DG403DY

Description
SPDT, 2 Func, 1 Channel, CMOS, PDSO16, PLASTIC, MS-012AC, SOIC-16
CategoryAnalog mixed-signal IC    The signal circuit
File Size1000KB,11 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Related ProductsFound12parts with similar functions to DG403DY
Download Datasheet Parametric View All

DG403DY Online Shopping

Suppliers Part Number Price MOQ In stock
DG403DY - - View Buy Now

DG403DY Overview

SPDT, 2 Func, 1 Channel, CMOS, PDSO16, PLASTIC, MS-012AC, SOIC-16

DG403DY Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
MakerRochester Electronics
Parts packaging codeSOIC
package instructionSOP,
Contacts16
Reach Compliance Codeunknown
Other featuresIT CAN ALSO OPERATE FROM 5V TO 34V SINGLE SUPPLY
Analog Integrated Circuits - Other TypesSPDT
JESD-30 codeR-PDSO-G16
JESD-609 codee0
length9.9 mm
Maximum negative supply voltage (Vsup)-20 V
Negative supply voltage minimum (Vsup)-5 V
Nominal Negative Supply Voltage (Vsup)-15 V
Number of channels1
Number of functions2
Number of terminals16
Nominal off-state isolation72 dB
On-state resistance matching specifications3 Ω
Maximum on-state resistance (Ron)45 Ω
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum seat height1.75 mm
Maximum supply voltage (Vsup)20 V
Minimum supply voltage (Vsup)5 V
Nominal supply voltage (Vsup)15 V
surface mountYES
Maximum disconnect time100 ns
Maximum connection time150 ns
technologyCMOS
Temperature levelINDUSTRIAL
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width3.9 mm
