CY74FCT257TQCT: DescriptionMultiplexer, FCT Series, 4-Func, 2 Line Input, 1 Line Output, True Output, CMOS, PDSO16, 0.150 INCH, QSOP-16; Categorylogic logic; File Size134KB，5 Pages; ManufacturerCypress Semiconductor

Download Datasheet Parametric Compare View All

CY74FCT257TQCT Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CY74FCT257TQCT	-	-	View	Buy Now

CY74FCT257TQCT Overview

Multiplexer, FCT Series, 4-Func, 2 Line Input, 1 Line Output, True Output, CMOS, PDSO16, 0.150 INCH, QSOP-16

CY74FCT257TQCT Parametric

Parameter Name	Attribute value
Maker	Cypress Semiconductor
Parts packaging code	SOIC
package instruction	SSOP,
Contacts	16
Reach Compliance Code	unknown
series	FCT
JESD-30 code	R-PDSO-G16
length	4.9 mm
Load capacitance (CL)	50 pF
Logic integrated circuit type	MULTIPLEXER
Number of functions	4
Number of entries	2
Output times	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
propagation delay (tpd)	10.5 ns
Certification status	Not Qualified
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	5.25 V
Minimum supply voltage (Vsup)	4.75 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
width	3.9116 mm
