2SA1160
TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)
2SA1160
Strobe Flash Applications
Medium Power Amplifier Applications
•
High DC current gain and excellent h
FE
linearity
: h
FE (1)
= 140 to 600 (V
CE
=
−1
V, I
C
=
−0.5
A)
: h
FE (2)
= 60 (min), 120 (typ.) (V
CE
=
−1
V, I
C
=
−4
A)
•
Low saturation voltage
: V
CE (sat)
=
−0.5
V (max) (I
C
=
−2
A, I
B
=
−50
mA)
Unit: mm
Maximum Ratings
(Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
DC
Pulsed (Note 1)
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
j
T
stg
Rating
−20
−10
−6
−2
−4
−2
900
150
−55
to 150
Unit
V
V
V
A
A
mW
°C
°C
JEDEC
JEITA
TOSHIBA
TO-92MOD
―
2-5J1A
Weight: 0.36 g (typ.)
Note 1: Pulse width
=
10 ms (max), duty cycle
=
30% (max)
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
DC current gain
Collector-emitter saturation voltage
Base-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
Symbol
I
CBO
I
EBO
V
(BR) CEO
V
(BR) EBO
Test Condition
V
CB
= −20
V, I
E
=
0
V
EB
= −6
V, I
C
=
0
I
C
= −10
mA, I
B
=
0
I
E
= −1
mA, I
C
=
0
Min
⎯
⎯
−10
−6
140
60
⎯
⎯
⎯
⎯
Typ.
⎯
⎯
⎯
⎯
⎯
120
−0.20
−0.83
140
50
Max
−100
−100
⎯
⎯
600
⎯
−0.50
−1.5
⎯
⎯
V
V
MHz
pF
Unit
nA
nA
V
V
h
FE (1)
V
CE
= −1
V, I
C
= −0.5
A
(Note 2)
h
FE (2)
V
CE (sat)
V
BE
f
T
C
ob
V
CE
= −1
V, I
C
= −4
A
I
C
= −2
A, I
B
= −50
mA
V
CE
= −1
V, I
C
= −2
A
V
CE
= −1
V, I
C
= −0.5
A
V
CB
= −10
V, I
E
=
0, f
=
1 MHz
Note 2: h
FE (1)
Classification
A: 140 to 280, B: 200 to 400, C: 300 to 600
1
2004-07-07
2SA1160
