SMBJ170CA/TR7 Overview

Trans Voltage Suppressor Diode,

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	YAGEO
package instruction	R-PDSO-C2
Reach Compliance Code	compliant
Other features	EXCELLENT CLAMPING CAPABILITY, PRSM-MIN, UL CERTIFIED
Maximum breakdown voltage	209 V
Minimum breakdown voltage	189 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 code	DO-214AA
JESD-30 code	R-PDSO-C2
Humidity sensitivity level	1
Maximum non-repetitive peak reverse power dissipation	600 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
polarity	BIDIRECTIONAL
Maximum power dissipation	5 W
Maximum repetitive peak reverse voltage	170 V
surface mount	YES
technology	AVALANCHE
Terminal form	C BEND
Terminal location	DUAL

TRANSIENT VOLTAGE SUPPRESSORS

AC/DC POWER SUPPLY

RoHS compliant & Halogen free

DATA SHEET

SMBJ series

Product specification– April 29, 2019 V.0
