M83513/08-C03 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> M83513/08-C03

M83513/08-C03: DescriptionD Microminiature Connector, 21 Contact(s), Male, Crimp Terminal, Plug, N; CategoryThe connector The connector; File Size196KB，2 Pages; ManufacturerGlenair; Websitehttp://www.glenair.com/

Download Datasheet Parametric View All

M83513/08-C03 Overview

D Microminiature Connector, 21 Contact(s), Male, Crimp Terminal, Plug, N

M83513/08-C03 Parametric

Parameter Name	Attribute value
Maker	Glenair
package instruction	N
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	8 weeks
Other features	STANDARD: MIL-DTL-83513
body width	0.208 inch
subject depth	0.196 inch
body length	1.078 inch
Body/casing type	PLUG
Connector type	D MICROMINIATURE CONNECTOR
Contact arrangement	S21P0
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	MALE
contact mode	STAGGERED
Contact resistance	8 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	600VAC V
Durability	500 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	2.78 N
Insulation resistance	5000000000 Ω
insulator material	GLASS FILLED LIQUID CRYSTAL POLYMER
JESD-609 code	e4
MIL compliance	YES
Plug contact pitch	0.05 inch
Match contact row spacing	0.043 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	HOLE .096
Installation type	CABLE
Number of connectors	ONE
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
Plating thickness	50u inch
Rated current (signal)	3 A
Guideline	MIL
Shell material	PLASTIC
Housing size	C
Termination type	CRIMP
Total number of contacts	21
Maximum wire diameter	24 AWG
Minimum wire diameter	26 AWG
Evacuation force-minimum value	0.139 N

Preview

Download Datasheet

View All

MIL-DTL-83513/08 & /09 Micro-D Connectors

Plastic Shell Crimp, Pre-Wired

Micro-D Pre-Wired Pigtails

— These connectors feature gold-plated

TwistPin contacts and mil spec crimp termination. 100% tested and

backpotted, ready for use.

Choose the Wire Type To Fit Your Application

— For lightest weight

and smallest diameter, select M22759/33 space grade insulated wire.

HOW TO ORDER PLASTIC SHELL PRE-WIRED CRIMP MIL-DTL-83513/08 AND /09 CONNECTORS

Base Part

Number

Slash Number

Insert Arrangement

Wire Type

M83513

/08

Pin Connector

(Plug)

/09

Socket Connector

(Receptacle)

M22759/11-26 Teflon

-Insulated Hookup Wire

– 18 Inches (457mm), White

– 36 Inches (914mm), White

– 18 Inches (457mm), 10 Color Repeating

– 36 Inches (914mm), 10 Color Repeating

– 72 Inches (1829mm), White

Codes A - G specify the

shell size. The number

of contacts is shown

below for reference.

A – 9

B – 15

C – 21

D – 25

E – 31

F – 37

G – 51

– 72 Inches (1829mm), 10 Color Repeating

M22759/33-26 Irradiated Tefzel

Insulated Hookup Wire

– 18 Inches (457mm), White

– 36 Inches (914mm), White

– 18 Inches (457mm), 10 Color Repeating

– 36 Inches (914mm), 10 Color Repeating

– 72 Inches (1829mm), White

– 72 Inches (1829mm), 10 Color Repeating

Single Strand Uninsulated Wire

– .500 Inch (12.7mm), Gold Plated

– 1.000 Inch (25.4mm), Gold Plated

– .500 Inch (12.7mm), Tin-Lead Plated

(2)

– 1.000 Inch (25.4mm), Tin-Lead Plated

(2)

Sample Part Number

M83513

/09

— G

APPLICATION NOTES

1. Intermatability:

2. Tin-Plated Wire:

M83513 plastic shell connectors are not intermateable with metal shell M83513 connectors.

The next revision of the mil spec is expected to prohibit the use of pure tin. Glenair M83513

connectors do not contain any components exceeding 97% tin.

The M83513 spec contains a cautionary note regarding M22759/33 wire. The wire insulation is known

to cause corrosion to metal parts when stored in a sealed environment. This corrosion has been

observed on M83513 connectors. Glenair has implemented a packaging procedure to minimize or

eliminate this problem. Connectors are individually wrapped with teflon tape, and the unit pack is a

perforated paper envelope. M22759/33 continues to be the preferred wire for space applications.

3. M22759/33 Corrosion:

U.S. CAGE Code 06324

Printed in U.S.A.

GLENAIR, INC.

•

1211 AIR WAY

•

GLENDALE, CA 91201-2497

•

818-247-6000

•

FAX 818-500-9912

www.glenair.com

E-Mail: sales@glenair.com

L-9

Micro-D

MIL-DTL-83513
