39-01-0431 datasheet, PDF - EEWORLD Datasheet

39-01-0431: Description4.20mm (.165") Pitch Mini-Fit Jr.垄芒 Receptacle Housing, Single Row, PA Polyamide Nylon 6/6, UL 94V-0, 3 Circuits, First Mate Last Break; File Size108KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet View All

39-01-0431 Overview

4.20mm (.165") Pitch Mini-Fit Jr.垄芒 Receptacle Housing, Single Row, PA Polyamide Nylon 6/6, UL 94V-0, 3 Circuits, First Mate Last Break

Preview

Download Datasheet

View All

This document was generated on 05/19/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0039014031

Active

minifit_jr

4.20mm (.165") Pitch Mini-Fit Jr.™ Receptacle Housing, Single Row, PA Polyamide

Nylon 6/6, UL 94V-0, 3 Circuits, First Mate Last Break

Documents:

3D Model

Test Summary (PDF)

Drawing (PDF)

Product Specification PS-5556-001 (PDF)

RoHS Certificate of Compliance (PDF)

Agency Certification

CSA

TUV

LR19980

R72081037

E29179

General

Product Family

Series

Comments

Crimp Housings

5557

Current = 13A max. per circuit when header is mated

to a receptacle loaded with 45750 series terminals

crimped to 16 AWG wire. . See Molex product

specification PS-45750-001 for additional current

de-rating information.. Glow Wire Equivalent Part

Number 50291662. See Molex product specification

PS-5556-001 for additional current de-rating information.

minifit_jr

Mini-Fit Jr.™

EU RoHS

ELV and

Complia

REACH S

Not Revie

Halogen

Status

Halogen

Need mo

environm

Email pro

For a mu

Complian

Overview

Product Name

Please vi

non-prod

Physical

Breakaway

Circuits (maximum)

Color - Resin

Flammability

Gender

Glow-Wire Compliant

Keying to Mating Part

Lock to Mating Part

Material - Resin

Number of Rows

Packaging Type

Panel Mount

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Polarized to Mating Part

Stackable

Temperature Range - Operating

Natural (White)

94V-0

Female

None

Yes

Nylon

Bag

0.165 In

4.20 mm

0.165 In

4.20 mm

Yes

-40°C to +105°C

5557Se

Mates

39-01-4

Free H

Header

39-30-3

Use W

44476

Termin

Female

Fit® Hi

Electrical

Current - Maximum per Contact

13A

Material Info

Old Part Number

5557-03R2-210

Reference - Drawing Numbers
