BL-HG026D-TRB
●
Features:
1. Emitted Color : Yellow Green
2. Lens Appearance : White Ddiffused.
3. Mono-color type.
4. 1.6x0.8x0.8mm(0603) standard package.
5. Suitable for all SMT assembly methods.
6. Compatible with infrared and vapor phase
reflow solder process.
7. Compatible with automatic placement
equipment.
8. This product doesn’t contain restriction
Substance, comply ROHS standard.
●
Package Dimensions:
●
Applications:
1.
2.
3.
Automotive : Dashboards, stop lamps,
turn signals.
Backlighting : LCDs, Key pads advertising.
Status indicators : Comsumer & industrial
electronics.
NOTES:
1.All dimensions are in millimeters (inches).
2.Tolerance is ±0.10mm (0.004”) unless otherwise specified.
3.Specifications are subject to change without notice.
4.
General use.
●
Absolute Maximum Ratings(Ta=25℃)
Parameter
Power Dissipation
Forward Current
Peak Forward Current
＊1
Reverse Volage
Operating Temperature
Storage Temperature
Soldering Temperature
Derating Linear From 25℃
Infrared Soldering Condition
Vapor Soldering Condition
Symbol
Pd
I
F
I
FP
V
R
Topr
Tstg
Tsol
-
-
-
Rating
80
30
100
5
-55℃~85℃
-55℃~85℃
See Page6
0.6
240℃(for 10 Seconds)
215℃(for 3Minutes)
Unit
mW
mA
mA
V
-
-
-
mA/℃
-
-
＊1
Condition for
I
FP
is pulse of 1/10 duty and 0.1msec width.
Ver.2.0 Page 1 of 7
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BL-HG026D-TRB
Max.
2.6
-
100
-
576
●
Electrical and optical characteristics(Ta=25℃)
Parameter
Forward Voltage
Luminous Intensity
Reverse Current
Peak Wave Length
Dominant Wave Length
Spectral Line Half-width
Veiwing Angle
Symbol
Vf
Iv
I
R
λp
λd
Δλ
2θ
1/2
Condition
I
F
=20mA
I
F
=20mA
V
R
=5V
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
Min.
-
3.7
-
-
566
-
-
Typ.
2.2
12.0
-
568
Unit
V
mcd
µA
nm
nm
nm
deg
30
120
-
-
●
Typical Electro-Optical Characteristics Curves
Fig.1 Relative intensity vs. wavelength
1.0
60
Fig.2 Forward current derating curve
vs. ambient temperature
50
Relative radiant intensity
Forward current (mA)
40
0.5
30
20
10
0
515
568
615
0
20
40
60
80
100
Wavelength (nm)
Ambient temperature Ta( C)
Fig.3 Forward current vs. forward voltage
50
3.0
Fig.4 Relative luminous intensity vs.
