(5 mm) AlInGaP Lamps
Technical Data
HLMP-Cx08 Series
HLMP-Cx25 Series
Features
High Intensity
General Purpose Leads
Popular 5 mm Diameter
Available in Bulk, Tape
and Reel, or Ammopack
• 8
°
or 25
°
Viewing Angles
• Choice of Colors:
Amber or Red
•
•
•
•
• Spoiler, Car Decorative
Lighting
• Motorcycle/Bicycle Warning
Lights
Description
The HLMP-Cx08 and HLMP-Cx25
series are 5 mm lamps specially
designed for applications requir-
ing very high on-axis intensity
that is not achievable with a
standard lamp. These devices
are capable of producing light
output over a wide range of
drive currents.
Built using AlInGaP technology,
they are well suited for typical
5 mm TS-AlGaAs lamp applica-
tions, and have significantly
Applications
•
•
•
•
Indoor/Outdoor Applications
Small Store-front Signs
Message Panels
Road Construction Barrier
Lights
• Center High Mount Stop
Lights
SUPERIOR RELIABILITY than
most TS-AlGaAs lamps in wet/
hot environments. These lamps
come with clear non-diffused
lens and are optically designed
to yield superior light output.
Device Selection
Part Number
HLMP-C008-U0000
HLMP-C208-S0000
HLMP-C608-R0000
HLMP-C025-P0000
HLMP-C225-O0000
HLMP-C625-P0000
Typical Viewing Angle
[1]
(degrees), 2
1
/
2
Typ.
8
8
8
25
25
25
Luminous Intensity,
Iv (mcd) @ 20 mA
Min.
Typ.
2900
6000
2600
3000
1000
2000
500
1000
450
800
500
700
Color
Red
Amber
Red
Red
Amber
Red
Dominant
Wavelength
[2]
626
590
635
626
590
635
Notes:
1.
1
/
2
is the off-axis angle at which the luminous intensity is half of the axial luminous intensity.
2. The dominant wavelength
d
, is derived from the CIE chromaticity diagram and represents the single wavelength which defines the
color of the device.
2
Package Dimensions
5.08 (0.200)
4.57 (0.180)
9.19 (0.352)
8.43 (0.332)
0.89 (0.035)
0.64 (0.025)
23.0
(0.90) MIN.
0.45 (0.018)
SQUARE NOMINAL
1.27 (0.050)
NOM.
6.10 (0.240)
5.59 (0.220)
CATHODE
2.54 (0.100)
NOM.
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
2. AN EPOXY MENISCUS MAY EXTEND ABOUT
1 mm (0.040") DOWN THE LEADS.
Absolute Maximum Ratings at T
A
=25
°
C
Parameter
Peak Forward Current
Average Forward Current
[1]
DC Current
[2]
Reverse Voltage (I
R
= 100
µA)
LED Junction Temperature
Operating Temperature
Storage Temperature
Lead Soldering Temperature
[1.59 mm (0.060 in.) below seating plane]
Absolute Maximum
70
30
50
5
110
-40 to +100
-40 to +100
260°C for 5 seconds
Units
mA
mA
mA
V
°C
°C
Notes:
1. See Figure 2 to establish pulsed operating conditions.
2. Derate linearly from 50°C at 0.5 mA/°C.
3. The transient peak current is the maximum non-recurring peak current that can be applied to the device without damaging
the LED die and wirebond. It is not recommended that this device be operated at peak currents above the Absolute Maximum
Peak Forward Current.
3
Optical/Electrical Characteristics at T
A
=25
°
C
Symbol
I
v
Device
Parameter
HLMP-
Luminous Intensity
C008-U0000
C208-S0000
C608-R0000
C025-P0000
C225-O0000
C625-P0000
Included Angle Between Half C008-U0000
Luminous Intensity Points
[1]
C208-S0000
C608-R0000
C025-P0000
C225-O0000
C625-P0000
Dominant Wavelength
[2]
C008-U0000
C208-S0000
C608-R0000
C025-P0000
C225-O0000
C625-P0000
Peak Wavelength
C008-U0000
C208-S0000
C608-R0000
C025-P0000
C225-O0000
C625-P0000
λ
1
/
2
τ
s
C
Rθ
J-PIN
V
F
Spectral Line Halfwidth
Speed of Response
Capacitance
Thermal Resistance
Forward Voltage
C008-U0000
C208-S0000
C608-R0000
C025-P0000
C225-O0000
C625-P0000
5.0
Min.
