Toroidal Inductors
Medium Current
CTP4553
CTP4553 is a medium current inductor with the following data and features:
0.68” o.d., Moly-Permalloy
Powder, perm 60.
•
Power rating:
0.86 watts for temp.
rise 50˚C.
•
Typical applications:
Switching Inductors in
Switch Mode Power
Supplies.
•
Core type:
Four mounting styles are offered:
1
Flying leads (1.00”), for vertical
or horizontal mounting.
2
4-pin header, for vertical mounting.
3
Threaded center hole, flying leads
(2.00”).
4
2-pin header, for vertical mounting.
MECHANICAL
Style 1
0.85
0.33
Style 2
0.95
0.25
Style 3
0.85
0.45
Thread
#6-32
0.60
0.75
Style 4
0.83
0.95
0.80
1.00
0.67
2.00
0.50
0.30
0.45
ELECTRICAL SPECIFICATION
Ordering Information:
Substitute the style number for the asterisk (*). Example: CTP4553, Style 1, 56uH.
Part No.
Ind.
CTP4553 - (uH)
DCR
Ohms
Rated
Current
Amp. RMS
I (amp.)
@ Lsat.
10%
I (amp.)
@ Lsat.
25%
I (amp.)
@ Lsat.
50%
Part No.
Ind.
CTP4553 - (uH)
DCR
Ohms
Rated
Current
Amp. RMS
Order: CTP4553 - 116
I (amp.)
@ Lsat.
25%
I (amp.)
@ Lsat.
50%
I (amp.)
@ Lsat.
10%
* 01
* 02
* 03
* 04
* 05
* 06
* 07
* 08
* 09
* 10
* 11
* 12
* 13
* 14
* 15
* 16
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
0.006
0.007
0.007
0.008
0.009
0.010
0.011
0.012
0.013
0.014
0.016
0.017
0.019
0.021
0.023
0.025
11.7
11.2
10.7
10.3
9.8
9.4
9.0
8.6
8.1
7.8
7.4
7.0
6.7
6.4
6.1
5.9
13.5
12.5
11.3
10.4
9.4
8.6
7.8
7.1
6.4
5.8
5.2
4.7
4.3
3.9
3.6
3.3
22.6
20.8
18.9
17.3
15.7
14.3
13.0
11.8
10.6
9.7
8.7
7.9
7.1
6.6
6.0
5.5
37.6
34.6
31.5
28.9
26.2
23.9
21.6
19.7
17.6
16.1
14.6
13.1
11.9
10.9
10.0
9.1
* 17
* 18
* 19
* 20
* 21
* 22
* 23
* 24
* 25
* 26
* 27
* 28
68
82
100
120
150
180
220
270
330
390
470
560
0.027
0.030
0.033
0.046
0.064
0.071
0.098
0.137
0.151
0.164
0.180
0.248
5.6
5.4
5.1
4.3
3.7
3.5
3.0
2.5
2.4
2.3
2.2
1.9
3.0
2.7
2.5
2.2
2.0
1.8
1.7
1.5
1.4
1.2
1.1
1.0
5.0
4.5
4.1
3.7
3.3
3.1
2.8
2.5
2.3
2.1
1.9
1.7
8.3
7.5
6.8
6.2
5.6
5.1
4.6
4.2
3.8
3.5
3.2
2.9
CTP4553
An ISO 9001 Registered Company
229 Colonnade Road, Nepean, Ontario, Canada K2E 7K3
Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com
33-2
