LX1552/3/4/5
U
LTRA
-L
OW
S
TART
-U
P
C
URRENT
, C
URRENT
-M
ODE
PWM
T
H E
I
N F I N I T E
P
O W E R
O F
I
N N O V A T I O N
P
R O D U C T I O N
D
A T A
S
H E E T
DESCRIPTION
The LX155x family of ultra-low start-up current
(250µA max), current mode control ICs offer new
levels of energy efficiency for offline converter
applications.
They are ideally optimized for
personal computer and CRT power supplies
although they can be used in any number of off-line
applications where energy efficiency is critical.
Coupled with the fact that the LX155x series
requires a minimal set of external components, the
series offers an excellent value for cost conscious
consumer applications.
Optimizing energy efficiency, the LX155x series
demonstrates a significant power reduction as
compared with other similar off-line controllers.
Table 1 compares the SG384x, UC384xA and the
LX155x start-up resistor power dissipation. The
LX155x offers an overall 4X reduction in power
dissipation.
Additionally, the precise oscillator discharge
current gives the power supply designer
considerable flexibility in optimizing system duty
cycle consistency.
The current mode architecture demonstrates
improved load regulation, pulse by pulse current
limiting and inherent protection of the power
supply output switch. The LX155x includes a
bandgap reference trimmed to 1%, an error
amplifier, a current sense comparator internally
clamped to 1V, a high current totem pole output
stage for fast switching of power MOSFETs, and
an externally programmable oscillator to set
operating frequency and maximum duty cycle.
The under voltage lock-out circuitry is designed to
operate with as little as 250µA of supply current
permitting very efficient bootstrap designs.
KEY FEATURES
Ultra-Low Start-up Current (150µA
Typical)
Trimmed Oscillator Discharge
Current (±2% Typical)
Initial Oscillator Frequency Better
Than ±4%
Output Pulldown During UVLO
Precision 2.5V Reference (±2
maximum)
Current Sense Delay to Output
(150ns Typical)
Automatic Feed Forward
Compensation
Pulse-by-Pulse Current Limiting
Enhanced Load response
Characteristics
Under-Voltage Lockout with
Hysteresis
Double Pulse Suppression
High Current Totem Pole Output
(±1A Peak)
500KHz Operation
IMPORTANT:
For the most current data, consult
MICROSEMI’s
website:
http://www.microsemi.com
PRODUCT HIGHLIGHT
Typical Application of LX155x Using Its MicroPower Start-Up Feature
R
ST
APPLICATIONS
LX155x
250µA
248KΩ
0.56W
AC
INPUT
I
ST
V
CC
Design Using
Max. Start-up Current
Specification (I
ST
)
Typical Start-up Resistor
Value (R
ST
)
Max. Start-up Resistor
Power Dissipation (P
R
)
SG384x
1000µA
62KΩ
2.26W
UC384xA
500µA
124KΩ
1.13W
Economy Off-Line Flyback or
Forward Converters
DC-DC Buck or Boost Converters
Low Cost DC Motor Control
Available Options Per part#
Part #
LX1552
LX1553
LX1554
LX1555
Start-Up
Max. Duty
Hysteresis
Voltage
Cycle
16V
6V
<100%
8.4V
0.8V
<100%
16V
6V
<50%
8.4V
0.8V
<50%
LX1552
or
LX1554
Note: Calculation is done for universal AC input
specification of V
ACMIN
= 90V
RMS
to V
ACMAX
= 256V
RMS
using
the following equation: (resistor current is selected to be 2
* I
ST
@ V
ACMIN
)
R
ST
=
V
ACMIN
2 • I
ST
, P
R
=
2V
AC2MAX
R
ST
PACKAGE ORDER INFO
T
A
(°C)
0 to 70
-40 to 85
-55 to 125
M
Plastic DIP
8-Pin
LX155xCM
LX155xIM
-
DM
Plastic SOIC
8-Pin
D
Plastic SOIC
14-Pin
LX155xCD
LX155xID
-
Y
Ceramic DIP
8-Pin
PW
Plastic TSSOP
20-Pin
RoHS Compliant / Pb-free
Transition DC: 0503
RoHS Compliant / Pb-free
Transition DC: 0440
RoHS Compliant / Pb-free
Transition DC: 0440
RoHS Compliant / Pb-free
Transition DC: 0442
LX155xCDM
LX155xIDM
-
-
-
LX155xMY
LX155xCPW
-
-
Note: Available in Tape & Reel. Append the letters “TR” to the part number (i.e. LX1552CDM-TR).
