CORCOM Product Guide
Three Phase RFI Power Line Filters
AYA Series
UL Recognized
25AYA6A
AYA Series
The AYA series filters are designed for 3-phase, four-wire,
WYE wiring applications. These cost-effective filters help
better protect electronic equipment in industrial
applications.
The series offers filtering up to 50 amps maximum and is
used in 3-phase, industrial applications such as
uninterruptible power supplies and industrial control
systems. The AYA series is designed to comply with
current international standards.
Specifications
Maximum leakage current, each line-to-ground
@ 120 VAC 60Hz
@ 250 VAC 50 Hz
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Operating voltage (max.):
Rated current:
16AYA6-A
25AYA6-A
36AYA6-A
50AYA6-A
1.62mA
2.82mA
1500 VAC
1450 VDC
50/60 Hz
440 VAC
16A
25A
36A
50A
Electrical Schematic
LINE
A
B
C
N
GND
Resistor location for reference only.
Typical insertion loss in dB:
LOAD
A
B
C
N
GND
Line-to-ground in 50 ohm circuit
Current
Rating
16A
25A
36A
50A
Current
Rating
16A
25A
36A
50A
.01
2
2
1
1
Frequency-MHz
.05 .1
.5
1
11
12
10
8
19
19
18
14
52
46
49
43
53
49
54
47
5
70
64
63
63
10
61
54
57
53
30
30
27
32
29
Line-to-line in 50 ohm circuit
.01
14
20
20
20
Frequency-MHz
.05 .1
.5
1
31
36
39
30
30
38
36
38
82
85
86
85
87
81
78
82
5
76
68
65
67
10
77
69
62
66
30
47
33
35
38
14
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Three Phase RFI Power Line Filters
(Continued)
AYA Series
RFI Power Line Filters
Case Style
Case Dimensions
Part No.
A
(max)
7.91
201.0
7.91
201.0
B
(max)
4.37
111.0
4.37
111.0
C
(max)
1.97
50.0
2.56
65.0
D
(max)
5.94
151.0
5.94
151.0
E
(max)
5.51
140.0
5.51
140.0
A
D
16/25
36/50
4.921±.020
125.0±.5
E
B
Part Numbers
2.756±.012
70.0±.3
C
16AYA6A
25AYA6A
36AYA6A
50AYA6A
Terminals:
16/25:
Torque (Max.):
36/50
Torque (Max.):
8-32 (8)
14 in.lb.
1/4-20 (8)
56 in.lb. ± 2 in.lb.
15
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
