SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 126, REV G.1
1N5550/US thru 1N5554/US
Standard
3A STANDARD RECOVERY
RECTIFIERS
A
V AI L AB L E AS
1 N , J AN , J AN T X , J AN T XV
J AN S
J AN EQ U I VAL EN T *
SJ*, SX*, SV*, SS*
Fast Recovery Rectifiers
Qualified per MIL-PRF-19500/420
DESCRIPTION:
This voidless hermetically sealed standard recovery rectifier diode series is military qualified per
MIL-PRF-19500/420 and is targeted for space, commerical and military aircraft, military vehicles,
shipboard markets and all high reliability applications.
FEATURES / BENEFITS:
Hermetic, non-cavity glass package
Category I Metallurgically bonded
All parts are 100% hot solder dipped
JAN/ JANTX/ JANTXV available per MIL-PRF-19500/420
“JANS Plus” removes atypical/out of family V
F
ELECTRICAL CHARACTERISTICS
MAX. RATINGS / ELECTRICAL CHARACTERISTICS
RATING
Peak Inverse Voltage
(PIV)
1N5550
1N5551
1N5552
1N5553
1N5554
Average DC Output
Current (I
o
)
Peak Single Cycle Surge
Current (I
fsm
)
-
CONDITIONS
All ratings are at T
A
= 25 C unless otherwise specified.
MIN
-
TYP
-
200
400
600
800
1000
T
A
= +55 C
t
p
= 8.3 ms Single
Half Cycle Sine
Wave,
Superimposed On
Rated Load
-
I
f
= 9.0A (300
sec
pulse, duty cycle <
2%)
o
o
MAX
UNIT
Vdc
-
-
-
-
3.0
100
Amps
Amps(pk)
Operating and Storage
Temp. (T
op
& T
stg
)
Maximum Forward
Voltage (V
f
)
1N5550
1N5551
1N5552
1N5553
1N5554
-65
-
-
-
+175
C
Volts
1.2
1.2
1.2
1.3
1.3
©2012 Sensitron Semiconductor
221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798
www.sensitron.com
sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 126, REV G.1
1N5550/US thru 1N5554/US
Standard
3A STANDARD RECOVERY
RECTIFIERS
MELF (Add “US” to part number)
.028 (.72
.019 .48)
0.20 R Max
(5.08)
.003 Min
(.076)
MELF-B
.137 (3.4
.148 3.8)
.200 5.0
.225 5.9)
.137 (3.4
.148 3.8 )
Note:
The cathode side is marked on body with a dark band.
PART ORDERING INFORMATION
The following part numbers can be screened and tested to the military screening flow. The parts are marked in
accordance with the testing performed, example:
Sensitron Screening Level
1N
JAN
JANTX
JANTXV
SJ
SX
SV
JANS
SS
*Part Number--
Leaded Package
(example for 1N5550)
1N5550
JAN1N5550
JANTX1N5550
JANTXV1N5550
SJ5550
SX5550
SV5550
JANS1N5550
SS5550
*Part Number--
Surface Mount Package
(example for 1N5550US)
1N5550US
JAN1N5550US
JANTX1N5550US
JANTXV1N5550US
SJ5550US
SX5550US
SV5550US
JANS1N5550US
SS5550US
*Parts can also be ordered Tape & Reel
