MAX5460EXK-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> MAX5460EXK-T

MAX5460EXK-T: Description100K DIGITAL POTENTIOMETER, INCREMENT/DECREMENT CONTROL INTERFACE, 32 POSITIONS, PDSO5, EIAJ, SC-70, 5 PIN; CategoryAnalog mixed-signal IC converter; File Size921KB，11 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

MAX5460EXK-T Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MAX5460EXK-T	-	-	View	Buy Now

MAX5460EXK-T Overview

100K DIGITAL POTENTIOMETER, INCREMENT/DECREMENT CONTROL INTERFACE, 32 POSITIONS, PDSO5, EIAJ, SC-70, 5 PIN

MAX5460EXK-T Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	EIAJ, SC-70, 5 PIN
Contacts	5
Reach Compliance Code	unknown
control interface	INCREMENT/DECREMENT
Converter type	DIGITAL POTENTIOMETER
JESD-30 code	R-PDSO-G5
JESD-609 code	e0
length	2 mm
Humidity sensitivity level	1
Number of functions	1
Number of positions	32
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	245
Certification status	COMMERCIAL
resistance law	LINEAR
Maximum resistor terminal voltage	2.7 V
Minimum resistor terminal voltage
Maximum seat height	1.1 mm
Nominal supply voltage	2.7 V
surface mount	YES
Nominal temperature coefficient	35 ppm/°C
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal total resistance	100000 Ω
width	1.25 mm
