2SA1430
TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)
2SA1430
Strobe Flash Applications
Medium Power Amplifier Applications
Unit: mm
•
High DC current gain and excellent h
FE
linearity
: h
FE (1)
= 140 to 600 (V
CE
=
−1
V, I
C
=
−0.5
A)
: h
FE (2)
= 60 (min), 120 (typ.) (V
CE
=
−1
V, I
C
=
−4
A)
•
Low saturation voltage: V
CE (sat)
=
−0.5
V (max)
(I
C
=
−2
A, I
B
=
−50
mA)
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
DC
Collector current
Pulsed
(Note 1)
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CES
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
j
T
stg
Rating
−20
−20
−10
−6
−2
−4
−2
1000
150
−55
to 150
A
Unit
V
V
V
JEDEC
JEITA
TOSHIBA
―
―
2-7D101A
A
mW
°C
°C
Weight: 0.2 g (typ.)
Note 1: Pulse width = 10 ms (max), duty cycle = 30% (max)
Note 2: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly
even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute
maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
1
2006-11-09
2SA1430
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
V
(BR) EBO
h
FE (1)
DC current gain
(Note 3)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
=
−20
V, I
E
= 0
V
EB
=
−6
V, I
C
= 0
I
C
=
−10
mA, I
B
= 0
I
E
=
−1
mA, I
C
= 0
V
CE
=
−1
V, I
C
=
−0.5
A
V
CE
=
−1
V, I
C
=
−4
A
I
C
=
−2
A, I
B
=
−50
mA
V
CE
=
−1
V, I
C
=
−2
A
V
CE
=
−1
V, I
C
=
−0.5
A
V
CB
=
−10
V, I
E
= 0, f = 1 MHz
Min
―
―
−10
−6
140
60
―
―
―
―
Typ.
―
―
―
―
―
120
−0.20
−0.83
140
50
Max
−100
−100
―
―
600
―
−0.50
−1.5
―
―
V
V
MHz
pF
Unit
nA
nA
V
V
Note 3: h
FE (1)
classification A: 140 to 280, B: 200 to 400, C: 300 to 600
Marking
A1430
Part No. (or abbreviation code)
Lot No.
Characteristics
indicator
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
2
2006-11-09
2SA1430
RESTRICTIONS ON PRODUCT USE
•
The information contained herein is subject to change without notice.
20070701-EN
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor
devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical
stress. It is the responsibility of the buyer, when utilizing TOSHIBA products, to comply with the standards of
safety in making a safe design for the entire system, and to avoid situations in which a malfunction or failure of
such TOSHIBA products could cause loss of human life, bodily injury or damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as
set forth in the most recent TOSHIBA products specifications. Also, please keep in mind the precautions and
conditions set forth in the “Handling Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability
Handbook” etc.
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications
(computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances,
etc.).These TOSHIBA products are neither intended nor warranted for usage in equipment that requires
extraordinarily high quality and/or reliability or a malfunction or failure of which may cause loss of human life or
bodily injury (“Unintended Usage”). Unintended Usage include atomic energy control instruments, airplane or
spaceship instruments, transportation instruments, traffic signal instruments, combustion control instruments,
medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in his
document shall be made at the customer’s own risk.
•
The products described in this document shall not be used or embedded to any downstream products of which
manufacture, use and/or sale are prohibited under any applicable laws and regulations.
•
The information contained herein is presented only as a guide for the applications of our products. No
responsibility is assumed by TOSHIBA for any infringements of patents or other rights of the third parties which
may result from its use. No license is granted by implication or otherwise under any patents or other rights of
TOSHIBA or the third parties.
•
Please contact your sales representative for product-by-product details in this document regarding RoHS
compatibility. Please use these products in this document in compliance with all applicable laws and regulations
that regulate the inclusion or use of controlled substances. Toshiba assumes no liability for damage or losses
occurring as a result of noncompliance with applicable laws and regulations.
4
2006-11-09