2900
2600
1000
500
450
500
Typ.
[3]
6000
3000
2000
1000
800
700
8
8
8
25
25
25
626
590
635
626
590
635
635
594
650
635
594
650
17
20
40
260
1.9
1.9
1.9
1.9
1.9
1.9
2.4
2.6
2.6
2.4
2.6
2.6
Max.
Units
mcd
Test
Conditions
I
F
=20 mA
2θ
1
/
2
Deg.
I
F
=20 mA
See Note 1
λ
d
nm
See Note 2
λ
PEAK
nm
Measurement
at Peak
at Peak
nm
ns
pF
°C/W
V
V
F
= 0;
f = 1 MHz
Junction to
Cathode Lead
I
F
= 20 mA
V
R
Reverse Breakdown Voltage
V
I
R
= 100
µA
Notes:
1.
θ
1
/
2
is the off-axis angle at which the luminous intensity is half of the axial luminous intensity.
2. The dominant wavelength,
λ
d
, is derived from the CIE chromaticity diagram and represents the single wavelength which defines the
color of the device.
3. Typical specification for reference only. Do not exceed absolute maximum ratings.
4
1.0
C208
C225
C008
C025
RELATIVE INTENSITY
C608
C625
0.5
0
550
600
WAVELENGTH – nm
650
700
Figure 1. Relative Intensity vs. Wavelength.
RATIO OF MAXIMUM TOLERABLE
PEAK CURRENT TO MAXIMUM
TOLERABLE DC CURRENT
6
5
4
CURRENT – mA
60
RELATIVE LUMINOUS INTENSITY
(NORMALIZED AT 20 mA)
3.0
2.5
2.0
1.5
1.0
0.5
0
50
40
RED
30
20
10
AMBER
3
300
100
100
z
1 KH
z
3 KH
Hz
10 K
Hz
30 K
2
Hz
Hz
KHz
I
PEAK
– MAX.
I
DC
– MAX.
1
1.0
10
100
1000
10,000
0
1.0
1.5
2.0
2.5
3.0
0
20
40
60
tp – PULSE DURATION – µs
V
F
– FORWARD VOLTAGE – V
I
F
– DC FORWARD CURRENT – mA
Figure 2. Maximum Tolerable Peak
Current vs. Pulse Duration.
Figure 3. Forward Current vs.
Forward Voltage.
Figure 4. Relative Luminous Intensity
vs. Forward Current.
1.0
0.9
RELATIVE INTENSITY
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-25
-20
-15
-10
-5
0
5
10
15
20
25
ANGULAR DISPLACEMENT – DEGREES
Figure 5. Relative Luminous Intensity vs. Angular Displacement
for HLMP-Cx08.
5
1.0
0.9
RELATIVE INTENSITY
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-90 -80 -70 -60 -50 -40 -30 -20 -10
0
10 20 30 40 50 60 70 80 90
ANGULAR DISPLACEMENT – DEGREES
Figure 6. Relative Luminous Intensity vs. Angular
Displacement for HLMP-Cx25.
Soldering/Cleaning
Cleaning agents from the ketone
family (acetone, methyl ethyl
ketone, etc.) and from the
chlorinated hydrocarbon family
(methylene chloride, trichloro-
ethylene, carbon tetrachloride,
etc.) are not recommended for
cleaning LED parts. All of these
various solvents attack or dissolve
the encapsulating epoxies used
to form the package of plastic
LED parts.
For information on soldering
LEDs please refer to Application
Note 1027.
