LSH32KM30 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> LSH32KM30

LSH32KM30: DescriptionBarrel Shifter, 32-Bit, CMOS, CQCC68, 0.950 X 0.950 INCH, CERAMIC, LCC-68; CategoryThe embedded processor and controller Microcontrollers and processors; File Size404KB，10 Pages; ManufacturerLOGIC Devices; Websitehttp://www.logicdevices.com/

Download Datasheet Parametric Compare View All

LSH32KM30 Overview

Barrel Shifter, 32-Bit, CMOS, CQCC68, 0.950 X 0.950 INCH, CERAMIC, LCC-68

LSH32KM30 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	LOGIC Devices
Parts packaging code	LCC
package instruction	QCCN,
Contacts	68
Reach Compliance Code	unknown
ECCN code	3A001.A.2.C
Other features	ICC SPECIFIED @ 5MHZ
boundary scan	NO
External data bus width	32
JESD-30 code	S-CQCC-N68
JESD-609 code	e0
length	24.13 mm
low power mode	NO
Humidity sensitivity level	3
Number of terminals	68
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output data bus width	16
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	225
Certification status	Not Qualified
Maximum seat height	3.048 mm
Maximum slew rate	30 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	24.13 mm
uPs/uCs/peripheral integrated circuit type	DSP PERIPHERAL, BARREL SHIFTER

Preview

Download Datasheet

View All

LSH32KM30 Related Products

	LSH32KM30	5962-8971702MYA	5962-8971702MXA	5962-8971701MXA	LSH32EC32	LSH32EC42	LSH32KC20	LSH32EC20	5962-8971701MYA
Description	Barrel Shifter, 32-Bit, CMOS, CQCC68, 0.950 X 0.950 INCH, CERAMIC, LCC-68	Barrel Shifter, 32-Bit, CMOS, CPGA68	Barrel Shifter, 32-Bit, CMOS, CQCC68	Barrel Shifter, 32-Bit, CMOS, CQCC68	Barrel Shifter, 32-Bit, CMOS, CPGA68, CAVITY-UP, CERAMIC, PGA-68	Barrel Shifter, 32-Bit, CMOS, CPGA68, CAVITY-UP, CERAMIC, PGA-68	Barrel Shifter, 32-Bit, CMOS, CQCC68, 0.950 X 0.950 INCH, CERAMIC, LCC-68	Barrel Shifter, 32-Bit, CMOS, CPGA68, CAVITY-UP, CERAMIC, PGA-68	Barrel Shifter, 32-Bit, CMOS, CPGA68
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
package instruction	QCCN,	PGA,	QCCN,	QCCN,	PGA,	PGA,	QCCN,	PGA,	PGA,
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Other features	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ	ICC SPECIFIED @ 5MHZ
boundary scan	NO	NO	NO	NO	NO	NO	NO	NO	NO
External data bus width	32	32	32	32	32	32	32	32	32
JESD-30 code	S-CQCC-N68	S-CPGA-P68	S-CQCC-N68	S-CQCC-N68	S-CPGA-P68	S-CPGA-P68	S-CQCC-N68	S-CPGA-P68	S-CPGA-P68
JESD-609 code	e0	e0	e0	e0	e0	e0	e0	e0	e0
length	24.13 mm	29.464 mm	24.1935 mm	24.1935 mm	29.464 mm	29.464 mm	24.13 mm	29.464 mm	29.464 mm
low power mode	NO	NO	NO	NO	NO	NO	NO	NO	NO
Humidity sensitivity level	3	3	3	3	3	3	3	3	3
Number of terminals	68	68	68	68	68	68	68	68	68
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	70 °C	70 °C	70 °C	70 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-	-	-	-	-55 °C
Output data bus width	16	16	16	16	16	16	16	16	16
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN	PGA	QCCN	QCCN	PGA	PGA	QCCN	PGA	PGA
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	CHIP CARRIER	GRID ARRAY	CHIP CARRIER	CHIP CARRIER	GRID ARRAY	GRID ARRAY	CHIP CARRIER	GRID ARRAY	GRID ARRAY
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	3.048 mm	4.4196 mm	3.048 mm	3.048 mm	4.4196 mm	4.4196 mm	3.048 mm	4.4196 mm	4.4196 mm
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.25 V	5.25 V	5.25 V	5.25 V	5.5 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.75 V	4.75 V	4.75 V	4.75 V	4.5 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	NO	YES	YES	NO	NO	YES	NO	NO
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)	TIN LEAD	TIN LEAD	TIN LEAD	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	TIN LEAD
Terminal form	NO LEAD	PIN/PEG	NO LEAD	NO LEAD	PIN/PEG	PIN/PEG	NO LEAD	PIN/PEG	PIN/PEG
Terminal pitch	1.27 mm	2.54 mm	1.27 mm	1.27 mm	2.54 mm	2.54 mm	1.27 mm	2.54 mm	2.54 mm
Terminal location	QUAD	PERPENDICULAR	QUAD	QUAD	PERPENDICULAR	PERPENDICULAR	QUAD	PERPENDICULAR	PERPENDICULAR
width	24.13 mm	29.464 mm	24.1935 mm	24.1935 mm	29.464 mm	29.464 mm	24.13 mm	29.464 mm	29.464 mm
uPs/uCs/peripheral integrated circuit type	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER	DSP PERIPHERAL, BARREL SHIFTER
Maker	LOGIC Devices	LOGIC Devices	LOGIC Devices	LOGIC Devices	-	-	LOGIC Devices	LOGIC Devices	LOGIC Devices
Parts packaging code	LCC	-	-	-	PGA	PGA	LCC	PGA	-
Contacts	68	-	-	-	68	68	68	68	-
ECCN code	3A001.A.2.C	3A001.A.2.C	3A001.A.2.C	3A001.A.2.C	-	-	-	-	3A001.A.2.C
Peak Reflow Temperature (Celsius)	225	-	-	-	225	225	225	225	-
Maximum slew rate	30 mA	-	-	-	30 mA	30 mA	30 mA	30 mA	-
Maximum time at peak reflow temperature	NOT SPECIFIED	-	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-
Base Number Matches	-	1	1	1	1	1	-	-	-
