DAT-15R5-PP+K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> DAT-15R5-PP+K

DAT-15R5-PP+K: DescriptionVariable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size549KB，12 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

DAT-15R5-PP+K Overview

Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN

DAT-15R5-PP+K Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
package instruction	LCC20,.16SQ,20
Reach Compliance Code	unknown
Other features	CMOS COMPATIBLE
Nominal attenuation	15.5 dB
Characteristic impedance	50 Ω
structure	COMPONENT
Maximum input power (CW)	23.98 dBm
Maximum insertion loss	4.7 dB
JESD-609 code	e3
Installation features	SURFACE MOUNT
Number of terminals	20
Maximum operating frequency	4000 MHz
Minimum operating frequency
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	LCC20,.16SQ,20
power supply	3 V
RF/Microwave Device Types	VARIABLE ATTENUATOR
Maximum slew rate	0.1 mA
surface mount	YES
technology	CMOS
Terminal surface	Tin (Sn)
Maximum voltage standing wave ratio	2.1

Preview

Download Datasheet

View All

DAT-15R5-PP+K Related Products

	DAT-15R5-PP+K	1KDAT-15R5-PPT	1KDAT-15R5-PP+T	1KDAT-15R5-PPPR	1KDAT-15R5-PP+E	1KDAT-15R5-PPE	DAT-15R5-PPK	DAT-15R5-PP+T	DAT-15R5-PPT
Description	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, CMOS, 4 X 4 MM, DG983-1, 20 PIN
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Other features	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE
Nominal attenuation	15.5 dB	15.5 dB	15.5 dB	15.5 dB	15.5 dB	15.5 dB	15.5 dB	15.5 dB	15.5 dB
Characteristic impedance	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω
structure	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT
Maximum input power (CW)	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm
Maximum insertion loss	4.7 dB	4.7 dB	4.7 dB	4.7 dB	4.7 dB	4.7 dB	4.7 dB	4.7 dB	4.7 dB
Maximum operating frequency	4000 MHz	4000 MHz	4000 MHz	4000 MHz	4000 MHz	4000 MHz	4000 MHz	4000 MHz	4000 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
RF/Microwave Device Types	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR
Maximum voltage standing wave ratio	2.1	2.1	2.1	2.1	2.1	2.1	2.1	2.1	2.1
Is it Rohs certified?	conform to	-	conform to	-	conform to	-	incompatible	conform to	incompatible
JESD-609 code	e3	e0	-	e0	-	e0	e0	e3	e0
Terminal surface	Tin (Sn)	TIN LEAD	-	TIN LEAD	-	TIN LEAD	Tin/Lead (Sn/Pb)	Tin (Sn)	Tin/Lead (Sn/Pb)
Is Samacsys	-	N	N	N	N	N	-	-	-
Base Number Matches	-	1	1	1	1	1	-	-	-
