F-210-1
DWM–20–53–G–S–300
DWM–10–59–G–D–500
(1,27mm) .050"
DWM, HDWM SERIES
HDWM–32–51–G–D–230
THROUGH-HOLE MICRO BOARD STACKER
SPECIFICATIONS
Mates with:
SMS, SLM, RSM
DWM
For complete specifications
see www.samtec.com?DWM
Insulator Material:
Top: Black LCP
Bottom: Natural
LCP
Terminal Material:
Phosphor Bronze
Plating:
Au or SN over
50µ" (1,27µm) Ni
Current Rating:
1A
Operating Temp Range:
-55°C to + 105°C with Tin
-55°C to + 125°C with Gold
RoHS Compliant:
Yes
B o a rd
Stacking
SO CK ET
PR OF ILE
OV ER AL L PO ST
T/ H
PI N
(O AL )
OV ER AL L
SM T
PI N
(O AL )
BO AR D
SP AC E
ST AC KE R
HE IG HT
HDWM
For complete specifications
see www.samtec.com?HDWM
Same as DWM except
not CSA rated.
TA IL
(1,27mm)
.050" pitch
TYPE
STRIP
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
These Series are
non-standard, non-returnable.
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
OTHER
OPTION
01
thru
50
DWM
–L
= 10µ" (0,25µm)
Gold contact,
Matte Tin
on tail
–S
= Single
Row
–“XXX”
= Stacker
Height
Example:
–250 =
(6,35mm)
.250"
– “XXX”
= Polarized
Position
(Specify
position of
omitted pin)
–D
= Double
Row
Processing:
Lead-Free Solderable:
Yes
–G
= 10µ" (0,25µm)
Gold on post,
Gold flash
on tail
= Standard Board Spacer
HDWM
= High Temp Board Spacer
50
(1,27) .050 x
No. of Positions
01
(2,48)
.098
02
(1,27) .050 TYP
100
(2,54)
.100
01
(4,98)
.196
(0,46) .018 SQ
99
(0,00)
.000
MIN
OAL
(2,54)
.100
STACKER
HEIGHT
(5,08)
.200
MIN
LEAD
STYLE
–01
–51
–52
–53
–54
–55
–56
–57
–58
–59
–60
–61
OAL
(11,43) .450
(10,41) .410
(10,80) .425
(12,83) .505
(14,10) .555
(15,49) .610
(15,88) .625
(16,51) .650
(17,91) .705
(19,18) .755
(20,96) .825
(26,67) 1.050
www.samtec.com
(0,51)
.020
(0,51) .020 DIA
(3,05)
.120
WWW.SAMTEC.COM
