Datasheet> All Categories > Discrete semiconductor> The transistor> ASAT20

Preview

ASAT20: DescriptionRF Power Bipolar Transistor, 1-Element, L Band, Silicon, NPN, 0.250 INCH, FM-2; CategoryDiscrete semiconductor The transistor; File Size105KB，2 Pages; ManufacturerAdvanced Semiconductor, Inc.

Download Datasheet Parametric View All

ASAT20 Overview

RF Power Bipolar Transistor, 1-Element, L Band, Silicon, NPN, 0.250 INCH, FM-2

ASAT20 Parametric

Parameter Name	Attribute value
Maker	Advanced Semiconductor, Inc.
package instruction	FLANGE MOUNT, R-CDFM-F2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum collector current (IC)	3.2 A
Collector-based maximum capacity	20 pF
Collector-emitter maximum voltage	28 V
Configuration	SINGLE
Minimum DC current gain (hFE)	15
highest frequency band	L BAND
JESD-30 code	R-CDFM-F2
Number of components	1
Number of terminals	2
Maximum operating temperature	200 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Polarity/channel type	NPN
Maximum power dissipation(Abs)	37.2 W
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	DUAL
transistor applications	AMPLIFIER
Transistor component materials	SILICON

Preview

Download Datasheet

View All

ASAT20

NPN SILICON RF POWER TRANSISTOR

DESCRIPTION:

The

ASI ASAT20

is Designed for

Genral Purpose Class C Operation up

to 1.7 GHz.

PACKAGE STYLE .250 2L FLG(A)

.020 x 45°

A

Ø .130 NOM.

.050 x 45°

FEATURES:

•

Internal Input Matching Network

•

P

G

= 8.0 dB at 20 W/1.7 GHz

•

Omnigold™

Metalization System /

Nitride Passivation

•

Common Base Class C

DIM

D C

L

B

M

F

E

G

H

I

J

K

MINIMUM

inches / mm

MAXIMUM

inches / mm

MAXIMUM RATINGS

I

C

V

CBO

V

CEO

V

EBO

P

DISS

T

J

T

STG

θ

JC

3.2 A

50 V

28 V

3.5 V

40 W @ T

C

= 25 °C

-65 °C to +200 °C

-65 °C to +150 °C

4.0 °C/W

A

B

C

D

E

F

G

H

I

J

K

L

M

.055 / 1.40

.124 / 3.15

.243 / 6.17

.635 / 16.13

.555 / 14.10

.739 / 18.77

.315 / 8.00

.002 / 0.05

.055 / 1.40

.075 / 1.91

.065 / 1.65

.253 / 6.43

.665 / 16.89

.565 / 14.35

.749 / 19.02

.325 / 8.26

.006 / 0.15

.065 / 1.65

.095 / 2.41

.190 / 4.83

.245 / 6.22

.092 / 2.34

.255 / 6.48

ORDER CODE: ASI10519

CHARACTERISTICS

SYMBOL

BV

CBO

BV

CEO

BV

EBO

h

FE

C

OB

P

G

η

C

T

C

= 25 °C

NONETEST

CONDITIONS

I

C

= 5.0 mA

I

C

= 5.0 mA

I

E

= 5.0 mA

V

CE

= 5.0 V

V

CB

= 28 V

V

CE

= 28 V

I

C

= 3.2 A

P

OUT

= 20 W

I

C

= 800 mA

f = 1.0 MHz

f = 1.40 GHz

MINIMUM TYPICAL MAXIMUM

45

12

3.0

10

24

7.6

8.0

8.2

50

100

UNITS

V

---

pF

dB

%

A D V A N C E D S E M I C O N D U C T O R, I N C.

7525 ETHEL AVENUE

•

NORTH HOLLYWOOD, CA 91605

•

(818) 982-1200

•

FAX (818) 765-3004

Specifications are subject to change without notice.

REV. C

1/3
