Datasheet> All Categories > Passive components> The resistor> 8-1625865-8
PDF
Preview

8-1625865-8

Description
RESISTOR, THIN FILM, 0.125W, 0.1%, 15ppm, 9.09ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size137KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

8-1625865-8 Online Shopping

Suppliers Part Number Price MOQ In stock
8-1625865-8 - - View Buy Now

8-1625865-8 Overview

RESISTOR, THIN FILM, 0.125W, 0.1%, 15ppm, 9.09ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT

8-1625865-8 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1289599825
package instructionCHIP, ROHS COMPLIANT
Reach Compliance Codecompliant
Samacsys DescriptionRP 2A 9R09 0.1% 15PPM CUT LENGTH
Samacsys ManufacturerTE Connectivity
Samacsys Modified On2020-10-06 12:14:54
YTEOL8
Other featuresPRECISION
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
method of packingTAPE
physical size2mm x 1.25mm x .55mm
Rated power dissipation(P)0.125 W
Rated temperature70 °C
resistance9.09 Ω
Resistor typeFIXED RESISTOR
size code0805
surface mountYES
technologyTHIN FILM
Temperature Coefficient15 ppm/°C
Terminal shapeWRAPAROUND
Tolerance0.1%
Operating Voltage150 V

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Resistors > Product Feature Selector > Product Details
RP73D2A9R09BTG Product Details
Fixed Resistors

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Fixed Resistor
Resistor Type = Precision Resistor
Resistance Selection = <1K Ω
Resistance = 9.09 Ω
Power Rating = .125 W
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
RP73D2A9R09BTG
(8­1625865­8)
TE Internal Number: 8­1625865­8
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Fixed Resistor
Resistor Type = Precision Resistor
Element = Thin Film
Electrical Characteristics:
Resistance Selection (Ω) = <1K
Resistance (Ω) = 9.09
Power Rating (W) = 0.125
Tolerance (%) = 0.1
Termination Features:
Termination Type = Solder
Body Features:
Mount Style = Surface Mount
Packaging Style = 0805
Package, Component Size = 2.1 x 1.3
Configuration Features:
Number of Terminations = 2
Number of Resistors = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Reflow solder capable to 245°C,
Reflow solder capable to 260°C
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Coefficient (ppm/°C) = ±15
Operation/Application:
Application = Precision
Packaging Features:
Package Type = Cut Tape Length
Other:
Series = RP73
Brand = Holsworthy
