P10SG-xxxxE/Z(Hxx)LF
PM5-SERIES
Rev.11-2008
2 Watt
Regulated
DIP24 Plastic
Case
1 - 6 kV
DC I/O Isolation
Single
and
Dual
Output
Continuous Short Circuit Prot.
Full SMD Technology
Input Specifications
Voltage Range
Input Filter
Input Reflected Ripple Current¹
Output Specifications
Voltage Accuracy
Short Circuit Protection
Line Regulation
Load Regulation
(0% - 100%)
Ripple and Noise
(20Mhz bandwidth)
Temperature Coefficient
General Specifications
Efficiency
I/O Isolation Voltage
(3 sec.)
I/O Isolation Capacity
I/O Isolation Resistance
Switching Frequency
(typical)
Humidity
Reliability Calculated MTBF
(MIL-HDBK-217F)
Physical Specifications
Case Material
Potting Material
Weight
Environment Specifications
Operating Temperature
Maximum Case Temperature
Storage Temperature
Cooling
RoHS Conform
Mainzer Straße 151–153
D-55299 Nackenheim
Tel. +49 6135 7026-0
Fax: +49 6135 931070
www.peak-electronics.de
peak@peak-electronics.de
The PM5 series P10SG-xxxxE/Z(Hxx)LF is a family of cost effective 2 W
single and dual output DC/DC converters. These converters are
encapsulated in an ultra miniature DIP24 case. High performance features:
1000VDC, optional up to 6000VDC input/output isolation, high efficiency
operation, output voltage accuracy of ±2% maximum, input range of ±10%
tolerance and low output ripple and noise.
All specifications typical at Ta=25° nominal input voltage and full load unless otherwise specified
C,
± 10%
Pi Type
35 mA pk-pk
± 2%
Indefinite
(automatic recovery)
± 0.5%
± 0.5% (3.3Vout Models: ± 1.5%)
75 mV pk-pk
± 0.02% / °
C
See Table
1000 VDC
(up to 6000 VDC optional)*
60 pF, typ.
1000 M Ohm
40 kHz
(Single out);
300 kHz
(Dual out)
95% rel H
> 3.072 Mhrs
Non Conductive Black Plastic
(UL94V-0 rated)
Epoxy
(UL94V-0 rated)
~ 12.5g, typ.
-40 to +85°
(ambient)
C
100°
C
-40 to +125°
C
Free Air Convection
Soldering 260° max.
(1.5mm from case 10s.)
C,
PM5-Series – P10SG-xxxxE/Z(Hxx)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 1/3
Selection Guide
Single/Dual
Output
A)
)
A)
d (m
(mA ad (m
a
²
ad
C)
)
o
ll Lo
uF)
(VD
o Lo t Full L
VDC
t Fu
(
n
)
ad (
tN
ge
e
o
urre
olta
rren
y (%
rren
ltag
or L
ut C
ut V
ienc
t Vo
t Cu put Cu
acit
p
p
Inpu
Inpu
In
Out
Out
Effic
Cap
Order #
SINGLE OUTPUT
P10SG-053R3ELF
P10SG-0505ELF
P10SG-0509ELF
P10SG-0512ELF
P10SG-0515ELF
P10SG-0524ELF
P10SG-123R3ELF
P10SG-1205ELF
P10SG-1209ELF
P10SG-1212ELF
P10SG-1215ELF
P10SG-1224ELF
P10SG-243R3ELF
P10SG-2405ELF
P10SG-2409ELF
P10SG-2412ELF
P10SG-2415ELF
P10SG-2424ELF
DUAL OUTPUT
P10SG-053R3ZLF
P10SG-0505ZLF
P10SG-0509ZLF
P10SG-0512ZLF
P10SG-0515ZLF
P10SG-0524ZLF
P10SG-123R3ZLF
P10SG-1205ZLF
P10SG-1209ZLF
P10SG-1212ZLF
P10SG-1215ZLF
P10SG-1224ZLF
P10SG-243R3ZLF
P10SG-2405ZLF
P10SG-2409ZLF
P10SG-2412ZLF
P10SG-2415ZLF
P10SG-2424ZLF
5
5
5
5
5
5
12
12
12
12
12
12
24
24
24
24
24
24
5
5
5
5
5
5
12
12
12
12
12
12
24
24
24
24
24
24
75
75
75
75
75
75
70
70
70
70
70
70
25
25
25
25
25
25
30
30
40
40
40
50
20
20
20
20
35
35
15
15
15
15
20
20
622
615
597
571
588
615
245
260
245
238
252
256
120
132
132
122
122
122
638
588
571
571
571
579
250
228
222
213
216
219
121
114
111
104
108
111
3.3
5
9
12
15
24
3.3
5
9
12
15
24
3.3
5
9
12
15
24
± 3.3
±5
±9
± 12
± 15
24
± 3.3
±5
±9
± 12
± 15
± 24
± 3.3
±5
±9
± 12
± 15
± 24
500
400
222
166
133
83.3
500
400
222
166
133
83.3
500
400
222
166
133
83.3
± 300
± 200
± 111
± 83
± 67
42
± 300
± 200
± 111
± 83
± 67
± 42
± 300
± 200
± 111
± 83
± 67
± 42
53
65
67
70
68
65
56
64
68
70
66
65
57
63
63
68
68
68
62
68
70
70
70
69
66
73
75
78
77
76
68
73
75
80
77
75
330
330
330
330
330
330
330
330
330
330
330
330
330
330
330
330
330
330
± 1000
± 1000
± 470
± 470
± 470
220
± 1000
± 1000
± 470
± 470
± 470
± 220
± 1000
± 1000
± 470
± 470
± 470
± 220
If you need other specifications, please enquire.
*OPTIONS:
H30 = 3000 VDC ISOLATION
H40 = 4000 VDC ISOLATION
H52 = 5200 VDC ISOLATION
H60 = 6000 VDC ISOLATION
For other I/O Isolation please see
table on the left hand side and add
“Hxx” before LF
(P10SG-2412EH60LF for
6KV)
PM5-Series – P10SG-xxxxE/Z(Hxx)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 2/3
Package / Pinning / Derating
20.32
(0.80)
15.24
(0.60)
PIN CONNECTIONS
# SINGLE
DUAL SINGLE
≥3KV
1 +Vin
+Vin
+Vin
2 N.C.
- Vout
+Vin
3 N.C.
Common Omitted
10 - Vout
Common Omitted
11 +Vout
+Vout
Omitted
12 - Vin
- Vin
- Vout
13 - Vin
- Vin
+Vout
14 +Vout
+Vout
Omitted
15 - Vout
Common Omitted
22 N.C.
Common Omitted
23 N.C.
- Vout
- Vin
24 +Vin
+Vin
- Vin
0.25
(0.01)
DUAL
≥3KV
+Vin
+Vin
Omitted
Common
Common
Omitted
- Vout
Omitted
+ Vout
Omitted
- Vin
- Vin
App Notes:
¹ =
Measured Input reflected ripple current with a simulated source inductance of 12uH.
² =
Tested by minimal Vin and constant resistive load.
PM5-Series – P10SG-xxxxE/Z(Hxx)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 3/3
PCB Design
