CSB507E

Description
Power Bipolar Transistor, 3A I(C), 60V V(BR)CEO, 1-Element, PNP, Silicon, TO-220AB, Plastic/Epoxy, 3 Pin, TO-220, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size122KB，3 Pages
ManufacturerCDIL[Continental Device India Pvt. Ltd.]
Environmental Compliance
Download Datasheet Parametric Compare View All

CSB507E Overview

Power Bipolar Transistor, 3A I(C), 60V V(BR)CEO, 1-Element, PNP, Silicon, TO-220AB, Plastic/Epoxy, 3 Pin, TO-220, 3 PIN

CSB507E Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?conform to
MakerCDIL[Continental Device India Pvt. Ltd.]
Parts packaging codeSFM
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Shell connectionCOLLECTOR
Maximum collector current (IC)3 A
Collector-emitter maximum voltage60 V
ConfigurationSINGLE
Minimum DC current gain (hFE)100
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typePNP
Maximum power dissipation(Abs)30 W
Certification statusNot Qualified
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Nominal transition frequency (fT)8 MHz

Preview

Download Datasheet
Continental Device India Limited
An ISO/TS16949 and ISO 9001 Certified Company
TO-220 Plastic Package
CSB507, CSD313
CSB507
CSD313
PNP PLASTIC POWER TRANSISTOR
NPN PLASTIC POWER TRANSISTOR
Low frequency Power Amplifier Applications
PIN CONFIGURATION
1. BASE
2. COLLECTOR
3. EMITTER
4. COLLECTOR
4
1
2
3
B
H
F
C
E
DIM
A
B
C
D
E
F
G
H
J
K
L
M
N
O
M IN.
14.42
9.63
3.56
M A X.
N
L
O
1 2 3
D
G
J
M
16.51
10.67
4.83
0.90
1.15
1.40
3.75
3.88
2.29
2.79
2.54
3.43
0.56
12.70 14.73
2.80
4.07
2.03
2.92
31.24
DE G 7
A
O
ABSOLUTE MAXIMUM RATINGS
Collector-base voltage (open emitter)
Collector-emitter voltage (open base)
Collector current
Total power dissipation up to T
C
= 25°C
Junction temperature
Collector-emitter saturation voltage
I
C
= 2A; I
B
= 0.2A
D.C. current gain
I
C
= 1A; V
CE
= 2V
RATINGS
(at T
A
=25°C unless otherwise specified)
Limiting values
Collector-base voltage (open emitter)
Collector-emitter voltage (open base)
Emitter-base voltage (open collector)
All dim insions in m m .
K
V
CBO
V
CEO
I
C
P
tot
T
j
V
CEsat
h
FE
max.
max.
max.
max.
max.
max.
min
max.
60
60
3.0
30
150
V
V
A
W
°C
1.0 V
40
320
V
CBO
V
CEO
V
EBO
max.
max.
max.
60 V
60 V
5.0 V
Continental Device India Limited
Data Sheet
Page 1 of 3
