Part Number

Search

PFC-A1206-01-50R0-2D00

Description
Fixed Attenuator, 0MHz Min, 6000MHz Max, CERAMIC PACKAGE-3
CategoryWireless rf/communication    Radio frequency and microwave
File Size312KB,2 Pages
ManufacturerTT Electronics plc
Websitehttp://www.ttelectronics.com/
Download Datasheet Parametric View All

PFC-A1206-01-50R0-2D00 Overview

Fixed Attenuator, 0MHz Min, 6000MHz Max, CERAMIC PACKAGE-3

PFC-A1206-01-50R0-2D00 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerTT Electronics plc
Reach Compliance Codeunknown
Nominal attenuation2 dB
Characteristic impedance50 Ω
structureCOMPONENT
Maximum input power (CW)20.97 dBm
JESD-609 codee0
Maximum operating frequency6000 MHz
Minimum operating frequency
RF/Microwave Device TypesFIXED ATTENUATOR
Terminal surfaceTin/Lead (Sn/Pb)
Thin Film Surface Mount
Attenuators
PFC A1206 Attenuator Series
RoHS compliant and Sn/Pb terminations available
Ultra-reliable TaNFilm
®
element
Available in 50Ω and 75Ω impedances
Excellent high frequency characteristics
The PFC A1206 chip attenuator is a surface mount attenuator available
in nominal values of 50Ω and 75Ω to meet the needs of both communication
and video designs. Packaged in a rugged 1206 ceramic chip package, the PFC-A1206 lends itself to RF and
microwave applications up to 6GHz.
The tantalum nitride thin film element is well known for its ruggedness in the most severe outdoor environments
and its stability over temperature and time. For your most demanding environmental attenuator applications,
specify the IRC PFC-A1206 chip attenuator.
Electrical Data
Attenuation Impedance
1dB
2dB
3dB
4dB
5dB
6dB
7dB
8dB
9dB
10dB
20dB
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
50Ω, 75Ω
Tolerance*
±0.3dB
±0.3dB
±0.3dB
±0.5dB
±0.5dB
±1.0B
±1.0dB
±1.0dB
±1.0dB
±1.0dB
±2.0dB
±100
125mW
TCR
(ppm/°C)
Power
@70°C
Environmental Data
Performance
Test Per MIL-PRF-55342
Typical
Thermal Shock
Low Temperature Operation
Short-time Overload
High Temperature Exposure
Effects of Solder
Moisture Resistance
Life
Max
±0.02% ±0.10%
±0.01% ±0.05%
±0.01% ±0.05%
±0.03% ±0.10%
±0.01% ±0.10%
±0.03% ±0.10%
±0.03% ±0.10%
Note*: Typical from 0 to 6GHz.
General Note
IRC reserves the right to make changes in product specification without notice or liability.
All information is subject to IRC’s own data and is considered accurate at time of going to print.
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
A subsidiary of
TT electronics plc
PFC A1206 Series Issue February 2009 Sheet 1 of 2
