4
RM6 Inductors
• Inductance Range
180mH to 27mH
DC Current mA.
800
700
600
500
400
300
200
100
0
Single Inductor Current Capacity
1 dc. mA. Rated
1 dc. mA. Saturation
10000
Impedance (Z) Kilohms
1000
100
10
1
0.1
5.6
6.8
0.1
0.4
Single Inductor Frequency Response
Impedance for 0.68mH
Impedance for 1.5mH
Impedance for 2.7mH
Impedance for 4.7mH
Impedance for 10mH
• Fixed or Tuneable up
to 17%
• Temperature Range
-20 to 120°C
• Core Material Curie
Temperature > 150°C
0.68
0.82
1.0
1.2
1.5
3.9
2.7
1.8
Inductance, mH
2.2
3.3
4.7
8.2
10
0.3
0.56
0.7
0.8
0.96
1.2
1.45
1.6
1.86
2.2
2.6
3.0
3.4
Frequency, MHz
Mechanical Data
Mass 7.5gm approx.
15.5 x 15.5 plan x 13mm height
2
5
PCB Foot Print
1
2
5
2
3
5
4
6
Part Numbering System
Example
- RM 6F 333 S
Style
RM
Pinned Bobbin
RS
Surface Mount
Form
S
- single
C
- common mode
D
- differential
Size
6F
-
Fixed
6T
-
Tuneable.
Inductance Value
Extended Range
183 = 1.8mH
273 = 2.7mH
393 = 3.9mH
Specials
682 = 0.68mH 563 = 5.6mH
822 = 0.82mH 683 = 6.8mH
103 = 1.0mH
823 = 8.2mH
123 = 1.2mH
104 = 10mH
CONTACT US NOW
UNITED KINGDOM
CRYDOM
T
+44 (0) 1202 897969
F
+44 (0) 1202 891918
E
magnetics@crydom.com
W
www.crydom.co.uk
USA
CRYDOM
T
+1 619 210 1600
F
+1 619 710 8540
E
sales@crydom.com
W
www.crydom.com
Preferred values
153 = 1.5mH
223 = 2.2mH
333 = 3.3 mH
473 = 4.7mH
Example RM6F333S =
RM5 3.3mH fixed single inductor with pinned bobbin.
Other values & package styles available on request.
