CORCOM Product Guide
Single Phase External Power Line Filter for Frequency Converters
FC Series
UL Recognized
FC10
FC Series
The FC filters provide filtering for frequency inverters and
variable speed motor drives. Designed for very noisy
applications, they attenuate conducted interference at low
and high frequency ranges and protect programmable
logic controllers from RF noise on the AC power line. These
filters perform best when installed on the line side of the
motor drive. The FC filters better prevent noise from
returning to the line, enabling equipment to meet strict
European regulations on RFI.
Suited for field wiring applications, these filters are ideal for
EMC troubleshooting and field refurbishing. The FC filters
feature side flanges for easy mounting and DIN type
terminals which eliminate live metal parts, allowing safer
and easier connection. The filters could also be sold as an
accessory to motor drives marketed into Europe.
Specifications
Maximum leakage current,each line-to-ground
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Rating
06A
12A
16A
25A
36A
.01
9
5
4
2
0
Frequency–MHz
.03 .05 .1
.5
1
5
19
17
15
14
6
26
25
22
22
14
37
37
36
36
27
65
65
65
75
68
65
65
65
75
75
50
65
70
70
70
10
40
60
70
70
70
30
35
35
35
48
50
3.8 mA
6.7 mA
2250 VDC
1450 VDC
50/60 Hz
250 VAC
Electrical Schematics
6 & 12 Amps
LINE
LOAD
Line-to-line in 50 ohm circuit
Current
Rating
06A
12A
16A
25A
36A
LOAD
.01
10
14
14
14
14
Frequency–MHz
.03 .05 .1
.5
1
5
10
14
14
14
14
35
30
29
17
17
60
51
55
42
42
75
75
75
75
75
75
75
75
75
75
60
75
75
70
70
10
50
70
70
70
70
30
45
45
45
50
50
16, 25 & 36 Amps
LINE
Resistor location for reference only.
58
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Single Phase External Power Line Filter for Frequency Converters
(Continued)
FC Series
RFI Power Line Filters
Case Styles
6, 12, 16FC10
Hole: .203 x .156
5.16 x 3.96
(4)
Case Dimensions
A
Part No. (max)
6FC10
LOAD
LINE
B
(max)
3.10
78.7
3.96
100.6
3.96
100.6
5.48
139.2
5.48
139.2
C
(max)
1.78
45.21
2.18
55.4
2.18
55.4
2.55
64.77
2.55
64.77
D
± .020
± .51
E
(max)
3.70
94.0
4.53
114.8
4.53
114.8
5.94
150.9
5.94
150.9
F
± .010
± .254
4.60
116.8
5.95
151.3
5.95
151.3
6.90
175.3
6.90
175.3
2.677
67.8
3.50
88.9
3.50
88.9
4.90
124.5
4.90
124.5
2.00
50.8
2.00
50.8
2.00
50.8
2.756
70.0
2.756
70.0
B
D
12FC10
16FC10
C
This hole indicates the "Line"
side and may be on either flange.
F
E
A
8-32 Screws (2)
25FC10
36FC10
6FC10, 12FC10, 16FC10
Phoenix contact VDFK4
Accepts 10 AWG solid wire, 12 AWG stranded wire
Torque Spec: 5.5 - 7.0 in.lb
Part Numbers
25, 36FC10
This hole indicates the "Line" side
and may be on either flange.
Slots: .260 x .156
6.60 x 3.96
(4)
06FC10
12FC10
16FC10
25FC10
36FC10
B
D
C
F
E
A
8-32 Screws (2)
25FC10, 36FC10
Phoenix contact VDFK6
Accepts 8 AWG solid wire, 10 AWG stranded wire
Torque Spec: 13.5 - 16 in.lb
59
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
