Zener Diodes
MAZ4000N Series
(MA4000N Series)
Silicon planar type
Unit: mm
For stabilization of power supply
I
Features
•
Extremely low noise voltage caused from diode (1/3 to 1/10 of our
conventional MAZ4000 series)
•
Extremely good rising performance (in the low-current range)
•
Easy-to-identify the zener-voltage rank by the color bands
•
Easy-to-select the optimum diode because of their finely divided
zener-voltage ranks
•
Easy-to-mount through the adoption of the small glass-sealed DHD
package (DO-34)
13.0 min.
0.2 max.
Colored band
indicatesVz
classification
Cathode
1st Band
2nd Band
3rd Band
φ
1.6
±0.2
Anode
I
Absolute Maximum Ratings
T
a
=
25°C
Parameter
Average forward current
Repetitive peak forward current
Total power dissipation
*
Junction temperature
Storage temperature
Symbol
I
F(AV)
I
FRM
P
tot
T
j
T
stg
Rating
250
250
400
200
−65
to
+200
Unit
mA
mA
mW
°C
°C
Cathode on the first band (wide)
1: Cathode
2: Anode
DO-34-A1 Package
(Main body to be painted in light purple)
•
Color indication of V
Z
rank classification
L rank
Black
M rank
Blue
H rank
Red
Note) * : With a printed-circuit board
I
Common Electrical Characteristics
T
a
=
25°C
*1
Parameter
Forward voltage
Zener voltage
*2
Operating resistance
Symbol
V
F
V
Z
R
ZK
R
Z
Reverse current
Temperature coefficient of zener voltage
*3
I
R
S
Z
I
F
=
10 mA
I
Z ··················
Specified value
I
Z ··················
Specified value
I
Z ··················
Specified value
V
R ···············
Specified value
I
Z ··················
Specified value
Refer to the list of the
electrical characteristics
within part numbers
Conditions
Min
Typ
0.83
Max
0.9
Unit
V
V
Ω
Ω
µA
mV/°C
Note) 1．
Rated input/output frequency: 5 MHz
2． 1 : The V
Z
value is for the temperature of 25°C. In other cases, carry out the temperature compensation.
*
*2 : Guaranteed at 20 ms after power application.
* 3 : T
j
=
25°C to 150°C
Note) The part numbers in parenthesis show conventional part number.
Publication date: September 2001
SKE00005BED
φ
0.40
±0.05
2.3
±0.3
2.2
±0.3
13.0 min.
1
MAZ4000N Series
I
Electrical characteristics within part numbers (continued)
T
a
=
25°C
Zener voltage
Part Number
Min
13.84
13.84
14.34
14.86
15.38
15.38
15.86
16.36
16.94
16.94
17.56
18.21
18.88
18.88
19.53
20.22
20.89
20.89
21.56
22.25
22.93
22.93
23.76
24.56
25.20
25.20
26.19
27.21
28.22
28.22
29.19
30.20
31.18
31.18
32.15
33.13
34.12
34.12
35.07
36.07
37.04
37.04
38.00
38.99
V
Z
(V)
I
Z
=
5 mA
Nom
14.68
14.15
14.66
15.19
16.23
15.69
16.18
16.72
17.98
17.32
17.96
18.62
19.98
19.28
19.95
20.65
22.02
21.33
22.01
22.70
24.25
23.45
24.27
25.07
26.91
25.85
26.86
27.91
29.98
28.94
29.94
30.97
33.01
31.98
32.97
33.98
36.02
34.99
35.97
36.99
39.02
37.99
38.97
39.99
Reverse current
I
R
(µA)
Max
Operating resistance
R
Z
R
ZK
(Ω)
I
Z
(Ω)
Max (mA) Max
Temperature
coefficient of
zener voltage
MAZ4150N
MAZ4150(N)-L
MAZ4150(N)-M
MAZ4150(N)-H
MAZ4160(N)
MAZ4160(N)-L
MAZ4160(N)-M
MAZ4160(N)-H
MAZ4180(N)
MAZ4180(N)-L
MAZ4180(N)-M
MAZ4180(N)-H
MAZ4200(N)
MAZ4200(N)-L
MAZ4200(N)-M
MAZ4200(N)-H
MAZ4220(N)
MAZ4220(N)-L
MAZ4220(N)-M
MAZ4220(N)-H
MAZ4240(N)
MAZ4240(N)-L
MAZ4240(N)-M
MAZ4240(N)-H
MAZ4270(N)
MAZ4270(N)-L
MAZ4270(N)-M
MAZ4270(N)-H
MAZ4300(N)
MAZ4300(N)-L
MAZ4300(N)-M
MAZ4300(N)-H
MAZ4330(N)
MAZ4330(N)-L
MAZ4330(N)-M
MAZ4330(N)-H
MAZ4360(N)
MAZ4360(N)-L
MAZ4360(N)-M
MAZ4360(N)-H
MAZ4390(N)
MAZ4390(N)-L
MAZ4390(N)-M
MAZ4390(N)-H
Max
15.51
14.46
14.98
15.51
17.08
16.00
16.50
17.08
19.02
17.70
18.35
19.02
21.08
19.68
20.37
21.08
23.15
21.76
22.45
23.15
25.57
23.96
24.78
25.57
28.61
26.50
27.53
28.61
31.74
29.66
30.69
31.74
34.83
32.78
33.79
34.83
37.91
35.86
36.87
37.91
40.99
38.94
39.94
40.99
V
R
(V)
S
Z
I
Z
(mV/°C) I
Z
(mA) Typ (mA) 1st.
Marking
Color indication
Main body:
light purple
2nd.
3rd.
0.05
11.0
40
5
80
0.5
11.4
5
Brown Green
0.05
12.0
50
5
80
0.5
12.4
5
Brown Blue
0.05
13.0
60
5
80
0.5
14.4
5
Brown Gray
0.05
15.0
80
5
100
0.5
16.4
5
Red Black
0.05
17.0
80
5
100
0.5
18.4
5
Red
Red
0.05
19.0
100
5
120
0.5
20.4
5
Red Yellow
0.05
21.0
120
5
120
0.5
23.4
5
Red Purple
0.05
23.0
160
5
160
0.5
26.6
5
Orange Black
0.05
25.0
200
5
200
0.5
29.7
5
Orange Orange
0.05
27.0
250
5
250
0.5
33.0
5
Orange Blue
0.05
30.0
300
5
300
0.5
35.6
5
Orange White
Note) 1. The V
Z
value is the one after power application for 20 ms at T
a
=
25°C.
2. The zener voltage temperature coefficient is the one for T
j
=
25°C to 150°C.
SKE00005BED
