KSR1001
NPN EPITAXIAL SILICON TRANSISTOR
SWITCHING APPLICATION
(Bias Resistor Built In)
•
Switching circuit, Inverter, Interface circuit, Driver Circuit
•
Built in bias Resistor (R
1
=4.7KΩ, R
2
=4.7KΩ)
•
Complement to KSR2001
TO-92
ABSOLUTE MAXIMUM RATINGS (T
A
=25°C)
°
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Rating
50
50
10
100
300
150
-55 ~ 150
Unit
V
V
V
mA
mW
°C
°C
1. Emitter 2. Collector 3. Base
ELECTRICAL CHARACTERISTICS (T
A
=25°C)
°
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Collector Cut-off Current
DC Current Gain
Collector-Emitter Saturation Voltage
Current Gain-Bandwidth Product
Output Capacitance
Input Off Voltage
Input On Voltage
Input Resistor
Resistor Ratio
Symbol
BV
CBO
BV
CEO
I
CBO
h
FE
V
CE
(sat)
f
T
C
OB
V
I
(off)
V
I
(on)
R
1
R
1
/R
2
Test Conditions
I
C
=10µA, I
E
=0
I
C
=100µA, I
B
=0
V
CB
=40V, I
E
=0
V
CE
=5V, I
C
=10mA
I
C
=10mA, I
B
=0.5mA
V
CE
=5mA, I
C
=10V
V
CB
=10V, I
E
=0
f=1.0MHz
V
CE
=5V, I
C
=100µΑ
V
CE
=0.3V, I
C
=20mA
Min
50
50
0.1
20
0.3
250
3.7
0.5
3.2
0.9
4.7
1
3
6.2
1.1
V
MHz
pF
V
V
KΩ
Typ
Max
Unit
V
V
µA
EQUIVALENT CIRCUIT
Collector
Base
Emitter
Rev. B
©
1999 Fairchild Semiconductor Corporation
