MCC
Micro Commercial Components
TM
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
DTA114ESA
Features
•
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Built-in bias resistors enable the configuration of an inverter circuit
without connecting external input resistors
The bias resistors consist of thin-film resistors with complete
isolation to allow negative biasing of the input. They also have the
advantage of almost completely eliminating parasitic effects.
Only the on/off conditions need to be set for operation, making
device design easy
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature
Min
---
-40
---
---
---
-55
Typ
-50
---
-50
300
150
---
Max
---
10
-100
---
---
150
Unit
V
V
mA
mW
℃
℃
Digital Transistors
TO-92S
B
Absolute maximum ratings @ 25℃
Symbol
V
CC
V
IN
I
O
P
d
T
j
T
stg
C
Electrical Characteristics @ 25℃
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
Parameter
Input voltage (V
CC
=-5V, I
O
=-100
μA)
(V
O
=-0.3V, I
O
=-10mA)
Output voltage (I
O
/I
I
=-10mA/-0.5mA)
Input current (V
I
=-5V)
Output current (V
CC
=-50V, V
I
=0)
DC current gain (V
O
=-5V, I
O
=-5mA)
Input resistance
Resistance ratio
Transition frequency
(V
CE
=-10V, I
E
=5mA, f=100MHz)
Min
-0.5
---
---
---
---
30
7.0
0.8
---
Typ
---
---
---
---
---
---
10
1.0
250
Max
---
-3.0
-0.3
-0.88
-0.5
---
13
1.2
---
Unit
V
V
V
mA
μA
KΩ
MHz
1
1
2
3
2
1. GND
2. OUT
3. IN
D
E
3
STRAIGHT LEAD BENT LEAD
BULK PACK
AMMO PACK
DIMENSIONS
DIM
A
B
C
INCHES
MIN
MAX
.056
.064
.154
.161
.120
.128
MM
MIN
1.42
3.90
3.05
MAX
1.62
4.10
3.25
NOTE
.050
1.27
Straight Lead
.086
.110
2.20
2.80
Bent Lead
.096
.104
2.44
2.64
Straight Lead
E
.173
.220
4.40
5.60
Bent Lead
L
.594
.610
15.10
15.50
* For ammo packing detailed specification, click here to visit our website
of product packaging for details.
D
www.mccsemi.com
Revision: D
1 of 3
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-AP-HF
Packing
Ammo Packing:
30Kpcs/Carton
Bulk:
100Kpcs/Carton
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
D
3
of
3
2013/01/01
