2RI60G-120: DescriptionRectifier Diode, 1 Phase, 2 Element, 60A, 1200V V(RRM), Silicon, R204, 3 PIN; CategoryDiscrete semiconductor diode; File Size126KB，2 Pages; ManufacturerFuji Electric Co., Ltd.

Download Datasheet Parametric View All

2RI60G-120 Overview

Rectifier Diode, 1 Phase, 2 Element, 60A, 1200V V(RRM), Silicon, R204, 3 PIN

2RI60G-120 Parametric

Parameter Name	Attribute value
package instruction	R-XUFM-X3
Reach Compliance Code	unknow
ECCN code	EAR99
application	POWER
Shell connection	ISOLATED
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V
JESD-30 code	R-XUFM-X3
Maximum non-repetitive peak forward current	1200 A
Number of components	2
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	60 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1200 V
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER
Base Number Matches	1

Preview

Download Datasheet

View All

2RI60G

(2x60A)

1200V,1600V / 60A

2 in one-package

Features

· Glass Passivation Chip

· Easy Connection

· Insulated Type

POWER DIODE MODULE

Outline Drawings, mm

Applications

· Inverters

· Battery Chargers

· DC Motors

· General Purpose DC Power Supplies

Inner Curcuit Schematic

1

~

+

2

-

3

Maximum ratings and characteristics

Absolute maximum ratings

Item

Repetitive peak reverse voltage

Non-repetitive peak reverse voltage

Average output current

Surge current

I

2

t

Operating junction temperature

Storage temperature

Isolation voltage

Screw torque

*1: Recommendable value : 2.5 to 3.0 N·m(M5)

Electrical characteristics (Ta=25°C Unless otherwise specified )

Item

Forward voltage drop

Reverse current

Thermal Characteristics

Item

Thermal resistance

Symbol

R

th(j-c)

R

th(c-f)

Conditions

Junction to case

the base to cooling fin *

Min.

Typ.

Max.

0.25

0.10

Unit

°C/W

Symbol

V

FM

I

RRM

Conditions

Tj=25°C, I

FM

=190A

Tj=150°C, V

R

=V

RRM

Min.

Typ.

Max.

1.40

20

Unit

V

mA

Symbol

V

RRM

V

RSM

I

O

I

FSM

I

2

t

T

j

T

stg

V

is

50/60Hz Sine wave, Tc=110°C

From rated load, Sine wave 10ms

From rated load

Conditions

Rating

-120

-160

1200

1320

1600

1760

2 x 60

1200

6000

-40 to +150

-40 to +125

AC2500(1min.)

3.5

*1

Unit

V

A

2

s

°C

V

N·m

*

: With Thermal Compound
