DATA SHEET
SILICON TRANSISTOR
2SA812
PNP SILICON EPITAXIAL TRANSISTOR
MINI MOLD
FEATURES
•
Complementary to 2SC1623
•
High DC Current Gain: h
FE
= 200 TYP. (V
CE
=
−6.0
V, I
C
=
−1.0
mA)
•
High Voltage: V
CEO
=
−50
V
<R>
PACKAGE DRAWING (Unit: mm)
2.8 ± 0.2
0.4
+0.1
–0.05
1.5 TYP.
0.65
–0.15
+0.1
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current (DC)
Total Power Dissipation
Junction Temperature
Storage Temperature Range
V
CBO
−60
V
V
CEO
−50
V
V
EBO
−5.0
V
I
C
−100
mA
P
T
200
mW
T
j
150
°C
T
stg
−55
to +150
°C
2.9 ± 0.2
0.95
TYP.
0.95
TYP.
2
3
1
0.3
TYP.
Marking
1.1 to 1.4
1. Emitter
2. Base
3. Collector
ELECTRICAL CHARACTERISTICS (T
A
= 25°C)
CHARACTERISTIC
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Collector Saturation Voltage
Base to Emitter Voltage
Gain Bandwidth Product
SYMBOL
I
CBO
I
EBO
h
FE
V
CE(sat)
V
BE
f
T
C
ob
−0.58
90
200
−0.18
−0.62
180
4.5
MIN.
TYP.
MAX.
−0.1
−0.1
600
−0.3
−0.68
V
V
MHz
pF
UNIT
TEST CONDITIONS
V
CB
=
−60
V, I
E
= 0 A
V
EB
=
−5.0
V, I
C
= 0 A
V
CE
=
−6.0
V, I
C
=
−1.0
mA
I
C
=
−100
mA, I
B
=
−10
mA
V
CE
= 6.0 V, I
C
=
−1.0
mA
V
CE
=
−6.0
V, I
E
= 10 mA
V
CB
=
−10
V, I
E
= 0 A, f = 1.0 MHz
Note
μ
A
μ
A
<R>
Output Capacitance
Note
Pulsed: PW
≤
350
μ
s, Duty Cycle
≤
2%
h
FE
CLASSIFICATION
Marking
h
FE
M4
90 to 180
M5
135 to 270
M6
200 to 400
M7
300 to 600
