CORCOM Product Guide
Smallest Filtered Power Entry Modules with Metric Fuseholders
GG/HG Series
UL Recognized
CSA Certified
VDE Approved
HG1/GG1
GG8
GG Series
The GG series power entry modules combine the functions
of a general purpose RFI filter with an IEC power cord
connector and single or dual metric fusing, in the smallest
possible panel space. A choice of .250” terminals or wire
leads is available for the load-side terminations.
For maximum cost effectiveness, 6 amp models should be
used for all applications rated 6 amps or less, unless the
higher performance of the 3 amp models, or the much
higher performance of the 1 amp models, is needed.
Models with C-suffix additionally incorporate a ground
choke
1
to isolate the equipment chassis from external
ground at RF frequencies.
Specifications
Maximum leakage current,each line-to-ground
HG Models
@ 120 VAC 60 Hz:
2µA
@ 250 VAC 50 Hz:
5µA
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Fuse (not included):
GG Models
.25 mA
.42 mA
1550 VAC
1450 VDC
50/60 Hz
250 VAC
Accepts one 5x20mm fuse
(-1 models) or two 5 x 20 mm
fuses (-2 models)
HG Series
A medical version of our GG series, these filters offer the
same compact design but reduce the line-to-ground
capacitance in order to meet UL 2601 patient care
requirements. For more information on UL2601
specification, see Appendix C.
Note: When using the models with an IEC connector,
remember that the leakage current of the companion line
cord, GA400, is more significant than that of the filter -
which may disqualify this line cord from use in patient care
applications.
Current
Rating .01
GG/GS Models
1A
12
3A
–
–
6A
HG Models
1A
12
3A
–
6A
–
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
.05
23
10
1
23
10
4
Frequency-MHz
.10 .15 .5
1
5
29
15
4
29
15
10
32
19
10
32
19
14
41
30
16
40
25
18
47
36
22
40
26
18
50
48
36
28
22
14
10
50
50
40
22
21
14
30
55
53
50
18
21
14
Electrical Schematics
GG/GS/HG
LINE
Note 1
LOAD
Line-to-line in 50 ohm circuit
Current
Rating
.01
1
1
1
1
1
1
.15
3
2
2
3
2
2
Frequency-MHz
.5
1
3
5
14
11
10
26
30
30
23
14
13
35
30
30
41
25
23
35
30
30
47
38
33
35
30
30
10
50
44
39
27
30
30
30
44
40
42
20
30
30
Note 2
GG-C
LINE
Note 1
LOAD
Note 2
Resistor location for reference only.
Note 1: Depicts single fuse for -1 models.
Note 2: For HG delete line-to-ground capacitors.
CAUTION: DO NOT ATTEMPT TO OPERATE A SINGLE-FUSED MODEL WITHOUT THE
FUSE DOOR IN PLACE!
GG/GS Models
1A
3A
6A
HG Models
1A
3A
6A
112
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Smallest Filtered Power Entry Modules with Metric Fuseholders
(Continued)
GG/HG Series
Case Styles
GG1/HG1
D
C
EGS
C
E
D
E
A
A
B
B
Power Entry Modules
Recommended Panel Cutouts
GG / HG
Front or Back Mount
1.14
29.0
GS / HGS
Front Mount Only
1.24
31.5
Typical dimensions:
Holes: .07 [1.8] Dia.
Terminals: .250 [6.35] (3)
Mounting Holes: .126 [3.20] Dia. (2)
1.30
33.0
1.29
32.8
GG8
Blue
Green/Yellow
Brown
1.417
36.0
for panel thickness
.032-.080
[.81-2.03]
Radius: 0.138
[0.35]
Case Dimensions
B
C
.6
15.2
D
E
A
Typical dimensions:
Wire leads: 5.0 [127.0] Min. 18 AWG Mounting Holes: .126 [3.20] Dia. (2)
A
Part No.
(max)
EGG1-1/EGG1-2/
2.15
EHG1-2
54.5
EGG8-1/EGG8-2
2.02
EGG8C-1/EGG8C-2
51.1
EGS1-1/EGS1-2
2.13
EHGS1-2
54.0
EGG1C-1-1/EGG1C-2
2.45
62.23
*max
B
(max)
1.13
28.7
1.13
28.7
1.13
28.7
1.13
28.7
C
(max)
1.29
32.8
1.29
32.8
1.28
32.5
1.28
32.5
D
± .015
± .38
1.417
36.0
1.417
36.0
1.46*
36.0
1.46*
36.0
E
(max)
1.76
44.7
1.76
44.7
1.42
36.1
1.42
36.1
Part Number
1
RFI Filter Type
2
Current Rating
3
Metric Fuseholders
2
1EGG1-1
General Purpose
1
1
1EGG1-2
General Purpose
1
2
1EGG8-1
General Purpose
1
1
1EGG8-2
General Purpose
1
2
1
1
1EGS1-1
General Purpose
2
General Purpose
1
1EGS1-2
3EGG1-1
General Purpose
3
1
3EGG1-2
General Purpose
3
2
3
1
General Purpose
3EGG8-1
3EGG8-2
General Purpose
3
2
3EGS1-1
General Purpose
3
1
3EGS1-2
General Purpose
3
2
General Purpose
6
1
6EGG1-1
2
6
General Purpose
6EGG1-2
1
6
General Purpose
6EGG8-1
6EGG8-2
General Purpose
6
2
6EGS1-1
General Purpose
6
1
6
2
General Purpose
6EGS1-2
1EHG1-2
Medical
1
2
3EHG1-2
Medical
3
2
6EHG1-2
Medical
6
2
1EHGS1-2
Medical
1
2
2
3
Medical
3EHGS1-2
2
6
Medical
6EHGS1-2
1
Ground choke available on general purpose models. Add suffix "C" (1EGG1C-1). Does not include EGS models.
2
General purpose filter for susceptibility applications.
3
Current rating @120 VAC and 250 VAC.
Load Side Terminations
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
5.0 [127.0] Wire Leads
5.0 [127.0] Wire Leads
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
5.0 [127.0] Wire Leads
5.0 [127.0] Wire Leads
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
5.0 [127.0] Wire Leads
5.0 [127.0] Wire Leads
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
.250 [6.35] Terminals (3)
113
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
