D300RP
Series
Short
Circuit Protected
Regulated,
3W SIP
DC/DC Convert
ers
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Key Features:
●
3W Output Power
●
Short Circuit Protection
●
Tight Line/Load Regulation
●
1,000 VDC Isolation
●
Miniature SIP Case
●
>1.5 MHour MTBF
●
15 Standard Models
Parameter
Input Voltage Range
Input Filter
Reverse Polarity Input Current
Conditions
5 VDC Input
12 VDC Input
24 VDC Input
Min.
4.5
10.8
21.6
Typ.
5.0
12.0
24.0
Max.
5.5
13.2
26.4
0.3
Units
VDC
π (Pi) Filter
A
Units
%
%
%
mV P - P
%
±0.02
Continuous
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,000
1,000
60
40
Conditions
Ambient
Case
Min.
-25
-25
-40
Free Air Convection
RH, Non-condensing
95
%
Typ.
+25
Max.
+71
+85
+125
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
ºC
ºC
ºC
%/ºC
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation (Note 1)
Ripple & Noise (20 MHz) (Note 2)
Output Power Protection
Temperature Coefficient
Output Short Circuit
120
For Vin Min to Max
Conditions
Min.
Typ.
Max.
±2.0
±0.5
±0.5
75
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
MicroPower Direct
232 Tosca Drive
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Physical
Case Size
Case Material
Weight
1.26 x 0.32 x 0.55 Inches (32.0 x 8.0 x 14.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.17 Oz (4.8g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
5 VDC Input
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
12 VDC Input
24 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
1.5
Min.
-0.7
-0.7
-0.7
Typ.
Max.
9.0
18.0
30.0
260
450
ºC
mW
VDC
Typ.
Max.
Units
MHours
Units
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Model
Number
D301RP
D302RP
D303RP
D304RP
D305RP
D311RP
D312RP
D313RP
D314RP
D315RP
D321RP
D322RP
D323RP
D324RP
D325RP
Notes:
Input
Voltage (VDC)
Nominal
Range
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
Current (mA)
Full-Load No-Load
895
90
895
90
833
90
833
90
857
90
373
60
373
60
347
60
347
60
357
60
192
30
192
30
179
30
179
30
174
30
Voltage
(VDC)
5.0
9.0
12.0
15.0
24.0
5.0
9.0
12.0
15.0
24.0
5.0
9.0
12.0
15.0
24.0
Output
Current
(mA, Max)
600.0
333.0
250.0
200.0
125.0
600.0
333.0
250.0
200.0
125.0
600.0
333.0
250.0
200.0
125.0
Current
(mA, Min)
60.0
33.0
25.0
20.0
12.5
60.0
33.0
25.0
20.0
12.5
60.0
33.0
25.0
20.0
12.5
Efficiency
(%, Typ)
67
67
72
72
70
67
67
72
72
70
65
65
70
70
72
Fuse Rating
Slow-Blow
(mA)
1,500
1,500
1,500
1,500
1,500
700
700
700
700
700
350
350
350
350
350
1. Output load regulation is specified for a load change
of 20% to 100%.
2. When measuring output ripple, it is recommended
that an external 0.33 μF ceramic capacitor be placed
from the +Vout pin to the -Vout pin.
3. Operation at no-load will not damage these units.
However, they may not meet all specifications.
4. These do not require external components to operate,
but the use of a low ESR capacitor (approximately
10 uF, ESR <1.0Ω at 100 kHz) mounted close to the
converter input pins is recommended.
5. It is recommended that a fuse be used on the input of
a power supply for protection. See the table above for
the correct rating.
Derating Curve
Capacitive
Load
μF Max
470
Pin Connections
Pin
1
2
3
9
10
11
12
Function
+Vin
NC
NC
NC
-Vout
+Vout
-Vin
Mechanical Dimensions
NC: No Connection
Notes:
All dimensions are typical in inches (mm)
Tolerance x.xx = ±0.01 (±0.25)
Pin 1 is marked by a “dot” or indentation on the side of the unit
MicroPower Direct
www.micropowerdirect.com
232 Tosca Drive Stoughton, MA 02072
■
TEL:
(781) 344-8226
■
FAX:
(781) 344-8481
■
E-Mail:
sales@micropowerdirect.com
