CAT5419WI-10-T1

Description
Digital Potentiometer, 2 Func, 10000ohm, 2-wire Serial Control Interface, 64 Positions, PDSO24, 0.300 INCH, ROHS COMPLIANT, MS-013, SOIC-24
CategoryAnalog mixed-signal IC    converter
File Size248KB,16 Pages
ManufacturerCatalyst
Websitehttp://www.catalyst-semiconductor.com/
Environmental Compliance
Download Datasheet Parametric View All

CAT5419WI-10-T1 Online Shopping

Suppliers Part Number Price MOQ In stock
CAT5419WI-10-T1 - - View Buy Now

CAT5419WI-10-T1 Overview

Digital Potentiometer, 2 Func, 10000ohm, 2-wire Serial Control Interface, 64 Positions, PDSO24, 0.300 INCH, ROHS COMPLIANT, MS-013, SOIC-24

CAT5419WI-10-T1 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerCatalyst
Parts packaging codeSOIC
package instructionSOP, SOP24,.4
Contacts24
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresNONVOLATILE MEMORY
control interface2-WIRE SERIAL
Converter typeDIGITAL POTENTIOMETER
JESD-30 codeR-PDSO-G24
JESD-609 codee3
length15.3 mm
Humidity sensitivity level1
Number of functions2
Number of positions64
Number of terminals24
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Encapsulate equivalent codeSOP24,.4
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
power supply2.5/6 V
Certification statusNot Qualified
resistance lawLINEAR
Maximum resistor tolerance20%
Maximum resistor terminal voltage5 V
Minimum resistor terminal voltage
Maximum seat height2.65 mm
Nominal supply voltage5 V
surface mountYES
Nominal temperature coefficient300 ppm/°C
Temperature levelINDUSTRIAL
Terminal surfaceMATTE TIN
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperature40
Nominal total resistance10000 Ω
width7.5 mm
CAT5419
Dual Digitally Programmable Potentiometers (DPP™)
with 64 Taps and 2-wire Interface
FEATURES
Two linear-taper digital potentiometers
64 resistor taps per potentiometer
End to end resistance 2.5kΩ, 10kΩ, 50kΩ or
100kΩ
Potentiometer control and memory access via
2-wire Interface (I
2
C like)
Low wiper resistance, typically 80
Four non-volatile wiper settings for each
potentiometer
Recall of wiper settings at power up
2.5 to 6.0 volt operation
Standby current less than 1µA
1,000,000 nonvolatile WRITE cycles
100 year nonvolatile memory data retention
24-lead SOIC and 24-lead TSSOP
Write protection for data register
DESCRIPTION
The CAT5419 is two Digitally Programmable
Potentiometers (DPP™) integrated with control logic
and 16 bytes of NVRAM memory.
A separate 6-bit control register (WCR) independently
controls the wiper tap position for each DPP.
Associated with each wiper control register are four 6-
bit non-volatile memory data registers (DR) used for
storing up to four wiper settings. Writing to the wiper
control register or any of the non-volatile data regis-
ters is via a 2-wire serial bus (I
2
C-like). On power-up,
the contents of the first data register (DR0) for each of
the two potentiometers is automatically loaded into its
respective wiper control registers (WCR).
¯¯¯
The Write Protection (WP) pin protects against
inadvertent programming of the data register.
The CAT5419 can be used as a potentiometer or as a
two terminal, variable resistor. It is intended for circuit
level or system level adjustments in a wide variety of
applications.
PIN CONFIGURATION
SOIC (W)
(top view)
V
CC
R
L0
R
H0
R
W0
A2
¯¯¯
WP
SDA
A
1
R
L1
R
H1
R
W1
GND
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
NC
NC
NC
NC
A
0
NC
A
3
SCL
NC
NC
NC
NC
SDA
A
1
R
L1
R
H1
R
W1
GND
NC
NC
NC
NC
SCL
A
3
For Ordering Information details, see page 15.
TSSOP (Y)
(top view)
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
¯¯¯
WP
A
2
R
W0
R
H0
R
L0
V
CC
NC
NC
NC
NC
A
0
NC
R
L0
R
L1
A0
A1
A2
A3
CONTROL
LOGIC
NONVOLATILE
DATA
REGISTERS
WP
R
W1
SCL
SDA
2-WIRE BUS
INTERFACE
WIPER
CONTROL
REGISTERS
FUNCTIONAL DIAGRAM
R
H0
R
H1
R
W0
CAT
19
5419
18
17
16
15
14
13
CAT
19
5419
18
17
16
15
14
13
© Catalyst Semiconductor, Inc.
Characteristics subject to change without notice
1
Doc. No. MD-2115 Rev. H
