Film capacitors – Power Factor Correction
PhiCap capacitors
B32344D****A***
B32344D / MKPxxx-D
EPCOS AG 2010. Reproduction, publication and dissemination of this publication, enclosures hereto and the information
contained therein without EPCOS' prior express consent is prohibited
Film capacitors – Power Factor Correction
PhiCap capacitors
B32344D****A***
B32344D / MKPxxx-D
Construction
Dielectric: metallized polypropylene film
Semi-dry; biodegradable soft resin; non-PCB
Case: extruded round aluminum can with stud
Mounting and grounding: threaded M12 stud
on bottom of can
Degree of protection: IP20; optionally IP54
with terminal plastic cap
Features
Three-phase, ceramic discharge resistor
pre-mounted
Dual safety system: overpressure
disconnector, self-healing technology
C
US
file # E106388
C22.2 Nº190 MC # 236094
Naturally air cooled (or forced air cooling)
Indoor mounting
Typical applications
For Power Factor Correction
Terminals
SIGUT terminals
Mounting
Threaded stud at bottom of can
(max. torque = 10 Nm for M12)
Dimensional drawing
Characteristics
Rated capacitance C
R
and Q
R
Tolerance
Connection
Rated voltage V
R
Rated frequency f
R
According to specification table
–5/+10%
D (Delta)
According to specification table
50/60 Hz
FK PC PM PFC
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 2 of 16
March 2010
Film capacitors – Power Factor Correction
PhiCap capacitors
B32344D****A***
B32344D / MKPxxx-D
Technical data and specifications
Maximum ratings (accord. to IEC 60831)
Maximum permissible voltage V
max
V
R
+10% (up to 8 h daily)
V
R
+15% (up to 30 min daily)
V
R
+20% (up to 5 min daily)
V
R
+30% (up to 1 min daily)
Up to 1.3 · I
R
(up to 1.5 · I
R
incl. combined effects of
harmonics, overvoltages and capacitance)
Up to 200 · I
R
< 0.2 W/kvar
< 0.45 W/kvar
Maximum permissible current I
max
Maximum transient inrush current
Power dissipation (dielectric)
Power dissipation
(excluding discharge resistors)
Test data (accord. To IEC 60831)
AC test voltage terminal-to-terminal
Insulation voltage between terminals and
container
Dissipation factor tan
at 100 Hz
Climatic category / –25/D (to IEC 60831)
2.15 · V
R
, 2 s
3000 V AC, 10 s
1.0 · 10
-3
Ambient temperature
Max. temp.
Max. mean 24 h =
Max. mean 1 year =
Lowest temperature =
Average relative:
4000 m
55 °C
45 °C
35 °C
–25 °C
< 95%
Maximum permissible humidity
Maximum permissible altitude
Mean life expectancy
t
LD
Up to 100.000 operating hours
Max. 5000 switching operations according to IEC 60831
FK PC PM PFC
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 3 of 16
March 2010
Film capacitors – Power Factor Correction
PhiCap capacitors
B32344D****A***
B32344D / MKPxxx-D
Design data
Dimensions (d × l)
Weight approx.
Filling
Fixing
Max. torque (Al can stud)
Mounting position
Terminals
Degree of protection
Max. torque
Terminal cross section
Maximum terminal current
Creepage distance
Clearance
Safety
Mechanical safety
Max. short circuit current
Discharge resistor time
Reference standards
IEC 60831–1/2. UL 810-5
th
edition
Ceramic discharge resistor, pre-mounted
Tear off fuses, overpressure disconnector
(AFC: 10 kA) (to UL 810)
≤
1 min (75 V) , IEC 60831 specifies 3 min.
IP20; optional IP54 with plastic terminal cap
10 Nm
16 mm
2
60 A (continuous)
12.7 mm
9.6 mm (to UL 810)
According to specification table
According to specification table
Biodegradable soft resin
Threaded bolt M12
10 Nm
Upright. See “Installation and maintenance
instructions for PFC capacitors” for further details.
FK PC PM PFC
Please read
Cautions and warnings
and
Important notes
at the end of this document.
Page 4 of 16
March 2010
Film capacitors – Power Factor Correction
PhiCap capacitors
B32344D****A***
B32344D / MKPxxx-D
Three-phase capacitors – V
R
= 220 V AC, 50/60 Hz, delta connection
Product / Type
Ordering code
MKP220-D-1.7
B32344D2021A020
MKP220-D-2.0
B32344D2021A520
MKP220-D-4.2
B32344D2051A020
MKP220-D-6.3
B32344D2071A520
MKP220-D-6.3
B32344D2101A020
MKP220-10.4
B32344D2121A520
MKP220-D-12.5
B32344D2151A020
Product / Type
Ordering code
MKP230-D-2.0
B32344D2022A030
MKP230-D-2.5
B32344D2022A530
MKP230-D-5.0
B32344D2052A030
MKP230-D-7.5
B32344D2072A530
MKP230-D-10.0
B32344D2102A030
MKP230-D-12.5
B32344D2122A530
MKP230-D-15.0
B32344D2152A030
50 Hz
Output
I
R
kvar
A
1.7
2.0
4.2
6.3
8.3
10.4
12.5
4.4
5.5
11.0
16.4
21.9
27.4
32.8
60 Hz
Output
I
R
kvar
A
2.0
2.5
5.0
7.5
10.0
12.5
15.0
5.3
6.6
13.2
19.7
26.3
32.9
39.4
C
R
μF
3 × 37.0
3 × 46.0
3 × 92.0
3 × 137.0
3 × 183.0
3 × 229.0
3 × 274.0
C
R
μF
3 × 42.0
3 × 50.0
3 × 100.0
3 × 150.0
3 × 200.0
3 × 250.0
3 × 300.0
Dimensions
d×h
mm
75 × 138
75 × 138
75 × 198
85 × 198
85 × 273
85 × 273
85 × 348
Dimensions
d×h
mm
75 × 138
75 × 138
75 × 198
85 × 198
85 × 273
85 × 273
85 × 348
Weight
kg
0.4
0.4
0.6
0.8
1.2
1.5
1.5
Weight
kg
0.4
0.4
0.6
0.8
1.2
1.5
1.5
Quantity
per
box
6
6
6
4
4
4
4
Quantity
per
box
6
6
6
4
4
4
4
Three-phase capacitors – V
R
= 230 V AC, 50/60 Hz, delta connection
50 Hz
Output
I
R
kvar
A
2.0
2.5
5.0
7.5
10.0
12.5
15.0
5.3
6.3
12.5
18.8
25.0
31.3
37.7
60 Hz
Output
I
R
kvar
A
2.5
3.0
6.0
9.0
12.0
15.0
1)
6.3
7.5
15.0
22.5
30.0
37.5
1)
