LT1127ACN#TR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> LT1127ACN#TR

LT1127ACN#TR: DescriptionIC QUAD OP-AMP, 160 uV OFFSET-MAX, 65 MHz BAND WIDTH, PDIP14, 0.300 INCH, PLASTIC, DIP-14, Operational Amplifier; CategoryAnalog mixed-signal IC Amplifier circuit; File Size275KB，12 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric View All

LT1127ACN#TR Overview

IC QUAD OP-AMP, 160 uV OFFSET-MAX, 65 MHz BAND WIDTH, PDIP14, 0.300 INCH, PLASTIC, DIP-14, Operational Amplifier

LT1127ACN#TR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Linear ( ADI )
Parts packaging code	DIP
package instruction	DIP,
Contacts	14
Reach Compliance Code	compliant
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.05 µA
Nominal Common Mode Rejection Ratio	124 dB
Maximum input offset voltage	160 µV
JESD-30 code	R-PDIP-T14
JESD-609 code	e0
length	19.558 mm
Negative supply voltage upper limit	-22 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	4
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Maximum seat height	3.809 mm
Nominal slew rate	10.2 V/us
Supply voltage upper limit	22 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Nominal Uniform Gain Bandwidth	65000 kHz
width	7.62 mm

Preview

Download Datasheet

View All

LT1126/LT1127

Dual/Quad

Decompensated Low Noise,

High Speed Precision Op Amps

FEATURES

■

DESCRIPTIO

100% Tested Low Voltage Noise: 2.7nV/√Hz Typ,

4.2nV/√Hz Max

Slew Rate: 11V/µs Typ

Gain-Bandwidth Product: 65MHz Typ

Offset Voltage, Prime Grade: 70µV Max

Low Grade: 100µV Max

High Voltage Gain: 5 Million Min

Supply Current Per Amplifier: 3.1mA Max

Common Mode Rejection: 112dB Min

Power Supply Rejection: 116dB Min

Available in 8-Lead SOIC, 8-Lead DIP, 16-Lead SO

and 14-Lead DIP Packages

The LT

1126 dual and LT1127 quad are high perfor-

mance, decompensated op amps that offer higher slew

rate and bandwidth than the LT1124 dual and the LT1125

quad operational amplifiers. The enhanced AC perfor-

mance is available without degrading DC specs of the

LT1124/LT1125. Both LT1126/LT1127 are stable in a gain

of 10 or more.

In the design, processing and testing of the device, par-

ticular attention has been paid to the optimization of the

entire distribution of several key parameters. Slew rate,

gain-bandwidth and 1kHz noise are 100% tested for each

individual amplifier. Consequently, the specifications of

even the lowest cost grades (the LT1126C and the LT1127C)

have been enhanced.

Power consumption of the dual LT1126 is less than one

half of two OP-37s. Low power and high performance in an

8-pin SO package makes the LT1126 a first choice for

surface mounted systems and where board space is

restricted.

, LTC and LT are registered trademarks of Linear Technology Corporation. All other

trademarks are the property of their respective owners. Protected by U.S. Patents including

4775884, 4837496.

APPLICATIO S

■

Two and Three Op Amp Instrumentation Amplifiers

Low Noise Signal Processing

Active Filters

Microvolt Accuracy Threshold Detection

Strain Gauge Amplifiers

Direct Coupled Audio Gain Stages

Tape Head Preamplifiers

Microphone Preamplifiers

Accelerometer Amplifiers

Infrared Detectors

TYPICAL APPLICATIO

– INPUT

Low Noise, Wide Bandwidth Instrumentation Amplifier

1/4

LT1127

–

RMS VOLTAGE NOISE DENSITY (nV/

√

Hz)

620

Ω

6.2k

10k

200

Ω

–

1/4

LT1127

+ INPUT

6.2k

620Ω

1/4

LT1127

OUTPUT

10k

GAIN = 1000, BANDWIDTH = 480kHz

INPUT REFERRED NOISE = 4.5nV/

√

Hz AT 1kHz, 6µV

RMS

OVER BANDWIDTH

1126-7 TA01

Voltage Noise vs Frequency

100

15V

= 25°C

MAXIMUM

1/f CORNER

2.3Hz

0.1

1.0

FREQUENCY (Hz)

1126-7 TA01b

TYPICAL

100

1000

11267fa
