NJM2801U-5043-(TE2) datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> NJM2801U-5043-(TE2)

NJM2801U-5043-(TE2): DescriptionFixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, SOT-89, 5 PIN; CategoryPower/power management The power supply circuit; File Size139KB，4 Pages; ManufacturerNew Japan Radio Co., Ltd..; Environmental Compliance

Download Datasheet Parametric Compare View All

NJM2801U-5043-(TE2) Overview

Fixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, SOT-89, 5 PIN

NJM2801U-5043-(TE2) Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	New Japan Radio Co., Ltd..
Parts packaging code	SOT-89
package instruction	SOT-89, 5 PIN
Contacts	5
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum drop-back voltage 1	0.18 V
Maximum input voltage	11 V
Minimum input voltage	6 V
JESD-30 code	R-PDSO-F5
JESD-609 code	e6
length	4.5 mm
Number of functions	1
Number of terminals	5
Maximum output voltage 1	5.11 V
Minimum output voltage 1	4.89 V
Nominal output voltage 1	5 V
Package body material	PLASTIC/EPOXY
encapsulated code	SOF
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	1.8 mm
surface mount	YES
technology	BIPOLAR
Terminal surface	TIN BISMUTH
Terminal form	FLAT
Terminal pitch	1.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	2.5 mm

Preview

Download Datasheet

View All

NJM2801

PRELIMINARY

Low Dropout Voltage Regulator with Reset

■

GENERAL DISCRIPTION

The NJM2801 is a low dropout voltage regulator with

reset function.

It provides up to

150mA

of logic supply, and the reset

function monitors either input or output voltage of the

regulator with 2% accuracy.

It is suitable for local power supply and reset for small

micro controller and other logic chips.

■

PACKAGE OUTLINE

NJM2801F**

NJM2801U**

■

FEATURES

■

PIN CONFIGURATION

= ±2.2%

Vreset

= ±2.0%

10mS±2.5mS

=300µA(max.)

•

Output Voltage Accuracy

•

Reset Voltage Accuracy

•

Reset Hold Time

•

Quiescent Current

•

Open Collector Output

•

Bipolar Technology

•

Input Voltage Monitor type

•

Package Outline

•

Protection Circuit

( MTP-5 )

1.V

2.GND

3.V

4.C

5.V

OUT

( SOT-89 )

SOT89(5Pin)/MTP5

1.Current

limit circuit

2.Thermal overload protection circuit

1.V

OUT

2.GND

3.Cd

4.V

5.V

■

Output Voltage/Reset Validated Voltage

PART NO

NJM2801-5043

Output Voltage

5.0V

Reset Validated

Voltage

4.3V

■

Block Diaglam

Thermal

Protection

Bandgap

Reference

GND

NJM2801U-5043-(TE2) Related Products

	NJM2801U-5043-(TE2)	NJM2801F-5043-(TE2)	NJM2801F-5043-(TE1)	NJM2801U-5043-(TE1)
Description	Fixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, SOT-89, 5 PIN	Fixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, MTP-5	Fixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, MTP-5	Fixed Positive LDO Regulator, 5V, 0.18V Dropout, BIPolar, PDSO5, SOT-89, 5 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Maker	New Japan Radio Co., Ltd..	New Japan Radio Co., Ltd..	New Japan Radio Co., Ltd..	New Japan Radio Co., Ltd..
Parts packaging code	SOT-89	SOIC	SOIC	SOT-89
package instruction	SOT-89, 5 PIN	MTP-5	LSSOP,	SOT-89, 5 PIN
Contacts	5	5	5	5
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Maximum drop-back voltage 1	0.18 V	0.18 V	0.18 V	0.18 V
Maximum input voltage	11 V	11 V	11 V	11 V
Minimum input voltage	6 V	6 V	6 V	6 V
JESD-30 code	R-PDSO-F5	R-PDSO-G5	R-PDSO-G5	R-PDSO-F5
JESD-609 code	e6	e6	e6	e6
length	4.5 mm	2.9 mm	2.9 mm	4.5 mm
Number of functions	1	1	1	1
Number of terminals	5	5	5	5
Maximum output voltage 1	5.11 V	5.11 V	5.11 V	5.11 V
Minimum output voltage 1	4.89 V	4.89 V	4.89 V	4.89 V
Nominal output voltage 1	5 V	5 V	5 V	5 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOF	LSSOP	LSSOP	SOF
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260	260
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	1.8 mm	1.4 mm	1.4 mm	1.8 mm
surface mount	YES	YES	YES	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR
Terminal surface	TIN BISMUTH	TIN BISMUTH	Tin/Bismuth (Sn/Bi)	TIN BISMUTH
Terminal form	FLAT	GULL WING	GULL WING	FLAT
Terminal pitch	1.5 mm	0.95 mm	0.95 mm	1.5 mm
Terminal location	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
width	2.5 mm	1.6 mm	1.6 mm	2.5 mm
