OP400HS-REEL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> OP400HS-REEL

OP400HS-REEL: DescriptionQUAD OP-AMP, 400000uV OFFSET-MAX, 0.5MHz BAND WIDTH, PDSO16, MS-013AA, SOIC-16; CategoryAnalog mixed-signal IC Amplifier circuit; File Size1MB，17 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

OP400HS-REEL Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	OP400HS-REEL	-	-	View	Buy Now

OP400HS-REEL Overview

QUAD OP-AMP, 400000uV OFFSET-MAX, 0.5MHz BAND WIDTH, PDSO16, MS-013AA, SOIC-16

OP400HS-REEL Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	MS-013AA, SOIC-16
Contacts	16
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.02 µA
Nominal Common Mode Rejection Ratio	130 dB
Maximum input offset voltage	400000 µV
JESD-30 code	R-PDSO-G16
JESD-609 code	e0
length	10.3 mm
Humidity sensitivity level	1
Negative supply voltage upper limit	-20 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	4
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Maximum seat height	2.65 mm
Nominal slew rate	0.15 V/us
Supply voltage upper limit	20 V
Nominal supply voltage (Vsup)	15 V
surface mount	YES
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Nominal Uniform Gain Bandwidth	500 kHz
width	7.5 mm

Preview

Download Datasheet

View All
