A Subsidiary of Data Device Corporation
40 Orville Drive, Bohemia, NY 11716-2529
Phone: (631) 244-7393; Fax: (631) 244-8893
Web site: www.bttc-beta.com
LPB-5000 SERIES
REV M
LOW-PROFILE
SURFACE MOUNT
MIL-STD-1553 PULSE TRANSFORMERS
FEATURES
•
Low Cost
•
Moisture Sensitivity Rating Level 1
Description and Applications
The military data bus specification, MIL-STD-1553, has brought about the
need for versatile pulse transformers that meet all the electrical requirements
of Manchester II serial bi-phase data transmission. The LPB-5000 series of
transformers provide the turns ratio configurations, component isolation, and
common mode rejection ratio characteristics necessary for MIL-STD-1553A
and B compliance.
The step-up and step-down ratios that are available with the LPB-5000 series
complement DDC’s entire MIL-STD-1553 product line and are compatible with
competitors’ drivers, receivers, and transceivers. These transformers are low-
profile, modular units that are multitapped to accommodate existing system
configurations. Encapsulated in accordance with MIL-PRF-21038, their C5191
Phosphor Bronze, Sn90 plated leads conveniently accommodate printed circuit
board mounting. Sinusoidal or trapezoidal waveforms are accurately pro-
cessed, making the LPB-5000 series of transformers an excellent choice for
any MIL-STD-1553A or B application.
•
For use in MIL-STD-1553A and B,
MacAir A-3818, A-5690, A-5232,
and A-4905
•
Qualification tested to
MIL-PRF-21038
•
Tested to M-Level and T-Level
(Optional) of MIL-PRF-21038
•
-55°C to +130°C Operating
Temperature Range
•
Robust Lead Design for Improved
Coplanarity
N:1
OVERSHOOT AND
RINGING ±1 V MAX
90%
E
D
E
IN
E
OUT
E
OUT
t
r
t
f
E
IN
= 10 V rms at 1 MHz
E
Calc: CMR = 20 log
IN
(see note)
E
OUT
FIGURE 2. CIRCUIT FOR COMMON MODE REJECTION
10%
% DROOP =
E
D
E
OUT
E
D
x 100%
E
OUT
360
Ω
1:N
E
IN
(SEE NOTE)
E
OUT
(SEE NOTE)
FIGURE 1. WAVEFORM INTEGRITY
E
IN
= 250 kHz square wave, 27.0 volts peak-to-peak with
a rise and fall time no greater than 100 ns.
Calc : Droop =
E
D
E
OUT
x 100%. (see figure 1 for E
D
)
FIGURE 3. CIRCUIT FOR WAVEFORM INTEGRITY
Notes: 1) Input to be applied and output to be measured for all dash numbers are as shown. N represents highest turns winding in each test.
2) For LPB-5033, the 360
Ω
resistor is replaced with a 50
Ω
resistor for conducting waveform test.
© 2005 Data Device Corporation
BETA TRANSFORMER TECHNOLOGY CORP • 40 ORVILLE DRIVE • BOHEMIA NY 11716-2529 • 631-244-7393 • FAX 631-244-8893
PARAMETER
Case
Terminals
Weight
Terminal Strength
Dielectric Withstanding Voltage
Life (expectancy “X”)
Insulation Resistance
Pulse Width (of Output Pulse)
Overshoot
Rise Time (of Output Pulse)
Common Mode Rejection
Operating Temperature Range
Storage Temperature Range
Droop
DC Resistance
Input Impedance
TABLE 1. LPB-5000 SERIES SPECIFICATIONS
UNIT
VALUE
REMARKS
—
—
Oz.(gm)
lbs
Vrms
Hrs
MΩ
µs
V
ns
dB
°C
°C
%
Ω
Ω
—
—
0.105 (3) max.
2
100
10,000 min.
1,000 min.
2
± 1 max.
—
≥
45
-55 to +130
-65 to +130
≤
20
—
—
2 pounds applied force, Method 211, MIL-STD-202, Test condition A
Method 301, MIL-STD-202
In accordance with MIL-PRF-21038
At 250 Vdc using method 302, test condition B, MIL-STD-202
Tested using FIGURE 3 with resulting FIGURE 1 waveform.
Tested using FIGURE 3 with resulting FIGURE 1 waveform.
Tested using FIGURE 3 with resulting FIGURE 1 waveform. See respective
ELECTRICAL CHARACTERISTICS TABLE
Tested using FIGURE 2.
—
—
Tested using FIGURE 3 with resulting FIGURE 1 waveform.
See respective Electrical Characteristics Table
See respective Electrical Characteristics Table.
Tested at 75 kHz and 1 MHz over entire operating temperature range.
