Electrical Specifications (-55°C to +105°C unless otherwise specified)
Input (2 terminal configuration)
Input supply voltage range (Vcc)
Input current (max.) @ 5Vdc
Must turn-on voltage
Must turn-off voltage
Reverse voltage protection
Input (3 terminal configuration)
Control voltage range
Control current (max.)
Input supply voltage range (Vcc)
Input current (max.) @ 5Vdc
0 - 18 Vd
250µAdc @ 5V, 1mA @ 18V
3.8 - 32 Vdc (Notes 1 & 2, Figures 1 & 2)
15mADC (Notes 1 & 2, Figures 1 & 2)
0.3Vdc
3.2Vdc
1,000V rms
109 ohms
10pF
2.1Adc (Figure 7)
60Vdc
80Vdc (Note 5)
0.15 ohm (Note 6, Figure 6)
0.5Vdc
100µAdc
2mAdc
3 ms (Figure 3)
1 ms (Figure 3)
100V / µs
600Vdc (Note 5)
125°C
90°C/W
25°C/W
1 - 18Vdc
600µADC (Figure 5, Note 8)
10µAdc
3.5 ms (Figure 4)
8 ms (Figure 4)
3.8 - 32 Vdc (Notes 1 & 2, Figures 1 & 2)
15mAdc (Notes 1 & 2, Figures 1 & 2)
3.8Vdc
1.5Vdc
-32Vdc
Mechanical Characteristics
Weight (approx.):
.176 oz. (5 grams)
Materials:
Header: Kovar
Cover: Nickel
Pins: Kovar, gold plated
Must turn-on voltage
Must turn-off voltage
I/O
Dielectric strength (min.)
Insulation resistance (min.) @ 500Vdc
Capacitance (max.)
Output
Continuous load current (max.) @ 25°C
Continuous load voltage (max.)
Transient blocking voltage (max.)
On resistance (max.) @ Tj = 25°C, IL = 100mA
Output voltage drop (max.)
Leakage current (max.) @ V = 60Vdc
Leakage current (max.) @ V = 60Vdc, with switch status
Turn-on time (max.)
Turn-off time (max.)
dv/dt (min.)
Electrical system spike
Output chip junction temperature (max.)
Thermal resistance (max.), junction to ambient
Thermal resistance (max.), junction to case
Status
Status supply voltage range
Status current (max.) @ Vstatus
≤
0.4Vdc
Status leakage current (max.) @ 16Vdc
Status turn-on time (max.)
Status turn-off time (max.)
Short Circuit Protection
Current surge without tripping (max.), 100ms pulse
Overload trip current (max.), 0.5 ms pulse, V = 60Vdc
Trip time (typical), turning on into short
Trip time (typical), shorting while relay is on
4.25Adc
10Adc
400µs
280µs
2
Catalog DS11-TBD
Issued 1-04
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
DS11 Series High Performance Solid State Relays
DC solid state relay for loads up to 2A @ 60Vdc
(Continued)
Figure 1 - Maximum Input Current vs. Input Voltage
Figure 2 - Series Resistance vs. Vcc Supply Voltage (Note 1)
18
1800
Input Current (mA)
12
9
6
3
0
0
5
10 15 20 25 30 40 50 60
R Series (ohms)
15
1500
1200
900
600
300
0
0
6
10
15
20
25
30
35
Input Voltage, Vcc (Vdc)
Figure 3 - Turn-on and Turn-off Timing
Vcc (Volts)
Figure 4 - Output Status Timing
Pin 14
(Input)
Pin 6-8
TOn
TOff
High
Low
90%
10%
V
Control
50%
OFF
ON
T
Off
On
V
S
90%
10%
T
Status
Turn-On
Time
Status
Turn-Off
Time
Figure 5 - Status Resistor vs. Status Supply Voltage
Figure 6 - On-Resistance vs. Temperature (Note 6)
Status Resistor (ohms)
30000
25000
20000
15000
10000
5000
0
0
5
10
15
20
Normalized On Resistance Factor
(NR)
35000
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
25
50
75
100
125
Status Supply Voltage (Volts)
Junction Temperature (°C)
3
Catalog DS11-TBD
Issued 1-04
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
DS11 Series High Performance Solid State Relays
DC solid state relay for loads up to 2A @ 60Vdc
(Continued)
Figure 7 - Temperature Derating Curve
Figure 8 - Maximum Surge Current Without Tripping
Output Current (amps)
Surge Current (amps)
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
-50 -40 -20
7.0
-55°C
6.0
5.0
4.0
3.0
2.0
+85°C
+25°C
0
20 40 60 80 100 120
1.0
0.01
0.1
1
10
Ambient Temperature (°C)
Figure 9 - Outline Dimensions
.530 MAX
(13.46)
.200
(5.08)
.273
±.020
(6.93
±
.50)
.020 MAX.
(.50)
.490 REF.
(12.44)
Time (seconds)
.140
(3.55)
.890 MAX.
(22.60) .600
.500
(12.70)
(15.24)
.850 REF.
(21.59)
TOP MARKING
ORIENT AS
SHOWN
.110
(2.79)
.300
(7.62)
.190 MAX.
(4.82)
.017 +.002, –.001 DIA.
(.43 + .05, –.02)
6 PLS.
DATE CODE
HERE
TOLERANCE:
±
0.010 (0.25mm) FOR 2 PLACE DECIMALS,
±
0.005 (0.13mm) FOR 3 PLACE DECIMALS.
UNLESS OTHERWISE SPECIFIED
Notes
1.2 terminal input configuration is compatible with CMOS or open collector TTL (with pull-up resistor). For Vcc levels above 6Vdc, a series limiting resistor is
required. See Fig. 2 for resistor value. Use standard resistor value equal to or less than value from the curve.
2.Input transitions to be
≤
1ms duration, and input direct drive should be “bounceless contact” type.
3. Vcc = 5Vdc for all tests unless otherwise specified.
4.All DS11 Series relays may drive loads connected to either positive or negative referenced power supply lines. Reversing polarity of output may cause permanent
damage. Inductive loads must be diode suppressed.
5.Transient blocking voltage and electrical system spike tests are performed per MIL-STD-704 (28VDC systems).
6.To determine the maximum on-resistance at any given junction temperature, multiply on-resistance at 25°C (0.15 ohm) by normalized on-resistance factor from
curve (Fig. 6).
7.Overload testing per MIL-R-28750 is constrained to the limits imposed by the short circuit protection requirements of this specification and DSCC drawing 88062.
Load circuit series inductance for “load shorted” mode of operation to be limited to 50mH max. Maximum repetition rate into a shorted load should not exceed 10
Hz.
8.Proper operation of the status feedback requires a status pull-up resistor. See Fig. 5 for status resistor value.
