2SA1020
ELECTRICAL CHARACTERISTICS
(TA=25 C unless otherwise noted) (Countinued)
Characteristics
Symbol
Min
Typ
Max
Unit
ON CHARACTERISTICS
DC Current Gain
(IC=-500 mAdc, VCE=-2.0 Vdc)
(IC=-1500 mAdc, VCE=-2.0 Vdc)
Collector-Emitter Saturation Voltage
(IC=-1000 mAdc, IB=-50mAdc)
Base-Emitter Saturation Voltage
(IC=-1000 mAdc, IB=-50mAdc)
Current-Gain-Bandwidth Product
(IC=-500 mAdc, VCE=-2 Vdc)
Collector Output Capacitance
V
CB
=-10V, I
E
=0, f= 1MHZ
hFE
(1)
hFE
(2)
VCE(sat)
VBE(sat)
70
40
-
-
-
-
-
-
240
-
-0.5
-1.2
-
-
Vdc
Vdc
fT
Cob
100
-
-
-
-
-
-40
0.1
1.0
0.1
-
MHz
PF
-
-
-
-
Switching Time
20us
I B2
- I B1 = I B2=0.05A
I B1
INPUT
I B2
I B1
OUTPUT
30Ω
Turn-on time
Storage time
Fall time
ton
t stg
tf
us
DUTY CYCLE
1%
VCC =-30V
CLASSIFICATION OF hFE
Rank
Range
O
70-140
Y
120-240