Flame Resistant, Diallyl Phthalate
C5191 Phosphor Bronze, Sn90 Plating
CONFIGURATION
.043 REF
(1.09)
3
.400 (10.16)
.200 (5.06)
1
TOP VIEW
2
8
7
6
5
4
.020 (0.51) 8 PLS
.625 MAX (15.9)
.004 - .010
(0.10 - 0.25)
1
5
4
.100 (2.54) 4 PLS
C
L
.625 MAX
(15.9)
2
6
8
3
7
CIRCUIT DIAGRAM FOR LPB-5005, LPB-5006
1
4
5
.020 (0.51) 8 PLS
0.155 MAX
(3.94)
2
6
7
3
8
0.81 (20.57)
1.11 (28.19)
150
(3.81)
NOTES:
(1) Dimensions are in inches (mm).
(2) Tolerance (unless specified otherwise):
.xx is ± .010 inches.
.xxx is ± .005 inches.
CIRCUIT DIAGRAM FOR ALL OTHERS
2
BETA TRANSFORMER TECHNOLOGY CORP • 40 ORVILLE DRIVE • BOHEMIA NY 11716-2529 • 631-244-7393 • FAX 631-244-8893
TABLE 2. ELECTRICAL CHARACTERISTICS
BETA P/N
LPB-5000
LPB-5001
LPB-5002
LPB-5003
LPB-5004
LPB-5005
LPB-5006
LPB-5015
LPB-5033
TURNS RATIO PRIMARY SECONDARY DC RESISTANCE
Ω
(MAX)
2:5 ±3%
4:7 ±3%
1:0.83 ±3%
1:0.60 ±3%
1.4:1 ±3%
2:1 ±3%
1:1 ±3%
1:0.707 ±3%
1.25:1 ±3%
1.66:1 ±3%
2.3:1 ±3%
3.2:1 ±3%
2.12 :1 ±3%
1.5 :1 ±3%
1:2.5 ±3%
1:1.79 ±3%
1: 3.75 ±3%
1: 2.70 ±3%
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
1-3
4-8
5-7
4-8
5-7
1-3
1-3
1-3
1-3
4-8
5-7
4-8
5-7
4-8
5-7
4-8
5-7
4-8
5-7
1-3
1-3
1-3
1-3
4-8
5-7
4-8
5-7
(1-3) 3.5
(4-8) 3.0
(1-3) 3.0
(4-8) 3.0
(1-3) 3.5
(4-8) 3.0
(1-3) 3.0
(4-8) 3.0
(1-3) 3.2
(4-8) 3.0
(1-3) 1.2
(4-8) 3.0
(1-3) 1.1
(4-8) 3.0
(1-3) 1.0
(4-8) 3.0
(1-3) 0.25
(4-8) 3.0
OUTPUT RISE TIME NSEC (MAX)
150
150
150
150
150
150
200
250
250
IMPEDANCE
Ω
(MIN)
(4-8)
3,000
(1-3)
3,000
(1-3)
7,200
(1-3)
4,000
(1-3)
4,000
(5-7)
3,000
(4-8)
4,000
(4-8)
3,000
(4-8)
3,000
Notes:
1) These transformers have been classified as IPC-9503 Level 1 and are not moisture sensitive. To ensure product integrity and maintain the product warranty, the reflow
process must not cause the peak body temperature of the device to exceed 225°C and must not expose the device to temperatures above 183°C for more than 90
seconds. Tape and Reel packaging is available upon request. Contact factory for further information.
TAPE AND REEL MECHANICAL OUTLINE
0.012
±
.002
(0.30
±
.05)
∅
0.059 +.004/-.000
(∅ 1.5 +.1/-.0)
0.079
±
.006
(2.00
±
.15)
0.157
(4.00)
0.069
(1.75)
R 0.012 MAX
(R 0.30 MAX)
0.795
±
.006
(20.20
±
.15)
1.205
(30.60)
0.55
(14.0)
1.591
(40.40)
1.73
±
.012
(44.0
±
.30)
45.0
0.17
(4.4)
R 0.02 TYP
(R 0.5 TYP)
0.787
(20.00)
0.65
(16.4)
∅
0.079 MIN
(∅ 2.00 MIN)
0.19
(4.9)
DMENSIONS ARE IN
INCHES (MM)
TOLERANCES
.XX (.X) =
±
.008 (0.20)
.XXX (.XX) =
±
.004 (0.10)
R 0.030
(R 0.75)
0.008
±
.002
(0.20
±
.05)
3
The information in this data sheet is believed to be accurate; however, no responsibility is
assumed by Beta Transformer Technology Corporation for its use, and no license
or rights are granted by implication or otherwise in connection therewith.
Specifications are subject to change without notice.
Visit our Web site at
www.bttc-beta.com
for the latest information.
