.600 (15.5)
0.580 (14.5)
0.676 (17.2)
0.646 (16.4)
0.350 (8.89)
0.330 (8.38)
PIN
2
0.635 (16.13)
0.625 (15.87)
0.350 (8.89)
0.330 (8.38)
0.603 (15.32)
0.573 (14.55)
0.560 (14.22)
0.530 (13.46)
0.191 (4.85)
0.171 (4.35)
0.060 (1.52)
PIN 1
PIN 2
0.110 (2.80)
0.100 (2.54)
PIN 1
PIN 2
0.205 (5.20)
0.195 (4.95)
0.037 (0.94)
0.027 (0.69)
0.022 (0.55)
0.014 (0.36)
0.105 (2.67)
0.095 (2.41)
0.205 (5.20)
0.195 (4.95)
0.037 (0.94)
0.027 (0.68)
0.022 (0.56)
0.014 (0.36)
TO-263AB (MBRB16xx)
0.411 (10.45)
0.380 (9.65)
0.190 (4.83)
0.160 (4.06)
0.055 (1.40)
0.045 (1.14)
Mounting Pad Layout TO-263AB
0.42
(10.66)
0.245 (6.22)
MIN
K
0.055 (1.40)
0.047 (1.19)
1
K
2
0.624 (15.85)
0.591 (15.00)
0-0.01 (0-0.254)
0.110 (2.79)
0.090 (2.29)
0.027 (0.686)
0.037 (0.940)
PIN 1
PIN 2
K - HEATSINK
0.33
(8.38)
0.63
(17.02)
Dimensions in inches
and (millimeters)
0.360 (9.14)
0.320 (8.13)
0.021 (0.53)
0.014 (0.36)
0.140 (3.56)
0.110 (2.79)
0.08
(2.032)
0.24
(6.096)
0.105 (2.67)
0.12
(3.05)
0.095 (2.41)
0.205 (5.20)
0.195 (4.95)
Features
•
Plastic package has Underwriters Laboratory
Mechanical Data
Case:
JEDEC TO-220AC, ITO-220AC & TO-263AB
molded plastic body
Terminals:
Plated leads, solderable per
MIL-STD-750, Method 2026
Polarity:
As marked
Mounting Position:
Any
Mounting Torque:
10 in-lbs maximum
Weight:
0.08 oz., 2.24 g
www.vishay.com
1
Flammability Classifications 94V-0
•
Metal silicon junction, majority carrier conduction
•
Low power loss, high efficiency
•
Guardring for overvoltage protection
•
For use in low voltage, high frequency inverters,
free wheeling, and polarity protection applications
•
High temperature soldering guaranteed:
250°C/10 seconds, 0.25" (6.35mm) from case
Document Number 88671
03-Mar-03
MBR16xx, MBRF16xx & MBRB16xx Series
Vishay Semiconductors
formerly General Semiconductor
Maximum Ratings
Parameter
(T
C
= 25°C unless otherwise noted)
Symbol
V
RRM
V
RWM
V
DC
I
F(AV)
I
FRM
MBR1635
MBR1645
MBR1650
MBR1660
Unit
V
V
V
A
A
Maximum repetitive peak reverse voltage
Working peak reverse voltage
Maximum DC blocking voltage
Maximum average forward rectified current at T
C
= 125 °C
Peak repetitive forward current at T
C
= 125°C
(rated V
R
, sq. wave, 20 KHz)
Peak forward surge current
8.3ms single half sine-wave superimposed
on rated load (JEDEC Method)
Peak repetitive reverse current
at t
p
= 2.0µs, 1KH
Z
Voltage rate of change (rated V
R
)
Operating junction temperature range
Storage temperature range
RMS Isolation voltage (MBRF type only) from terminals to
heatsink with t = 1.0 second, RH
≤
30%
35
35
35
45
45
45
16
32
50
50
50
60
60
60
I
FSM
150
A
I
RRM
dv/dt
T
J
T
STG
V
ISOL
1.0
10,000
–65 to +150
–65 to +175
4500
(NOTE 1)