Copyright
©
1994
Rev. 1.0b,2005-03-01
L
IN
F
INITY
M
ICROELECTRONICS
I
NC
.
11861 W
ESTERN
A
VENUE
, G
ARDEN
G
ROVE
, CA. 92841, 714-898-8121, F
AX
: 714-893-2570
1
PRODUCT DATABOOK 1996/1997
LX1552/3/4/5
U
LTRA
-L
OW
S
TART
-U
P
C
URRENT
, C
URRENT
-M
ODE
PWM
P
R O D U C T I O N
D
A T A
S
H E E T
A B S O L U T E M A X I M U M R AT I N G S
(Note 1)
PACKAGE PIN OUTS
COMP
V
FB
I
SENSE
R
T
/C
T
1
2
3
4
8
7
6
5
Supply Voltage (Low Impedance Source) .................................................................. 30V
Supply Voltage (I
CC
< 30mA) ......................................................................... Self Limiting
Output Current ............................................................................................................. ±1A
Output Energy (Capacitive Load) ................................................................................ 5µJ
Analog Inputs (Pins 2, 3) ........................................................................... -0.3V to +6.3V
Error Amp Output Sink Current ............................................................................... 10mA
Power Dissipation at T
A
= 25°C (DIL-8) ...................................................................... 1W
Operating Junction Temperature
Ceramic (Y Package) ............................................................................................ 150°C
Plastic (M, DM, D, PW Packages) ........................................................................ 150°C
Storage Temperature Range .................................................................... -65°C to +150°C
Lead Temperature (Soldering, 10 Seconds) ............................................................ 300°C
Pb-free
/ RoHS Peak
Package Solder Reflow Temp. (40 second max. exposure)................ 260°C (+0, -5)
Note 1. Exceeding these ratings could cause damage to the device. All voltages are with respect
to Ground. Currents are positive into, negative out of the specified terminal. Pin
numbers refer to DIL packages only.
V
REF
V
CC
OUTPUT
GND
M & Y PACKAGE
(Top View)
M Package RoHS / Pb-free 100% Matte Tin Lead Finish
COMP
V
FB
I
SENSE
R
T
/C
T
1
2
3
4
8
7
6
5
V
REF
V
CC
OUTPUT
GND
DM PACKAGE
(Top View)
RoHS / Pb-free 100% Matte Tin Lead Finish
T H E R M A L D ATA
M PACKAGE:
THERMAL RESISTANCE-JUNCTION TO AMBIENT,
θ
JA
DM PACKAGE:
THERMAL RESISTANCE-JUNCTION TO AMBIENT,
θ
JA
D PACKAGE:
THERMAL RESISTANCE-JUNCTION TO AMBIENT,
θ
JA
Y PACKAGE:
THERMAL RESISTANCE-JUNCTION TO AMBIENT,
θ
JA
PW PACKAGE:
THERMAL RESISTANCE-JUNCTION TO AMBIENT,
θ
JA
144°C/W
130°C/W
120°C/W
165°C/W
95°C/W
COMP
N.C.
V
FB
N.C.
I
SENSE
N.C.
R
T
/C
T
1
2
3
4
5
6
7
14
13
12
11
10
9
8
V
REF
N.C.
V
CC
V
C
OUTPUT
GND
PWR GND
D PACKAGE
(Top View)
RoHS / Pb-free 100% Matte Tin Lead Finish
N.C.
N.C.
COMP
V
FB
N.C.
I
SENSE
N.C.
R
T
/C
T
N.C.
N.C.
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
Junction Temperature Calculation: T
J
= T
A
+ (P
D
x
θ
JA
).
The
θ
JA
numbers are guidelines for the thermal performance of the device/pc-board system.
All of the above assume no ambient airflow
N.C.
N.C.
V
REF
N.C.
V
CC
V
C
OUTPUT
GND
PWR GND
N.C.
PW PACKAGE
(Top View)
RoHS / Pb-free 100% Matte Tin Lead Finish
2
Copyright © 1994
Rev. 1.0b
PRODUCT DATABOOK 1996/1997
LX1552/3/4/5
U
LTRA
-L
OW
S
TART
