CORCOM Product Guide
Compact RFI Filter with IEC Connector for Higher Frequency Applications
EJT Series
UL Recognized
CSA Certified
VDE Approved*
EJT1
EJT8
EJT Series
The EJT Series is a power inlet filter designed to attenuate
noise up to 1 GHz. This inlet uses an IEC 320/C14 input
connector which gives it a maximum rating of 15 amps.
The EJT series is flange-mounted with optional outputs of
1/4" terminals or wire leads. This product was designed to
address the demand for more noise attenuation at higher
frequencies in a compact inlet. Now also available with an
IEC 320/C20 connector with a maximum rating of 20 amps.
*15EJT - VDE rated at 10 amps, 250 VAC
20EJT - VDE rated at 16 amps, 250 VAC
Specifications
Maximum leakage current,each line-to-ground
1-15 Amp
@ 120 VAC 60 Hz:
.22 mA
@ 250 VAC 50 Hz:
.38 mA
Hipot rating (one minute):
line-to-ground
2250 VDC
line-to-line
1450 VDC
Operating frequency:
Rated voltage (max.):
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Rating
01A
03A
06A
10A
15A
20A
.15
27
22
13
7
4
-
.5
33
30
21
14
10
8
Frequency-MHz
1
5
10
40
59
65
34
57
63
27
51
60
21
43
52
15
38
48
15
42
50
30
65
69
65
61
63
60
20 Amp
.20 mA
.40 mA
1500 VAC
1450 VDC
50/60 Hz
250 VAC
Electrical Schematics
1-15 Amp
LINE
LOAD
100
61
61
59
61
63
58
1000
14
10
14
14
14
14
Line-to-line in 50 ohm circuit
Current
Rating
01A
03A
06A
10A
15A
20A
.15
10
10
10
10
10
9
.5
20
20
21
21
20
20
Frequency-MHz
1
5
10
23
43
52
51
24
41
24
37
48
25
28
44
26
25
36
26
40
35
30
65
59
65
63
56
48
100
45
52
55
53
45
50
1000
14
17
20
18
23
10
20 Amp
Resistor location for reference only.
52
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Compact RFI Filter with IEC Connector for Higher Frequency Applications
(Continued)
EJT Series
RFI Power Line Filters
Case Styles
EJT1
Case Dimensions
A
B
(max) (max)
2.87
72.9
2.23
56.6
3.8
96.52
3.2
81.28
1.19
30.2
1.19
30.2
1.350
34.29
1.350
34.29
C
D
E
F
(max) (max) (max) (max)
0.875
22.2
0.875
22.2
1.18
29.99
1.18
29.99
1.575
40.0
1.575
40.0
1.654
42.01
1.654
42.01
1.98
—
50.3
1.98 0.295
50.3
7.5
2.087
—
53.00
2.087
—
53.00
Part No.
C
1-15A
EJT1
B
D
E
A
1-15A
EJT8
20EJT1
4.0
101.6
F
EJT8
20EJT8
B
F
E
D
Part Numbers
C
A
Typical dimensions:
Wire Leads:
4.0 [101.6] Min. - 18 AWG
01EJT1
03EJT1
06EJT1
10EJT1
15EJT1
20EJT1
Line Cord No.
01EJT8
03EJT8
06EJT8
10EJT8
15EJT8
20EJT8
GA400
20EJT1
Recommended Panel Cutout
D
A
B
1 to 15 Amp
∅
.140
3.56
C
0.126 Dia. with
0.236 x 90° Countersink
for #4 Flat Head Screw (2X)
1.035 [26.29]
0.650
16.51
max.
E
0.25 Terminal with
0.069 (
± .003)
dia. hole
(2 places)
.820
20.83
1.200
30.48
1.575
40.00
Panel Cutout (front mount)
Tolerance ±.005 [0.13]
0.005
Tolerance +/-
Panel Cutout (Front Mount)
E
Label
0.25 Terminal with
0.069 x 0.155 Slot
R .062
1.57
20EJT8
20 Amp
D
A
4.0
101.6
min.
E
0.138
Dia. (2X)
3.51
R 0.118
3.00
C
1.035 [26.29]
1.055
26.80
0.528
13.41
0.126 Dia. with
0.236 x 90° Countersink
for #4 Flat Head Screw (2X)
Wire, #14 AWG
UL 1015 (3 places)
B
1.370
34.80
E
Label
Brown (Line)
Green / Yellow (Ground)
Blue (Neutral)
1.654
42.01
Panel Cutout (front mount)
Tolerance ±.005 [0.13]
53
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