3500
(NOTE 2)
1500
(NOTE 3)
0.5
1,000
A
V/µs
°C
°C
V
Electrical Characteristics
(T
Parameter
C
= 25°C unless otherwise noted)
Symbol
V
F
MBR1635
MBR1645
MBR1650
MBR1660
Unit
V
mA
Maximum instantaneous forward voltage
(Note 4)
at I
F
= 16A,
T
C
= 25°C
at I
F
= 16A,
T
C
= 125°C
Maximum instantaneous reverse current T
C
= 25°C
at rated DC blocking voltage
(Note 4)
T
C
= 125°C
0.63
0.57
0.2
40
0.75
0.65
1.0
50
I
R
Thermal Characteristics
(T
Parameter
C
= 25°C unless otherwise noted)
Symbol
R
ΘJC
MBR
1.5
MBRF
3.0
MBRB
1.5
Unit
°C/W
Typical thermal resistance from junction to case
Notes:
(1) Clip mounting (on case), where lead does not overlap heatsink with 0.110” offset
(2) Clip mounting (on case), where leads do overlap heatsink
(3) Screw mounting with 4-40 screw, where washer diameter is
≤
4.9 mm (0.19”)
(4) Pulse test: 300µs pulse width, 1% duty cycle
Ordering Information
Product
MBR1635 - MBR1660
MBRF1635 - MBRF1660
MBRB1635 - MBRB1660
Case
TO-220AC
ITO-220AC
TO-263AB
Package Code
45
45
31
45
81
Package Option
Anti-Static tube, 50/tube, 2K/carton
Anti-Static tube, 50/tube, 2K/carton
13” reel, 800/reel, 4.8K/carton
Anti-Static tube, 50/tube, 2K/carton
Anti-Static 13” reel, 800/reel, 4.8K/carton
www.vishay.com
2
Document Number 88671
03-Mar-03
MBR16xx, MBRF16xx & MBRB16xx Series
Vishay Semiconductors
formerly General Semiconductor
Ratings and
Characteristic Curves
(T
20
A
= 25°C unless otherwise noted)
Fig. 1 - Forward Current
Derating Curve
150
Fig. 2 - Maximum Non-Repetitive Peak
Forward Surge Current
Peak Forward Surge Current (A)
T
J
= T
J
max.
8.3ms single half sine-wave
(JEDEC method)
Resistive or Inductive Load
Average Forward Current (A)
16
125
100
12
75
50
8
4
25
0
1
10
100
0
0
50
100
150
Case Temperature (°C)
Number of Cycles at 60 Hz
Fig. 3 - Typical Instantaneous
Forward Characteristics
50
50
Fig. 4 - Typical Reverse Characteristics
Instantaneous Reverse Current (mA)
T
J
= 125°C
10
Instantaneous Forward Current (A)
10
T
J
= 150°C
Pulse Width = 300µs
1% Duty Cycle
1
T
J
= 75°C
1
0.1
T
J
= 25°C
0.01
MBR1635 - MBR1645
MBR1650 - MBR1660
0
20
40
60
80
100
T
J
= 25°C
0.1
MBR1635 - MBR1645
MBR1650 - MBR1660
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
0.001
Instantaneous Forward Voltage (V)
Percent of Rated Peak Reverse Voltage (%)
Fig. 5 - Typical Junction Capacitance
5,000
T
J
= 25°C
f = 1.0 MH
Z
Vsig = 50mVp-p
100
Fig. 6 - Typical Transient Thermal
Impedance
Transient Thermal Impedance (°C/W)
Junction Capacitance (pF)
10
1,000
1
MBR1635 - MBR1645
MBR1650 - MBR1660
100
0.1
1
10
100
0.1
0.01
0.1
1
10
100
Reverse Voltage (V)
Document Number 88671
03-Mar-03
t, Pulse Duration (sec.)
www.vishay.com
3