ambient temperature
40
2.5
Relative Luminous intensity
(Normalized @20mA)
1
2
3
4
5
Forward current (mA)
2.0
30
1.5
20
1.0
10
0.5
0
0
-40
-20
0
20
40
60
Forward voltage(V)
Ambient temperature Ta( C)
Fig.5 Relative luminous intensity
vs. forward current
4.0
RADIATION DIAGRAM
0
10
20
30
Relative luminous intensity (@20mA)
3.0
RELATIVE RADIANT INTENSITY
40
1.0
0.9
0.8
50
60
70
0.7
80
90
2.0
1.0
0
10
20
30
40
50
0.5
0.3
0.1
0.2
0.4
0.6
Forward current (mA)
Ver.2.0 Page 2 of 7
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BL-HG026D-TRB
●
Tapping and packaging specifications(Units: mm)
USER DIRECTION OF FEED
1.04
±
0.1
1.08
±
0.1
ANODE
START
END
71.0
±
0.1
13.0
±
0.5
1.88
±
0.1
13.0
±
0.5
5.3
±
0.05
8.0
±
0.3
CATHODE
4.0
±
0.1
4.0
±
0.1
1.5
±
0.1
2.0
±
0.05
1.75
±
0.1
3.5
±
0.05
TRAILER
LEADER
0.3
FIXING TAPE
NOTE: 3000 pcs PER REEL
●
Package Method:(unit:mm)
12 bag/box
3000 pcs/reel
215
Bar Code Label
245
230
167
220
Aluminum Foil Bag
645
6 box/carton
230
334
Ver.2.0 Page 3 of 7
179
±
1
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BL-HG026D-TRB
●
Bin Limits
Intensity Bin Limits (At 20mA)
BIN CODE
Min. (mcd)
F
G
H
J
2.1
3.2
4.8
7.0
Max. (mcd)
4.2
6.3
9.4
14.0
Color Bin Limits (At 20mA)
BIN CODE
4
5
6
7
8
Min. (nm)
565
567
569
571
573
Max. (nm)
569
571
573
575
577
Ver.2.0 Page 4 of 7
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BL-HG026D-TRB
●
Reliability Test
Classification
Test Item
Operation Life
Reference Standard
MIL-STD-750:1026
MIL-STD-883:1005
JIS-C-7021 :B-1
MIL-STD-202:103B
JIS-C-7021 :B-11
MIL-STD-883:1008
JIS-C-7021 :B-10
JIS-C-7021
:B-12
Test Conditions
Ta=Under RoomTemperature As Per Data
Sheet Maximum Rating
Test Time=1000HRS(-24HRS,+72HRS)＠
20mA
Ta=+65℃±5℃
RH=90%-95%
Test time=240hrs±2HRS
High Ta=+105℃±5℃
Test time=1,000hrs(-24HRS,+72HRS)
Low Ta=-55℃±5℃
Test time=1,000hrs(-24HRS,+72HRS)
+105℃ ~ +25℃ ~ -55℃ ~ +25℃
30min
5min 30min 5min
Test Time=10cycle
IR-Reflow In-Board, 2
(10min)~-40±5℃(10min)
Test Time=10cycle
T.sol=260±5℃
Dwell Time=10±1secs
Times
85±5
℃
0/20
Result
0/20
Endurance
Test
High
Temperature
High Humidity
Storage
High
Temperature
Storage
Low
Temperature
Storage
Temperature
Cycling
0/20
0/20
0/20
Thermal Shock
Solder
Resistance
Environmental IR-Reflow
Test
MIL-STD-202:107D
MIL-STD-750:1051
MIL-STD-883:1010
JIS-C-7021 :A-4
MIL-STD-202:107D
MIL-STD-750:1051
MIL-STD-883:1011
MIL-STD-202:201A
MIL-STD-750:2031
JIS-C-7021 :A-1
-
0/20
0/20
0/20
0/20
0/20
0/20
0/20
0/20
0/20
0/20
0/20
0/20
Solderability
-
Solderability
-
Ramp-up rate(183℃ to Peak)+3℃ 1sec
max
Temp maintain at125
±
25℃ 120sec max
Temp maintain above 183℃ 60〜150sec
Peak temperature range 235℃〜240℃
Time within5℃ of actual Pwck
Temperature10-30sec
Ramp-down rate+6℃ 1sec max
T.sol=235
±
5
℃
Immesion time 2
±
0.5sec
Immesion rate 25
±
2.5mm/sec
Coverage≧95% of the dipped surface
●
Judgment criteria of failure for the reliability
Measuring items
Forward voltage
Reverse current
Luminous intensity
Symbol
V
F
( V)
I
R
(uA)
Iv ( mcd )
Measuring conditions
I
F
=20mA
V
R
=5V
I
F
=20mA
Judgement criteria for failure
Over Ux1.2
Over Ux2
Below SX0.5
Note:
1.U means the upper limit of specified characteristics.
S means initial value.
2.Measurment shall be taken between 2 hours and after the test pieces have been returned to
normal ambient conditions after completion of each test.
Ver.2.0 Page 5 of 7
