Coaxial
High Power Combiner
5 Way-0° 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
-55°C to 90°C
-55°C to 100°C
ZB5CS-920-10W
450 to 920 MHz
Features
•
•
•
•
high power, up to 10W input power
low insertion loss, 0.4 dB typ.
good isolation, 26 dB typ.
excellent amplitude unbalance, 0.10 dB typ.
Connectors
N-TYPE
CASE STYLE: Z688
Model
ZB5CS-920-10W-N
Price
$144.95
Qty.
(1-9)
Applications
Coaxial Connections
SUM PORT
PORT 1
PORT 2
PORT 3
PORT 4
PORT 5
S
1
2
3
4
5
• UHF transmitters
High Power Combiner Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
450-920
ISOLATION
(dB)
INSERTION
LOSS (dB)
ABOVE 7.0 dB
Typ.
0.4
Max.
1.0
PHASE
UNBALANCE
(Degrees)
Typ.
2.0
Max.
7.0
AMPLITUDE
UNBALANCE
(dB)
Typ.
0.10
Max.
0.6
POWER
INPUT
1
(W)
as
combiner
2
Max.
10
as
splitter
Max.
20
Outline Drawing
Typ. Min.
26
18
1. Over -55°C to +55°C. Derate linearly to 20% of rating at 90°C
2. As a combiner of non-coherent signals, max. power per port is power rating divided by number of ports.
Typical Performance Data
Freq.
(MHz)
S-1
439.33
459.00
498.33
518.00
557.33
616.33
652.00
700.00
748.00
780.00
812.00
844.00
860.00
916.67
945.00
7.45
7.37
7.37
7.34
7.32
7.38
7.42
7.39
7.38
7.39
7.33
7.45
7.43
7.48
7.63
Insertion Loss
(dB)
S-2 S-3 S-4
7.61
7.53
7.50
7.46
7.45
7.49
7.53
7.48
7.45
7.42
7.36
7.44
7.40
7.41
7.50
7.23
7.16
7.19
7.19
7.21
7.31
7.39
7.41
7.44
7.48
7.47
7.62
7.63
7.77
7.98
7.33
7.32
7.35
7.37
7.34
7.39
7.40
7.38
7.42
7.43
7.41
7.55
7.51
7.51
7.59
S-5
7.36
7.34
7.37
7.38
7.34
7.38
7.39
7.36
7.38
7.39
7.37
7.50
7.45
7.43
7.52
Amp.
Unbal.
(dB)
0.38
0.37
0.30
0.27
0.24
0.18
0.14
0.12
0.07
0.10
0.14
0.18
0.23
0.36
0.48
1-2
29.85
31.52
29.76
27.66
24.77
23.71
24.41
26.49
28.55
28.16
26.76
25.33
24.48
21.01
18.59
Isolation
(dB)
2-3
2-5
32.97
34.93
29.48
26.83
23.59
22.17
22.54
24.03
26.09
26.88
26.96
26.69
26.32
23.61
20.84
34.05
36.31
44.62
55.67
43.79
37.80
37.11
37.97
41.36
44.71
42.35
37.12
34.76
28.84
27.05
4-5
23.36
23.92
25.53
26.74
30.54
41.07
33.51
27.88
25.95
26.07
27.75
32.70
38.68
26.36
21.17
Phase VSWR
Unbal.
S
(deg.)
5.06
4.66
4.19
3.84
3.18
2.57
2.46
2.21
1.98
1.42
1.23
1.76
2.16
3.08
3.45
1.32
1.28
1.15
1.09
1.05
1.18
1.21
1.17
1.08
1.03
1.04
1.05
1.05
1.19
1.40
VSWR VSWR
1
5
1.20
1.20
1.18
1.16
1.12
1.07
1.07
1.07
1.07
1.05
1.03
1.02
1.02
1.02
1.02
1.16
1.18
1.22
1.22
1.22
1.19
1.16
1.11
1.07
1.08
1.09
1.11
1.12
1.11
1.09
Outline Dimensions (
inch
)
mm
INSERTION LOSS (dB)
ISOLATION (dB)
A
B
C
7.06 3.13 1.00
7.11 79.50 25.40
J
2.875
73.03
D
E
F
G
.250 1.430 5.630 6.810
6.35 36.32 143.00 172.97
H
.250
6.35
wt
grams
810
ZB5CS-920-10W
INSERTION LOSS
8.0
S-1(dB)
7.8
7.6
7.4
7.2
7.0
435
S-2(dB)
S-5(dB)
ZB5CS-920-10W
ISOLATION
70
2-5(dB)
4-5(dB)
58
46
34
22
10
435
K
L
M
N
P
.156 3.53
.44
.73 1.40
3.96 89.66 11.18 18.54 35.56
537
639
741
843
945
537
639
741
843
945
FREQUENCY (MHz)
ZB5CS-920-10W
VSWR
1.5
#S-VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
435
#1-VSWR
#5-VSWR
FREQUENCY (MHz)
electrical schematic
537
639
741
843
945
FREQUENCY (MHz)
