P3P623S05A/B,

P3P623S09A/B

Timing-Safet Peak EMI

Reduction IC

Functional Description

P3P623S05/09 is a versatile, 3.3 V Zero−delay buffer

designed to distribute Timing−Safe clocks with Peak EMI

reduction. P3P623S05 is an eight−pin version, accepts one

reference input and drives out five low−skew Timing−Safe

clocks. P3P623S09 accepts one reference input and drives

out nine low−skew Timing−Safe clocks.

All parts have on−chip PLL that locks to an input clock on

the CLKIN pin. The PLL feedback is on−chip and is

obtained from the CLKOUT pad, internal to the device.

Multiple P3P623S05 / P3P623S09 devices can accept the

same input clock and distribute it. In this case, the skew

between the outputs of the two devices is guaranteed to be

less than 700 pS.

All outputs have less than 200 pS of cycle−to−cycle jitter.

The input and output propagation delay is guaranteed to be

less than

±350

pS, and the output−to−output skew is

guaranteed to be less than 250 pS.

Refer “Spread Spectrum Control and Input−Output Skew

Table” for deviations and Input−Output Skew for

P3P623S05A/B and P3P623S09A/B devices.

P3P623S05/09 operates from a 3.3 V supply and is

available in TSSOP package, as shown in the ordering

information table.

Application

www.onsemi.com

TSSOP8 4.4x3

CASE 948AL

TSSOP16 4.4x5

CASE 948AN

ORDERING INFORMATION

See detailed ordering and shipping information in the package

dimensions section on page 6 of this data sheet.

Spread Spectrum Frequency Generation

P3P623S05/09 is targeted for use in Displays and memory

interface systems.

General Features

•

Clock Distribution with Timing−Safe Peak EMI

•

Reduction

Input Frequency Range: 20 MHz

−

50 MHz

Multiple Low Skew Timing−Safe Outputs:

♦

P3P623S05: 5 Outputs

♦

P3P623S09: 9 Outputs

Supply Voltage: 3.3 V

0.3 V

Packaging Information:

♦

P3P623S05: 8 Pin TSSOP

♦

P3P623S09: 16 Pin TSSOP

True Drop−in Solution for Zero Delay Buffer

These Devices are Pb−Free, Halogen Free/BFR Free

and are RoHS Compliant

The clocks in digital systems are typically square waves

with a 50% duty cycle and as frequencies increase the edge

rates also get faster. Analysis shows that a square wave is

composed of fundamental frequency and harmonics. The

fundamental frequency and harmonics generate the energy

peaks that become the source of EMI. Regulatory agencies

test electronic equipment by measuring the amount of peak

energy radiated from the equipment. In fact, the peak level

allowed decreases as the frequency increases. The standard

methods of reducing EMI are to use shielding, filtering,

multi−layer PCBs, etc. These methods are expensive.

Spread spectrum clocking reduces the peak energy by

reducing the Q factor of the clock. This is done by slowly

modulating the clock frequency. The P3P623S05/09 uses

the center modulation spread spectrum technique in which

the modulated output frequency varies above and below the

reference frequency with a specified modulation rate. With

center modulation, the average frequency is the same as the

unmodulated frequency and there is no performance

degradation.

Timing−Safe Technology

Timing−Safe technology is the ability to modulate a clock

source with Spread Spectrum technology and maintain

synchronization with any associated data path.

Semiconductor Components Industries, LLC, 2014

October, 2014

−

Rev. 0

Publication Order Number:

P3P623S05B/D
