2N689PBF: DescriptionSilicon Controlled Rectifier, 25A I(T)RMS, 500V V(DRM), 500V V(RRM), 1 Element, TO-208AA; CategoryAnalog mixed-signal IC Trigger device; File Size39KB，1 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance; Related ProductsFound16parts with similar functions to 2N689PBF

Download Datasheet Parametric View All

2N689PBF Overview

Silicon Controlled Rectifier, 25A I(T)RMS, 500V V(DRM), 500V V(RRM), 1 Element, TO-208AA

2N689PBF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	POST/STUD MOUNT, O-MUPM-D2
Reach Compliance Code	compli
Configuration	SINGLE
Maximum DC gate trigger current	40 mA
JEDEC-95 code	TO-208AA
JESD-30 code	O-MUPM-D2
JESD-609 code	e2
Number of components	1
Number of terminals	2
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum rms on-state current	25 A
Off-state repetitive peak voltage	500 V
Repeated peak reverse voltage	500 V
surface mount	NO
Terminal surface	Tin/Copper (Sn/Cu)
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	40
Trigger device type	SCR
Base Number Matches	1
